KAVAN Smart PRO SE6 6ch BUS servo decoder -
Instruction manual
INTRODUCTION
Congratulations on purchasing the KAVAN Smart PRO SE6 4ch BUS servo decoder, a device that converts serial bus signals to standard PWM servo
outputs. It offers up to six configurable servo outputs with optional period and fail-safe settings. The SE6 is a perfect choice for models with complex wing
or tail mechanics where multiple servos may be connected to a primary receiver using just a single cable. In addition, if you are running out of receiver
channels simply connect the SE6 to the receiver serial line and freely assign its own output channels.
SUPPORTED PROTOCOLS:
Futaba: S.Bus/S.Bus2
Graupner: SUMD, Hott telemetry for setting
JETI: EX Bus
Multiplex: SRXL 12ch, SRXL 16ch
PowerBox: P²Bus
FEATURES
Small dimensions and high current throughput via the integrated MR30 power connector
Up to 6-channel servo expander
Automatic detection of serial data/telemetry after startup
Configuration through the transmitter, external terminal (JETIBOX/SMART-BOX) or MAV Manager PC software
Firmware updates via USB interface
TECHNICAL SPECIFICATIONS
Dimensions (including connectors)
Weight (including connectors)
Servo output channels
Operating current
Operating temperature
Supply voltage
Continuous current
Peak current
Supported protocols
Status LED
Sensor expander
INSTALLATION
Attach the required servos to the SE6 servo expander. Connect the receiver – use its output port with the serial data option. The SE6 uses the MR30
connector for primary data input.
Turn on the transmitter and apply the appropriate power source to the receiver. The status LED starts blinking as soon as the SE6 detects the signal on
the serial line.
BASIC INSTALLATION
SE4
34×14×9 mm
4 g
3 or 4
15 mA
(-20)–85 °C
4–14 V (recommended 5–8.4 V)
15 A
60 A (2 s)
JETI Duplex, Multiplex, Graupner Hott, Futaba S.Bus, PowerBox P²Bus
Yes
EX Bus: up to 4 sensors
SE6
34×19×8 mm
4,5 g
5 or 6
15 mA
(-20)–85 °C
4–14 V (recommended 5–8.4 V)
15 A
60 A (2 s)
Yes
No
Advertisement
Summary of Contents for Kavan Smart PRO SE6
- Page 1 INTRODUCTION Congratulations on purchasing the KAVAN Smart PRO SE6 4ch BUS servo decoder, a device that converts serial bus signals to standard PWM servo outputs. It offers up to six configurable servo outputs with optional period and fail-safe settings. The SE6 is a perfect choice for models with complex wing or tail mechanics where multiple servos may be connected to a primary receiver using just a single cable.
- Page 2 HIGH POWER INSTALLATION MULTIPLE INSTALLATION IN A COMPLEX WING TELEMETRY AND SETTINGS The device is compatible with JETIBOX for programming. The JETIBOX menu is divided into three sections: Actual values - Displays the latest telemetry values (voltage, temperature, system status) including minimums and maximums. System - Shows the detected serial protocol and its average frame rate.
- Page 3 JETIBOX OR SMART BOX CONNECTION Plug the SE6 into the sensor slot of the JETIBOX/SMART-BOX. Power it up using a battery with appropriate voltage (4.5–8.4V). Now you can configure the device using the arrows on the JETIBOX/SMART-BOX. Optional type of connection. Output No.6 must be configured to a Default connection of JETIBOX/SMART-BOX.
-
Page 4: Safety Information
SAFETY INFORMATION Operate the SE6 always in a dry environment and within the device limits stated in this guide. Never expose the device to excessive heat or cold. Do not remove the heat shrink tube from the device and do not try to implement any changes or modifications. This can result in damage to the product and denial of any warranty claims. - Page 5 GUARANTEE The KAVAN Europe s.r.o. products are covered by a guarantee that fulfils the currently valid legal requirements in your country. If you wish to make a claim under guarantee, please contact the retailer from whom you first purchased the equipment. The guarantee does not cover faults which were caused in the following ways: crashes, improper use, incorrect connection, reversed polarity, maintenance work carried out late, incorrectly or not at all, or by unauthorised personnel, use of other than genuine KAVAN Europe s.r.o.
