User Manual
Saturn
RI IMSI
RI Viewer
Research Instruments Ltd
Bickland Industrial Park, Falmouth, Cornwall TR11 4TA, UK
t: +44 (0) 1326 372 753 | f: +44 (0) 1326 378 783 |e: sales@research-instruments.com
www.research-instruments.com
Document 6-47-500UM, Issue 4, 26
Laser System
™
™
™
February 2013
th
Advertisement
Table of Contents
Related Manuals for Research Instruments RI Saturn
Summary of Contents for Research Instruments RI Saturn
- Page 1 ™ RI IMSI ™ RI Viewer ™ Research Instruments Ltd Bickland Industrial Park, Falmouth, Cornwall TR11 4TA, UK t: +44 (0) 1326 372 753 | f: +44 (0) 1326 378 783 |e: sales@research-instruments.com www.research-instruments.com Document 6-47-500UM, Issue 4, 26 February 2013...
- Page 2 CONTENT Section 1 Preface Section 2 Introduction to Saturn™ Laser Systems Intended Use Applicable Part Numbers Microscope Compatibility Installation Section 3 Saturn™ Laser Systems Safety Precautions Safety Precautions Guidance and Manufacturer’s Declaration – Electromagnetic Emissions (IEC 6060 1-1-2) Guidance and Manufacturer’s Declaration — Electromagnetic Immunity Guidance and Manufacturer’s Declaration —...
- Page 3 Section 5 RI Viewer™ Introduction How to View Live Images How to Zoom & Pan the Image Changing Camera Settings How to Take a Picture How to Record Video How to Perform Measurements Section 6 Saturn™ Laser Systems Operation How to Configure the Laser for a New Procedure How to Check Objective Calibration How to Check Laser Target Alignment How to Check Hole Size Calibration...
- Page 4 How to Configure the Foot Pedal/Keyboard How to View Still and Recorded Images How to Select Objectives How to Add Objectives How to Remove Objectives Section 12 Saturn™ Laser Systems Care And Maintenance Disposal of Goods Section 13 Returns Procedure Research Instruments Ltd Customer Feedback...
- Page 5 © This manual is protected by copyright, all rights reserved, and no part hereof may be photocopied or reproduced in any form without the prior written consent of Research Instruments. Saturn™, RI Viewer™ and RI IMSI™ are trademarks of Research instruments Ltd. All other brand names are trademarks of their respective owners.
- Page 6 Section 2 Research Instruments Ltd Introduction to Saturn Laser Systems ™ INTRODUCTION TO SATURN™ LASER SYSTEMS Intended Use The Saturn™ Laser System is intended ‘to ablate a User defined section of a gamete or embryo within ART’. Applicable indications for use are subject to the regulations of the country into which the device is sold.
-
Page 7: Installation
Laser Systems ™ Installation Installation of the Saturn™ Laser System should be carried out by a Research Instruments technician or other RI-authorised personnel. Incorrect installation could result in reduced power output, laser misalignment or laser malfunction. All relevant sections of this manual should be read and understood fully before any operation of the Saturn™... - Page 8 Section 3 Research Instruments Ltd Saturn Laser Systems Safety Precautions ™ SATURN™ LASER SYSTEMS SAFETY PRECAUTIONS Safety This indicates cautionary text which should be followed to avoid injury to users or damage to samples Laser radiation is present within the control unit, the fibre optic patch lead and through the microscope to output at the objective.
- Page 9 Section 3 Research Instruments Ltd Saturn Laser Systems Safety Precautions ™ WARNING Thermal lensing is a defocusing of the laser beam caused by changes to the refractive index of the medium as it is heated. The degree of defocus depends on the total beam energy deposited in the medium.
- Page 10 Section 3 Research Instruments Ltd Saturn Laser Systems Safety Precautions ™ Guidance and Manufacturer’s Declaration – Electromagnetic Emissions (IEC 6060 1-1-2) The Saturn™ Laser System is intended for use in the electromagnetic environment specified below. The customer or the user of the Saturn™ Laser System should assure that it is used in such an environment.
-
Page 11: Guidance And Manufacturer's Declaration - Electromagnetic Immunity
Section 3 Research Instruments Ltd Saturn Laser Systems Safety Precautions ™ Guidance and Manufacturer’s Declaration — Electromagnetic Immunity The Saturn™ Laser System is intended for use in the electromagnetic environment specified below. The customer or the user of the Saturn™ Laser System should ensure that it is used in such an environment. - Page 12 Section 3 Research Instruments Ltd Saturn Laser Systems Safety Precautions ™ Guidance and Manufacturer’s Declaration — Electromagnetic Immunity The Saturn™ Laser System is intended for use in the electromagnetic environment specified below. The customer or the user of the Saturn™ Laser System should assure that it is used in such an environment.
- Page 13 Section 3 Research Instruments Ltd Saturn Laser Systems Safety Precautions ™ User Interface Icons Symbol Meaning Symbol Meaning Take a picture Laser control Take a video General settings Stop video Additional camera recording settings View images Take measurements Choose objective...
- Page 14 Section 3 Research Instruments Ltd Saturn Laser Systems Safety Precautions ™ Symbols SYMBOL MEANING Caution: Federal law restricts this device to sale by or on the order of a (licensed healthcare Only practitioner). Indicates disposal of goods instruction Class 1 laser product...
-
Page 15: Hardware Overview
The light on the front of the control unit indicates that the control unit is operational. If the unit is plugged in PART NUMBER: 2-47-012 and the light is not on, contact Research Instruments for assistance SATURN REAR PANEL ARTWORK... - Page 16 Section 4 Research Instruments Ltd Saturn Laser Systems Product Overview ™ Packaging and Handling Requirements No special packaging or handling requirements Saturn™ Laser System Component Part Numbers Part Number Description 5-47-010 Control Unit with 1.5m Patch Lead 5-47-100 Motor Module (Saturn™ Active) 1-10-100 12V 2.5A Medical PSU (x2 for Saturn Active™)
- Page 17 Section 4 Research Instruments Ltd Saturn Laser Systems Product Overview ™ Saturn™ Mirror Modules 5-45-163 Collimator module for IX53/73/83 5-45-383 Collimator module for IX70 5-45-387 Collimator module for IX71 5-45-388 Collimator module for IX71 fluor 5-45-580 Collimator module for IMT2...
-
Page 18: Electrical Specifications
Section 4 Research Instruments Ltd Saturn Laser Systems Product Overview ™ Laser Specifications Laser Specifications Ablation Laser Pilot Laser Output wavelength 1480nm 650nm Power output from patch lead 400mW 130µW (max) Maximum pulse length 2.0ms None *Laser Safety Classification Class 1 Class 1 * IEC60825-1: 2008, US 21CFR 1040.10... - Page 19 Section 5 Research Instruments Ltd RI Viewer ™ RI VIEWER™ Introduction RI Viewer™ is the software that interacts with the Saturn™ and RI IMSI™ range of products from Research Instruments for use within an ART laboratory. Connected to a camera attached to a microscope, it provides on screen images of samples under the microscope.
-
Page 20: How To Perform Measurements
Section 5 Research Instruments Ltd RI Viewer ™ How to Take a Picture 1. Click on the tool bar. 2. A camera icon will flash briefly in the centre of the screen to let the user know that an image has been taken. - Page 21 Section 6 Research Instruments Ltd Saturn Laser Systems Operation ™ SATURN™ LASER SYSTEMS OPERATION How to Configure the Laser for a New Procedure 1. Check objective calibration. 2. Check laser target alignment. 3. Check hole size calibration. How to Check Objective Calibration 1.
- Page 22 Section 6 Research Instruments Ltd Saturn Laser Systems Operation ™ How to Check Hole Size Calibration The laser objective must be calibrated correctly for the Hole Size Indicator to work correctly. The actual size of hole a laser produces may vary depending on the type of Petri dish and media, the characteristics of the embryo and other factors.
- Page 23 Section 6 Research Instruments Ltd Saturn Laser Systems Operation ™ How to Fire the Laser (Single Pulse) 1. Find the sample under the microscope using an objective with wide field of view (e.g. 4x objective). 2. Hold the sample with a holding pipette at the bottom of the dish.
- Page 24 Section 6 Research Instruments Ltd Saturn Laser Systems Operation ™ Preset Pulse Lengths The preset values can be changed using RI Viewer™. Pulse lengths are limited to stay within Class 1 laser safety standards. Choose the preset by clicking the + or - buttons. To change a preset, select the preset, set the desired value using the slider, and click the Save button.
- Page 25 Section 7 Research Instruments Ltd Assisted Hatching Procedure ASSISTED HATCHING PROCEDURE Introduction The aim of Laser Assisted Hatching (LAH) is to locally weaken the zona pellucida. The specimen is viewed along the optical axis and the laser creates a trench in the zona pellucida which extends above and below the apparent hole.
- Page 26 Section 7 Research Instruments Ltd Assisted Hatching Procedure Hole Size Selection For safe and effective treatment we recommend that pulses used are in the range 15 to 1000ms. Pulses that are very short may be ineffective and pulses that are too long may damage the embryo. For this reason, a warning will appear on the Fire button when pulse width is 15ms or below and when the pulse width is greater or equal to 1000ms.
- Page 27 Section 7 Research Instruments Ltd Assisted Hatching Procedure Move the specimen into the field of view. Select a short pulse length using the handset or the RI Viewer™ controls. The different settings do not vary the power of the laser; they control the length of time that the laser is fired.
- Page 28 Section 8 Research Instruments Ltd Saturn™ Laser Systems Additional Modes SATURN™ LASER SYSTEMS ADDITIONAL MODES USA Clearance Regulations In the USA, Saturn™ Laser Systems are 510(k) cleared for Assisted Hatching only. The operations in this section are for investigational purposes only How to Enable Biopsy Mode 1.
- Page 29 Section 8 Research Instruments Ltd Saturn™ Laser Systems Additional Modes How to Fire the Laser (Multi-Pulse Mode) The laser target cannot be moved during Multi-Pulse Mode. 1. Switch to the Laser Objective. 2. Focus on the sample. 3. Click on the tool bar.
- Page 30 Section 9 Research Instruments Ltd Saturn™ Laser Systems Troubleshooting SATURN™ LASER SYSTEMS TROUBLESHOOTING Problem Possible Cause Solution Check the power supply is No lights on control unit No power input plugged in to the mains and No lights on control unit...
-
Page 31: Specifications
Section 10 Research Instruments Ltd RI IMSI ™ RI IMSI™ Introduction Please read this manual carefully before using the system, and follow the instructions to ensure that your RI IMSI™ system will work reliably. Obtaining high quality images requires careful set-up and regular cleaning. -
Page 32: Sample Preparation
Section 10 Research Instruments Ltd RI IMSI ™ IMSI Monitor We recommend a monitor designed for medical imaging, and that the PC is fitted with a separate PCI-E graphics card with DVI (Digital Video Interface) output and at least 256MB memory. -
Page 33: Maintenance
Section 10 Research Instruments Ltd RI IMSI ™ Maintenance General The microscope must be maintained to a high standard. Problems such as worn focus mechanisms, dirt on optics, etc. may result in reduced image quality. It is essential that optical components are correctly adjusted to achieve the best image quality. -
Page 34: Troubleshooting
Section 10 Research Instruments Ltd RI IMSI ™ Troubleshooting Problem Possible Cause Solution Ensure USB cable is properly connected No video image Camera not connected and undamaged No video image Ensure the microscope‘s port selector is Port selector closed set to the appropriate position... - Page 35 Section 11 Research Instruments Ltd Appendices APPENDICES How to Select Cameras 1. Click on the tool bar. The Video Source drop down box will have a list of camera names referring to the cameras connected to the PC. 2. Click on the drop down box to allow the selection of cameras. Clicking on the required camera in the list will change the live image to that of the selected camera.
- Page 36 Section 11 Research Instruments Ltd Appendices How to Select Objectives 1. Click the magnification on the tool bar 2. Click the required objective magnification. How to Add Objectives 1. Click on the tool bar. 2. Click the Objective Calibration button.
- Page 37 Section 12 Research Instruments Ltd Saturn Laser Systems Care and Maintenance ™ SATURN™ LASER SYSTEMS CARE AND MAINTENANCE We recommend that a non PVC dust cover is placed over the microscope when not in use. Plasticisers commonly used in PVC are toxic to embryos.
-
Page 38: Returns Procedure
Section 13 Research Instruments Ltd Returns Procedure RETURNS PROCEDURE 1. Contact RI to obtain a Returned Materials Authorisation (RMA) number. Note goods will not be replaced or refunded without prior agreement and clearly stating the RMA number. 2. Pack the item carefully in its original packaging. RI will not accept responsibility for damage due to incorrect packaging.
