Summary of Contents for Euroquip Strata SLR1100
- Page 1 SLR1100 LASER WELDING HELMET USER MANUAL EN 175 ANSI Z87.1 CSA Z94.3 AS/NZS 1337.1 EN 207 AS/NZS 1337.4 PLEASE READ AND UNDERSTAND ALL INSTRUCTION BEFORE USE. RETAIN THIS MANUAL FOR FUTURE REFERENCE. www.strata.co.nz...
-
Page 2: Table Of Contents
SLR1100 LASER WELDING HELMET TABLE OF CONTENTS SECTION 1 − SAFETY PRECAUTIONS − READ BEFORE USING 1-1. Symbol Usage 1-2. Warnings SECTION 2 − SPECIFICATIONS SECTION 3 − ADJUSTING HEADGEAR SECTION 4 − REPLACING THE FILTER SECTION 5 − MAINTENANCE SECTION 6 −... -
Page 3: Section 1 − Safety Precautions − Read Before Using
SLR1100 LASER WELDING HELMET SECTION 1 − SAFETY PRECAUTIONS − READ BEFORE USING Protect yourself and others from injury — read, follow, and save these important safety precautions and operating instructions. 1-1. Symbol Usage DANGER! − Indicates a hazardous �� Indicates special instructions. situation which, if not avoided, will result in death or serious injury. -
Page 4: Warnings
SLR1100 LASER WELDING HELMET Read Instructions • Read and follow all labels and the User Manual carefully before in stalling, operating, or servicing unit. Read the safety information at the beginning of the manual and in each section. • Use only genuine replacement parts from the manufacturer. •... -
Page 5: Section 2 − Specifications
SLR1100 LASER WELDING HELMET SECTION 2 − SPECIFICATIONS Helmet Shell Special Nylon (Flame Retardant) Filter Special Polycarbonate Compound Filter Dimension 7.6 x 4.7 x 0.09 in. (193 x 120 x 2.4 mm) View Size 6.73 x 4.63 in. (171 x 117.6 mm) Shade No.# W3.0# Visible Light Transmission... -
Page 6: Section 3 − Adjusting The Headgear
SLR1100 LASER WELDING HELMET SECTION 3 − ADJUSTING THE HEADGEAR There are four head-gear adjustments: headgear top, tightness, angle adjustment, and distance adjustment. Headgear Top Adjustment Adjusts headgear for prop-er depth on the head to en-sure correct balance and stability. Headgear Tightness Adjustment To adjust, turn the adjusting knob located on the back of the headgear left or right to desired tightness. -
Page 7: Section 4 − Replacing The Filter
SLR1100 LASER WELDING HELMET SECTION 4 − REPLACING THE FILTER The Filter is a protection lens and must be replaced if broken, damaged or covered with laser welding spatter to the extent that vision is impaired. Push the plugs inside the helmet up,see position 1,The Filter will released from the helmet ;pull the Filter out. see position 2. -
Page 8: Section 5 − Maintenance
SLR1100 LASER WELDING HELMET SECTION 5 − MAINTENANCE NOTICE − Never use solvents or abrasive cleaning detergents. NOTICE − Do not immerse the lens assembly in water. The helmet requires little maintenance. However, for best performance clean helmet after each use. Using a soft cloth dampened with a mild soap and water solution, wipe the cover lenses clean. -
Page 9: Section 7 − Parts List
SLR1100 LASER WELDING HELMET SECTION 7 − PARTS LIST Part Name: Part Number: 1. Helmet shell SLR1100-1 2. Filter lens SLR1100-2 2.1 Filter protective film SLR1100-2.1 3. Block nut SLR1100-3 4. Block washer SLR1100-4 5. Headgear slider (with 5 slots) SLR1100-5 6. -
Page 10: Section 8 − Warranty
Registered warranty period for the SLR1100 Laser No costs incurred will be considered under warranty if Welding Helmet: repairs are carried out by a party other than a Euroquip Commercial Use: 12 Months Approved Service Agent, unless with prior consent in Domestic Use: 12 Months writing from Euroquip. - Page 11 SLR1100 LASER WELDING HELMET Notes www.strata.co.nz...
- Page 12 This product is backed by our extensive warranty and world-wide service network. To locate your nearest dis- tributor or service agency visit www.strata.co.nz, or email us at info@ euroquip.co.nz www.strata.co.nz...
