Summary of Contents for W&D EPON ONU
- Page 1 EPON ONU (WD-5716) Quick Start Guide V1.0...
- Page 2 Introduction Thank you for purchasing EPON ONU (WD-5716). The contents in the product box include: One set of WD-5716 Antenna x 2 AC-to-DC power adapter (100Vac ~ 240Vac to +12Vdc) Safety Warnings 1. This product contains a high output-power Laser. Please do not point the SC optical connector directly to eyes.
- Page 3 2 Hardware Connections The rear panel of WD-5716 is described and depicted in the following picture. Interface Description SC/APC type connector for connecting to OLT CATV F-connector for connecting to TV Universal Serial Bus for external storage Four Gigabit Ethernet Ports for connecting to CPE devices 10/100/1000 (1~4) (eg.
- Page 4 3 LED Description When finishing ONU cabling connection, then power on ONU. No software configuration is required for ONU. You can check the LEDs of ONU to see whether ONU works correctly. The LEDs of WD-5716 is depicted in the following figure. The details of the LEDs are described below.
