HP SitePrint Robot Top Cover
Accessory Assembly Instructions
© Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice.

Advertisement

loading
Need help?

Need help?

Do you have a question about the SitePrint Robot Top Cover and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HP SitePrint Robot Top Cover

  • Page 1 HP SitePrint Robot Top Cover Accessory Assembly Instructions © Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice.
  • Page 2 HP SitePrint Robot Top Cover Accessory Turn off the HP SiteRobot Printer. Remove the battery. © Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice.
  • Page 3 HP SitePrint Robot Top Cover Accessory Remove the prism or the blue handle. Remove the Top Cover. © Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice.
  • Page 4 HP SitePrint Robot Top Cover Accessory Remove 3 screws T10. Remove the Trim Cover. © Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice.
  • Page 5 HP SitePrint Robot Top Cover Accessory Remove the 4 T10 screws. Please don’t Remove the 2 hinges. Please don’t discard the screws. discard the hinges. © Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice.
  • Page 6 Tighteen the 4 T10 screws with the 4 old the 4 previously used screws. Be careful hinges screws. to insert them in the correct direction. © Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice.
  • Page 7 Insert the new Top Cover. Do not fix it in Remove the tap from the port. place with the screws yet. IMPORTANT: Clean the port before connecting. © Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice.
  • Page 8 HP SitePrint Robot Top Cover Accessory Connect the USB cable in the port. Ensure the USB cable passes through the drain slot. © Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice.
  • Page 9 HP SitePrint Robot Top Cover Accessory Tighten the 4 T10 screws provided with Insert the trim cover. the accessory. © Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice.
  • Page 10 HP SitePrint Robot Top Cover Accessory Tighteen the 3 screws T10 with the same Place the prism or the blue handle. screws. © Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice.
  • Page 11 HP SitePrint Robot Top Cover Accessory Insert the battery © Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice.
  • Page 12 You are set up and ready to work on your first project! © Copyright 2024 HP Development Company, L.P. The information contained herein is subject to change without notice.
