CSY-207-093 Thank you for purchasing DAIICHI ELECTRONICS product. Read this instruction manual carefully before installation, wiring, and using this product. Safety precautions Environment conditions Please be sure to use this product in a place that meets the following conditions. In places that do not meet this condition, malfunctions and failures, and performance and product life may be reduced.
Page 3
Aluminum electrolytic capacitors are used in products. Please energize the power supply within one year after purchase. Countermeasures against troubles If trouble occurs within the warranty period, DAIICHI ELECTRONICS will repairs this product. Disposal Please dispose this product as industrial waste (non-combustible).
CSY-207-093 1. Product outline This product is a synchronous check relay with a synchronous verification display developed for synchronous closing between a bus and a generator and between a grid and a grid. This product can be used as a fail-safe for automatic synchronization and manual synchronization. 2.
CSY-207-093 4. Handling explanation 4.1 Display Disposition of display Auxiliary supply Dead bus closing signal POWER:Green D.B.C:Green Voltage difference within setting Synchronism check signal △V:Green △φ:Amber Frequency difference within Phase difference setting (Rectangular LED. 26 points) △F:Green Alarm signal ALARM:Red (Measurement display)...
CSY-207-093 4.2 Outline dimension <Note> Design the panel cutout so that the distance between this unit and adjacent devices is 27mm or more. The thickness of the mounting panel should be 8 mm or less. Precautions for installation Installation should be done by a person who has specialized skills such as electrical work and electrical wiring.
CSY-207-093 4.4 Wiring Be sure to check the phases on LINE side and GENERATOR side. △φ ; Synchronism check signal D.B.C ; Dead bus closing signal ALARM ; Alarm signal Precautions for wiring. ■ ・Do not work with live wires. ・Check the wiring diagram before wiring.
CSY-207-093 4.6 How to set up Please refer to the setting values below and change the settings before applying power. If a setting change is made after power is applied, control will stop and an alarm is output. When resetting the alarm, please set the power supply to no voltage. (Arrangement of setting device) Auxiliary supply Dead bus closing signal...
CSY-207-093 5. Control function 5.1 Control range Bus voltage :90 to 135V AC Bus frequency :50±3Hz, 60±3Hz Generator voltage :More than 80V AC Frequency difference:Within ±4Hz Output is stopped except for the above. 5.2 Control output and description (1) Display of frequency difference within setting (ΔF). If a frequency difference are within the range of ΔF setting value, LED lights of ΔF.
CSY-207-093 6. Operation overview (1) Before application of auxiliary power [bus voltage (VB) and generator voltage (VG) are no voltage]. ① When checking the wiring to this product, make sure that all power and signal lines are in a no-voltage state.
CSY-207-093 7. Test Please refer to the following when conducting a mock test. 1) Performance test ① Apply auxiliary power and verify that the "POWER" LED is illuminated. ② Apply voltage to the bus input (terminals 1-2) and the generator input (terminals 3-4). When the voltage difference and frequency difference are less than the set values (ΔF LED ON, ΔV LED ON) and within Δφ, confirm that Δφ...
CSY-207-093 8. Specification and performance 8.1 Specification Item Specification Bus side input (Single-phase) 110V AC 50/60Hz 0.5VA or AC input Generator side input (Single-phase) 110/√ V AC 50/60Hz 0.5VA Synchronism check signal (Δφ) Control Optical MOS-FET relay output Dead bus closing signal (D.B.C) output MAX.
CSY-207-093 9. Principle of operation 9.1 Block-diagram 9.2 Explanation of operation (1) Frequency measurement. The bus voltage (VB) input and the generator voltage (VG) input are isolated by a VT, then input to the frequency detection circuit via a waveform shaping circuit and a frequency dividing circuit. In the frequency detection circuit, the cycle of AC is counted, taken in the data bus, and the frequency is calculated by software calculation (1 / cycle).
CSY-207-093 10. Maintenance 10.1 Error description № Contents of error Control status Fault output Reset condition Note Equipment ROM/RAM error Control stop Alarm output replacement Equipment A/D error Control stop Alarm output replacement Setting change or Setting error Control stop Alarm output auxiliary power OFF Bus voltage out of range...
