DeLOCK 47232 User Manual

Declaration of conformity
Products with a CE symbol fulfill the EMC directive (2014/30/EU) and
RoHS directive (2011/65/EU+2015/863+2017/2102), which were released by the
EU-comission.
The declaration of conformity can be downloaded here:
https://www.delock.de/produkte/G_47232/merkmale.html
WEEE-notice
The WEEE (Waste Electrical and Electronic Equipment)-directive, which became
effective as European law on February 13th 2003, resulted in an all out change
in the disposal of disused electro devices. The primarily purpose of this directive
is the avoidance of electrical waste (WEEE) and at the same time the support of
recycling and other forms of recycling in order to reduce waste. The WEEE-logo
on the device and the package indicates that the device should not be disposed
in the normal household garbage. You are responsible for taking the disused
electrical and electronical devices to a respective collecting point. A separated
collection and reasonable recycling of your electrical waste helps handling the
natural resources more economical. Furthermore recycling of electrical waste is
a contribution to keep the environment and thus also the health of men. Further
information about disposal of electrical and electronical waste, recycling and
the collection points are available in local organizations, waste management
enterprises, in specialized trade and the producer of the device.
Cet appareil
se recycle
Points de collecte sur www.quefairedemesdechets.fr
EU Import: Tragant Handels- und Beteiligungs GmbH
Beeskowdamm 13/15, 14167 Berlin, Germany
Support Delock
If you have further questions, please contact our customer support
support@delock.de
You can find current product information on our homepage: www.delock.com
Final clause
Information and data contained in this manual are subject to change without notice
in advance. Errors and misprints excepted.
Copyright
No part of this user's manual may be reproduced, or transmitted for any purpose,
regardless in which way or by which means, electronically or mechanically, without
explicit written approval of Delock.
Edition: 08/2024
User manual
Mode d'emploi
Uživatelská příručka
Manuale utente
Manual de utilizare
Korisnički priručnik
3.5" Mobile Rack for
1 x 2.5" U.2 NVMe SSD or
SATA / SAS HDD / SSD
English
Description
This solid metal mobile rack by Delock can be installed into a free 3.5" bay of a
PC.
U.2 SFF-8639 interface also suitable for SATA and SAS
A 2.5" U.2 SSD can be mounted in the tray and slid into the rack.
A SATA or SAS HDD or SSD can also be installed. Depending on which memory
type is installed, the appropriate cable must be connected to the backside and
connected to the system. This is possible because the SFF-8639 port allows the
connection of a SAS 29 pin or SATA cable.
The hot swap function allows the exchange of the hard disk drive during operation.
Tray with key lock
The mobile rack is equipped with a key lock to prevent unauthorised access.
Specification
• Connectors:
internal: 1 x U.2 SFF-8639 female
external: 1 x U.2 SFF-8639 male
• Suitable for 2.5" U.2 / SATA / SAS HDD / SSD:
HDD height up to 15 mm
supports 5 V SATA / SAS HDD / SSD
supports 12 V SAS HDD / SSD
• Data transfer rate:
SATA up to 6 Gb/s
SAS up to 12 Gb/s
NVMe up to 32 Gb/s
• 1 x On / Off switch
• Key lock
• Hot Swap
System requirements
• Linux Kernel 3.19 or above
• Windows 7/7-64/8.1/8.1-64/10/10-64/11
• Windows Server 2016
• PC with one free 3.5" bay
• A free U.2 port or
• A free SATA / SAS port
Bedienungsanleitung
Manual del usuario
Instrukcja obsługi
Bruksanvisning
Használati utasítás
Εγχειρίδιο χρήστη
Product-No: 47232
User manual no: 47232-a
www.delock.com
