Summary of Contents for EUROCHILL ERE72
- Page 1 EUROCHILL BENCHTOP 4 BAY SCOOP ICE CREAM FREEZER USER MANUAL EUROCHILL ICE CREAM FREEZER MODEL: ERE72 V2 07/24 SOUTHERN p: 0800 503 335 | w: www.southernhospitality.co.nz DISTRIBUTED BY: HOSPITALITY e: online@southernhospitality.co.nz...
-
Page 2: Table Of Contents
Model Specifications ....................Disposal ............................ Thank you for purchasing a Eurochill Ice Cream Freezer. Please read the operation instructions before use for correct application. This appliance complies with the requirement of 2006/42/EC. SOUTHERN p: 0800 503 335 | w: www.southernhospitality.co.nz... -
Page 3: General
GENERAL 1. This unit has a fully enclosed compressor and the refrigerant R290 used is environmentally friendly. The unit runs at a constant temperature. 2. The unit features an artistic and elegant appearance with a double hollow transparent glass door giving the operator easy access. -
Page 4: Handling And Care
HANDLING AND CARE Handling Dry Place Unplug the unit from the wall socket first. Always lo cate the unit in a dry place. Never tilt the unit over 45 degrees during handling. 10cm Sufficient Space Ventilation The distance from both sides and back of the unit to Always locate the unit in a place with good the wall or other things must not be less than 10cm. -
Page 5: Power Supply & Safety
POWER SUPPLY AND SAFETY Power Socket Earth Bar Power Outlet Sockets The power supply is 220–240V single phase AC with Plug power cord into a dedicated single exclusive single phase, three pin plug (250V, 10A) socket outlet. Do not use a multi-plug. and fuse (6A). -
Page 6: Operation
OPERATION 1. Before use Plug the unit into a 220–240V~ single socket. After the unit is running, place hand on the air suction to confirm it is sufficiently cold. Then place icecream in the unit. 2. Digital temperature controller The controller is a mini-sized, integrated intelligent controller which controls the 1 HP compressor. -
Page 7: User Warnings & Cautions
USER WARNINGS & CAUTIONS • Open the door for a short time and reduce open frequency to keep a cold temperature inside the refrigerator. • Never block the air suction and outlet. Keep air circulation and refrigeration capability. • Do not overfill the unit as it will influence the cooling effect. •... -
Page 8: Maintenance
MAINTENANCE 1. Note Keep the unit clean. Periodical maintenance is necessary. Always unplug the unit before maintenance. To prevent an electric shock or a short circuit, never use a damaged plug or wall socket. Never flush the unit. Never use alkali detergent, soap, gasoline, acetone or a brush. 2. -
Page 9: Refrigeration System
REFRIGERATION SYSTEM Refrigerant flows through the compressor, which raises the pressure of the refrigerant. Next the refrigerant flows through the condenser, where it condenses from vapour form to liquid form, giving off heat in the process. After the condenser, the refrigerant goes through the expansion valve, where it experiences a pressure drop. -
Page 10: Disposal
NOTES 1. The electrical circuit diagram and parameters on the product nameplate are final ones if they have been changed. 2. The specifications of the unit may change without notice. Disposal Disposal of the unit must take place in an environmentally correct way. Please note existing regulations on disposal.
