huem MS-SDL101-B-BK Manual

Smart door lock
Hide thumbs

Advertisement

Table of Contents

Smart Door Lock
1
Fingerprint
Password
Lock
Item Code
Material
MS-SDL101-B-BK
Zinc alloy
Dynamic
Operating
Current
Humidity
≤200 mA
20 ~ 93%RH
Card
Door Thickness
Power
Range
Supply
≧45mm
Opening
Mobile
Time
Phone App
Around 1.5
One
Seconds
administrator
Dimensions in mm
page 1 of 12
Bluetooth 4.2
Kep
Alarm
Voltage
4*AA
4.8V ±0.2V
APP send
password
Custom
password
Huem
-40ºC~70ºC
Static
Current
Kg
≤60µA
3.5
Custom
password
10 pcs

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS-SDL101-B-BK and is the answer not in the manual?

Questions and answers

Summary of Contents for huem MS-SDL101-B-BK

  • Page 1 Fingerprint Password Card Bluetooth 4.2 -40ºC~70ºC Lock Door Thickness Power Alarm Static Item Code Material Range Supply Voltage Current MS-SDL101-B-BK Zinc alloy 4*AA 4.8V ±0.2V ≤60µA ≧45mm Dynamic Operating Opening Mobile APP send Custom Current Humidity Time Phone App password password Around 1.5...

  • Page 2: Functions And Operations

    Format: Enter * # → administrator password → # → 83 → #After finishing the format, and voice says “please add Bluetooth administrator”, put your phone near the lock and open the Huem app, and click “Go to Add” button on your phone and then click “Next”...
  • Page 3 Functions & Operations 8. Change administrator password: Format: Enter * # → administrator password → # → 12 → # → new administrator password → # → new administrator password → # 9. Add user password: Format: Enter * # → administrator password → # → 85 → # → user password → # →...
  • Page 4 1. App Download Instructions and set steps Scan the QR code below and click “Download” (or go to Apple Store /Android Market to search “Huem” to download) the APP; Huem App Then click “...” → then click “Open with Browser” → and then click “Browser”...
  • Page 5 You can log in via email or mobile phone. (Country/region will follow phone system setting, or change country/region manually). After entering phone number or email, click “getting verification code”. Huem App Adding new Door Lock by app (Note: Keep your phone close to the lock during the process)After entering administrator code in the lock, and you will find the below left interface and click “Add”...
  • Page 6 2.Adding Permanent Users (Fingerprints/Password/Cards) in the app On the main interface click “ Family” and then click “Me Administrator” to enter the interface of adding users Adding the users of Fingerprints or Passwords or Cards, just click the “Add” to add Fingerprints or Passwords or Cards accordingly 3.Temporary Users On the main interface click “...

  • Page 7: Important Reminders

    UNLOCK/LOCK Unlock mode: Fingerprint, Password, Card, Phone App, Mechanical Key.) 1. To Unlock by Password/Fingerprint/Card/Phone Touch the screen to turn the keyboard light on, the keyboard light and status indicator blue light on, enter password followed by # key (Put your finger on the reader or scan the card directly or click the unlock icon on the phone), the door is unlocked, the status indicator light blinks green light and sound prompt.

  • Page 8: Installation And Adjustment

    INSTALLATION AND ADJUSTMENT 1. Installation Condition 2. Installation Assembly 3. Installation Steps 1) Drill a hole of 54mm diameter on the door from the door edge 57mm; page 8 of 12...
  • Page 9 2～3) Put the cable of the front panel through the door to inside and hold the front panel on the door; 4) Put the cable through the square hole of mounting plate then fix the mounting plate and the front panel with 3 screws(G) 5～6) Insert the plug of front panel into the socket on the PCB of the rear panel;...

  • Page 10: After-Sale Service

    Maintenance a. The lock surface is prohibited contact with the corrosive substances to avoid to damage the prevention layer of the lock and affect the products life; b. Kindly recommend to install the lock after room decoration. That will avoid the lock surface be damaged; c.Always keep the rotating part with lubricant, it will help the lock working smoothly and extend the service life.
  • Page 11 Appendix 1. Packing List 2. Installation Tools page 11 of 12...

  • Page 12: App Download

    App Download Download Huem App 1. Search the App “Huem“ from Apple Store or Google Play. 2. Scan the QR code from the label or user manual. Android iOS 10.0 The App is compatible with Android 5.0 and iOS 10.0 and higher version.
