  • Page 1 RDERING SSISTANCE PESA Switching Systems, Inc. 103 Quality Circle, Suite 210 Huntsville AL 35806 USA www.qustream.com FFICE Tel: 256.726.9200 Fax: 256.726.9271 ERVICE EPARTMENT Tel: 256.726.9222 (24/7) Toll Free: 800.323.7372 Fax: 256.726.9268 Email: service@qustream.com Document Number 81-9059-0545-0 Revision B TREAM ORPORATION...
  • Page 2 UCI-2000-S P ROTOCOL RANSLATOR 2008 QuStream Corporation Original Printing © 2003 PESA Switching Systems, Inc. All Rights Reserved. UCI-2000 is a trademark of PESA Switching Systems, Inc. in the United States and/or other countries. Microsoft, Windows, and Windows NT are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
  • Page 3 81-9059-0545-0 Rev. B UCI-2000-S P ROTOCOL RANSLATOR About This Manual This manual provides detailed instructions for the installation, operation, and maintenance of the PESA UCI-2000-S Protocol Translator. Warnings, Cautions, and Notes Warning statements identify conditions or practices that can result in personal injury or loss of life.

  • Page 4: Table Of Contents

    81-9059-0545-0 Rev. B UCI-2000-S P ROTOCOL RANSLATOR Contents CHAPTER 1 – INTRODUCTION......................1 CHAPTER 2 - INSTALLATION......................2 Receipt Inspection ........................2 Unpacking ..........................2 Location ............................ 2 Mounting ........................... 3 Cabling............................4 Plug-In Card Installation......................4 Power Supply Installation......................4 CHAPTER 3 –...

  • Page 5: Chapter 1 - Introduction

    81-9059-0545-0 Rev. B UCI-2000-S P ROTOCOL RANSLATOR Chapter 1 – Introduction The PESA UCI-2000-S protocol converter is designed to provide an interface between Sony and PESA routing switchers and control systems. The UCI-2000-S can operate in one of two distinct modes, allowing PESA routing matrices to be controlled by a Sony control system and control panels or allowing Sony routing matrices to be controlled by a PESA 3500 family control system.

  • Page 6: Chapter 2 - Installation

    81-9059-0545-0 Rev. B UCI-2000-S P ROTOCOL RANSLATOR Chapter 2 - Installation This section details UCI-2000-S Mainframe installation procedures. The following topics are discussed: • Receipt Inspection • Unpacking • Location • Mounting • Cabling • Plug-In Card Installation • Power Supply Installation The UCI-2000-S contains static sensitive devices.

  • Page 7: Mounting

    81-9059-0545-0 Rev. B UCI-2000-S P ROTOCOL RANSLATOR 2.4 Mounting The UCI-2000-S Mainframe is rack mounted in a standard 19” equipment rack. Sufficient space must be provided behind the rack to allow for the control and power cables. All mounting holes should be utilized and mounting hardware tightened securely.

  • Page 8: Cabling

    81-9059-0545-0 Rev. B UCI-2000-S P ROTOCOL RANSLATOR 2.5 Cabling All cables should be strain relieved and secured to racks or other supporting structures. Failure to provide adequate cable support can result in cables separating from connectors. If cable runs are to be stored under an elevated floor, they should be tied to the racks as a guide.

  • Page 9: Chapter 3 - Setup And Operation

    81-9059-0545-0 Rev. B UCI-2000-S P ROTOCOL RANSLATOR Chapter 3 – Setup and Operation 3.1 Sony to PESA Mode The Sony to PESA control mode allows the UCI-2000-S to control up to eight levels of PESA PRC-based routing switchers from the Sony control system. Each of the eight additional levels can support a matrix size of 256 x 256 inputs and outputs.

  • Page 10: Pesa To Sony Mode

    81-9059-0545-0 Rev. B UCI-2000-S P ROTOCOL RANSLATOR 3.2 PESA to Sony Mode The PESA to Sony control mode allows the UCI-2000-S to control up to eight levels of Sony S- BUS based routing switchers from a PESA 3500 family control system. Each of the eight additional levels can support a matrix size of 256 x 256 inputs and outputs.

  • Page 11: Hardware Configuration

    81-9059-0545-0 Rev. B UCI-2000-S P ROTOCOL RANSLATOR 3.3 Hardware Configuration 3.3.1 Setting the Operating Mode Dip switch S1 on the UCI-2000-S PC board is used to set the card’s operating mode. Available operating modes for the UCI-2000-S are listed in Table 1 below. Table 1.

  • Page 12: Setting The Control Levels

    81-9059-0545-0 Rev. B UCI-2000-S P ROTOCOL RANSLATOR Currently, the UCI-2000-S only supports the default S-BUS data rate of 384k bps and does not support the new high-speed S-BUS that operates at 1M bps. If a newer Sony HDS-X series router or BKPF-R70A control card is used as the S-BUS Primary station, please ensure that the dip switch that sets the S-BUS data rate is configured to use the 312k bps setting.

  • Page 13: Configuring The On-Board Jumpers

    81-9059-0545-0 Rev. B UCI-2000-S P ROTOCOL RANSLATOR Switches 5, 6 and 7 of S6 set the number of controlled Sony matrices according to the following table: Table 4. Number of Controlled Sony Levels S2-5 S2-6 S2-7 Function UCI Controls 8 Levels UCI Controls 1 Levels UCI Controls 2 Levels UCI Controls 3 Levels...

  • Page 14: Software Configuration

    81-9059-0545-0 Rev. B UCI-2000-S P ROTOCOL RANSLATOR PESA To Sony Mode: J4 - J5 (COM 1: RS-422) Not Used J14 - J16 (COM 2: RS-232) Diagnostic Terminal J7 - J9 (COM 3: RS-422) PRC Port J1: 1 - 2 J10: 3 - 4, 5 - 6 J12: 2 - 3 J13: 1 –...

  • Page 15: Cable Connections

    81-9059-0545-0 Rev. B UCI-2000-S P ROTOCOL RANSLATOR 3.5 Cable Connections 3.5.1 Sony to PESA Mode: COM1: PRC - Connect to PESA Routers COM2: RS232 Terminal/PC (38400,N,8,1) COM3: Not Used SYSTEM V CONTROL (37-pin): Not Used BNC #4: Connect to Sony S-BUS Controller and Routers Figure 6.

  • Page 16: Pesa To Sony Mode

    81-9059-0545-0 Rev. B UCI-2000-S P ROTOCOL RANSLATOR 3.5.2 PESA to Sony Mode: COM1: Not Used COM2: RS232 Terminal/PC (38400,N,8,1) COM3: PRC - Connect to PESA 3500 family control system SYSTEM V CONTROL (37-pin): Not Used BNC #4: Connect to Sony S-BUS Controller and Routers Figure 7.
