NewLine Atlas S-Trap Instruction Manual

Close coupled suite

Advertisement

Quick Links

INCLUDES: Pan, Soft Close Seat, Cistern, Valved, Inlet hose, Seals & Fastenings
Wells 4 Star rated with 4.5 & 3 ltr Dual Flush
Important
INSTRUCTION MANUAL
Atlas S-Trap Toilet
Close Coupled Suite
1.When you receive your product check the contents for any freight damage or defects.
2.If this is a custom order, the size will be on the outside of the box. Check that it is correct.
3.Advise Newline on 0508 639 5463 if any damage has occurred or if you have any
questions about the size within 8 hours of receiving the goods so this can be rectified.
4.Do not install faulty products, as this will void your warranty.
