- Page 1 HDCi® LX3 2U Installation Guide www.optronicsplus.net LX3 2U HDCi® LX3 2U PATCH PANEL INSTALLATION GUIDE For more information, please contact our sales team: sales@optronicsplus.net...
-
Page 2: Safety Precautions
HDCi® LX3 2U Installation Guide www.optronicsplus.net HDCi® LX3 2U PATCH PANEL INSTALLATION GUIDE Before installing or adjusting this product, please read these instructions carefully. Please keep this guide for future reference. SAFETY PRECAUTIONS GENERAL PRECAUTIONS Before use, all equipment, especially safety gear, must be inspected and tested for proper operation. Replace and repair as necessary. - Page 3 HDCi® LX3 2U Installation Guide www.optronicsplus.net HDCi®LX3 High Density 2U Patch Panel Operation manual The operation steps for installing the distribution frame on the rack are as follows: 1：Open the distribution frame and check the appearance; 2：Check the quantity of accessory and prepare a cross screwdriver;...
- Page 4 HDCi® LX3 2U Installation Guide www.optronicsplus.net 6： Strip out the optical fibre cable in moderately 7 ： Introduce the optical fibre from the back of length, and fix it up with cable tie module box and split them inside. 1- MTP®/MPO box 1-optical fibre cable 2-cable tie 3-cable fixing plate 4-pigtail...
- Page 5 HDCi® LX3 2U Installation Guide www.optronicsplus.net © 2024, all rights reserved. Specifications are subject to change without notice. For more information, please contact our sales team: sales@optronicsplus.net...
