RUNHOOD

Runhood Residential ESS & Portable

Power Station Product User Manual

Version

Date

V1.0

2023.08.04

V1.1

2023.08.29

V1.2

2024.04.07

V1.3

2024.04.08

The copyright of this document belongs to Shanghai Anku Smart Energy Co., Ltd. Any

violation of rights will be prosecuted

F2400-US

V1.3

version management

Change person

Auditing

Qinwei

Zhaoqiuhong

Wangliwen

Zhaoqiuhong、

Wangliwen

Ratify

Change content

First edition

Additional functions

Table of Contents

Need help?

Do you have a question about the F2400-US and is the answer not in the manual?

Questions and answers

Summary of Contents for RUNHOOD F2400-US

Page 1 RUNHOOD Runhood Residential ESS & Portable Power Station Product User Manual F2400-US V1.3 version management Version Date Change person Auditing Ratify Change content V1.0 2023.08.04 Qinwei First edition V1.1 2023.08.29 Zhaoqiuhong Additional functions V1.2 2024.04.07 Wangliwen Additional functions Zhaoqiuhong、 V1.3 2024.04.08...
Page 2: Table Of Contents
RUNHOOD catalogue 1 Product Definition .............................3 1.1 Application scenarios ..........................3 1.2 System Block Diagram ........................3 1.3 F2400 ................................ 4 1.3.1 Product appearance ....................... 4 1.3.2 Principle Block Diagram ......................5 1.3.3 Specification parameters ...................... 5 1.3.4 basic function ..........................8 1.3.5 Grid connection function ....................17 2 Appendix ................................23...
Page 3: Product Definition
RUNHOOD 1 Product Definition 1.1 Application scenarios Application Scenario one: Used as an outdoor mobile energy storage power source. Supports input methods such as AC charging, photovoltaic charging, and vehicle charging. Supports DC output such as USB, DC12V10A, and AC output. Can be moved and stacked for use.
Page 4: F2400
RUNHOOD 1.3 F2400 Composed of battery pack, inverter, DC interface, parallel interface, etc. 1.3.1 Product appearance F2400 product appearance diagram The copyright of this document belongs to Shanghai Anku Smart Energy Co., Ltd. Any violation of rights will be prosecuted...
Page 5: Principle Block Diagram
RUNHOOD 1.3.2 Principle Block Diagram F2400 Principle Block Diagram 1.3.3 Specification parameters F2400 Cell specifications LiFePO4（LFP64151，50Ah） Cell model LFP64151/50Ah Battery Grouping method 15S1P Electricity level 2400Wh Rated current charging：40A；discharge：50A The copyright of this document belongs to Shanghai Anku Smart Energy Co., Ltd. Any...
Page 6 RUNHOOD Maximum current charging：40A；discharge：80A Voltage range 40.5-54Vdc temperature range charging：-15℃~55℃；discharge：-25℃~55℃ Number of cycles 8000 cycles to 70%+ capacity@25℃ LCD Screen Support（Broken code screen） Lamp Support（Flip） Key1 Main Power switch on/off Key2 AC on/off Key3 DC on/off Key4 Wifi Reset PV Max Input Voltage 60Vdc...
Page 7 RUNHOOD Australian regulations 230Vac， 50Hz， 10A， 1800W Max China regulations 220Vac，50Hz，10A，1800W Max American regulations 120Vac, 60Hz, total 2400W Max (Socket*5 & Back-Up*1) Japanese regulations 100Vac, 50/60Hz, total 2400W Max (Socket*4 & Back-Up*1) European regulations 230Vac, 50Hz, total 2400W Max (Socket*4 & Back-Up*1)
Page 8: Basic Function
RUNHOOD switch Weight 29kg Dimensions 503mm*323mm*344mm 1.3.4 basic function LCD display screen Display the battery level and usage status information of the product. icon information Prompt explanation Current address The current ID of the F2400 product. Number of battery packs...
Page 9 RUNHOOD operation Grid connected power When the grid connection switch is turned on, generation prompt this icon is displayed. OTA indication During OTA, this icon is displayed. The system supports the use of external grid connected hybrid inverters. At this time, the...
Page 10 RUNHOOD not allow charging or discharging. The product will automatically reset after reaching the working temperature. If the device does not reset, please contact product expertservice@runhoodpower.com。 When this icon prompts, it indicates a serious malfunction. Check for strong static or...
Page 11: Led Lights
PV or DC charging input port Specification XT60EW-M. We can charge the power supply through the dedicated connection cable of RUNHOOD's built-in car charging port, and can charge the power supply through a photovoltaic panel. Supports solar panel series parallel input, rated voltage range: 12-60Vdc, maximum supported voltage: 150V, current: 25A Max, power: 1200W Max.
Page 12 RUNHOOD Press and hold the DC switch to turn on or off the F2400 DC power output, while lighting up the indicator light for the DC output. This button controls the DC output, USB-A, and USB-C outputs of the F2400 car charging port.
Page 13 RUNHOOD Turn on the main power button, and the buzzer will sound once to prompt the system to turn on. Press and hold the main power button for 3 seconds, the buzzer will sound once, indicating that the system is shut down normally. Press and hold the main power button for 10 seconds, the buzzer will sound three times, indicating that the system is forced to shut down.
Page 14 RUNHOOD Connect the negative electrode of the battery module in series CAN0H Signal line of CAN bus CAN0L Signal line of CAN bus M_TX Signal transmission through uplink communication M_RX Signal transmission through uplink communication Ground 2/10000 SYN_ON System start signal...
Page 15 RUNHOOD Connect the negative electrode of the battery module in series CANH Parallel communication CAN-H CANL Parallel communication CAN-L S_RX Lower link communication receiving signal S_TX Send signal through lower link communication S_DET Downlink access signal detection SYN_ON System start signal...
Page 16 RUNHOOD RS485_A_EMS EMS module RS485-A RS485_A PCS module RS485 A RS485_B PCS module RS485 B RJ45-2 (COM2) Debug Port Pin Description Number identification description CAN0H Debugging communication CAN_H CAN0L Debugging communication CAN_L Ground RS485_B1 Internal inverter module RS485-B RS485_A1 Internal inverter module RS485-A...
Page 17: Grid Connection Function
RUNHOOD switch. 6-digit dial switch, 1-5 is the reserved switch, and 6 is the communication internal resistance 120 Ω access switch. When there are multiple F2400 connected to the grid, it is necessary to select one F2400 as the main device. Set the main device dial 1 to ON and 2-5 to OFF; The remaining F2400 dials 1-5 to OFF.
Page 18 RUNHOOD supplying power to the load, and the insufficient power is then supplied to the load by the power grid. (2) Timer mode Set the charging and discharging time period through the manual APP, such as during the low electricity price period at night, which can be set as the charging time period. The system charges the energy storage at maximum charging power during this period, and during the high electricity price period, it is set as the discharging time period.
Page 19 RUNHOOD network process uses the BluFi provided by ESP32, which is a WIFI network configuration function based on Bluetooth channel. The process diagram and the specific distribution network process of F2400 are as follows: F2400/Intelligent socket Bluetooth network distribution process diagram ESP32 enables GATT Server mode to send broadcasts with specific advertising data.
Page 20 RUNHOOD ESP32 for key negotiation. After receiving the data frame for key negotiation, ESP32 will parse it according to a custom negotiation method. Key negotiation between mobile phone and ESP32. The negotiation process can use encryption algorithms such as DH/RSA/ECC.
Page 21 RUNHOOD Diagram of LAN Device Discovery The process of WiFi device discovery in local area network is as follows: Triggered by power on, if no correct response is received, continue to send with a 1-second interval between sending; After confirming disconnection from TCP Server, continue to send multicast messages;...
Page 22 RUNHOOD Within the local area network, WiFi devices act as TCP clients and F2400 acts as TCP servers for data transmission; WiFi devices report data every 1 second, and the server responds with the corresponding message after receiving the data; The fixed port number is 3333.
Page 23: Appendix
RUNHOOD 2 Appendix 2.1 Disclaimer The length of all external cables shall not exceed 3m. 2.2 FCC Caution a、§ 15.19 Labeling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this...
Page 24 This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. FCC ID:2BB59-F2400-US The copyright of this document belongs to Shanghai Anku Smart Energy Co., Ltd. Any violation of rights will be prosecuted...
