Olympia Faucets P-4550 Installation

OLYMPIA FAUCETS, INC.
3325 S. Garfield Ave.
Commerce, CA 90040
(888) 772-7701
www.olympiafaucets.com
Model Number: P-4550
Warnings and Notes:
Check with local plumbing code requirements before installation.
This product should be installed by a local listed plumber.
Do not use plumbers putty on threads.
Installation Steps:
Handheld Shower Set
3/8"
(F)
(H)
(3)
Attach Slide Bar (E) to Diverter Body (H).
●
Make sure a washer is included where Slide
●
Bar (E) connects to Diverter Body (H).
(E)
Insert Diverter Body Escutcheon (G) onto
●
rear end of the Diverter Body (H).
(G)
(H)
(5)
Simultaneously insert the Upper Mounting
●
Bracket (D) into the secured Mounting Flange
(C)
(C) from Step 2 and insert the Diverter Body
(H) into the Inlet Adapter (F) from Step 1.
Use provided Allen wrench to tighten both set
●
(D)
screws from both parts to secure the assembly,
but do not over tighten.
Tighten the nut on the Slide Bar (E) to Divert-
●
(E)
er Body (H) if needed, but do not over tighten.
(H) (H)
(1) Make sure the inlet is 1/2" pipe
nipple and must protrude 3/8" from
the finished wall.
*Note: Inlet Adapter (F) is preinstalled
inside of Diverter Body (H) .
● Loosen the set screw underneath
the Diverter Body (H) , keep set screw
nearby for later step.
Use a tool such as Allen wrench to
●
rotate and take out the Inlet Adapter
(F) from behind.
Apply Teflon tape onto 1/2" pipe
●
nipple and secure the Inlet Adapter
(F) to male 1/2" NPT pipe with Allen
wrench.
Tools:
Power Drill Silicone Sealant
(A)
(D)
(E)
(B)
(K)
(H)
(I)
(J)
INSTALLATION
Teflon Tape
(2)
Drill a 1/4" hole as shown in the
●
drawing.
Make sure the hole is 27-15/16"
●
from the inlet hole, center to center.
Using a hammer to tap a plastic
●
anchor into the hole and flush with
(C)
the wall.
Secure the Mounting Flange (C)
●
on the wall with the help of mounting
screw.
(4)
Attach Shower Arm (A) and Upper Mounting
●
Bracket (D) to Slide Bar (E).
Make sure the Shower Arm (A) is facing front
●
and Upper Mounting Bracket (D) is pointing
toward the wall.
(6)
Attach Vacuum Breaker (I) onto bottom outlet
●
of the Diverter Body (H), then attach SST Hose
(J) with washer onto Vacuum Breaker (I).
Attach Shower Head (B) to outlet end of
●
Shower Arm (A), but do not over tighten.
Attach Handheld Showerhead (K) to outlet
●
end of SST Hose (J) with washer and check
valve.
Rags
