DOCUMENT NO:
117038-ICS-PD-UMN-0001
USER MANUAL
SUBSEA CAMERA TONGA
PUBLISHED
REVISION
15.01.2024
B
20.01.2021
A
PREPARED
Vidar Haus
Ixys AS
Langmyra 11, 4344 Bryne, Norway
post@ixys.no, www.ixys.no
Org.nr: 913 498 194
+47 514 22 222
DATE:
15.01.2024
REVISION NOTE
Updated with new web interface
Released
CHECKED
Sven Hatteland
PREPARED BY:
Vidar Haus
APPROVED
Ole Morten Haaland
Advertisement
Table of Contents
Summary of Contents for IXYS 117038
- Page 1 DOCUMENT NO: DATE: PREPARED BY: 117038-ICS-PD-UMN-0001 15.01.2024 Vidar Haus USER MANUAL SUBSEA CAMERA TONGA PUBLISHED REVISION REVISION NOTE 15.01.2024 Updated with new web interface 20.01.2021 Released PREPARED CHECKED APPROVED Vidar Haus Sven Hatteland Ole Morten Haaland Ixys AS Langmyra 11, 4344 Bryne, Norway post@ixys.no, www.ixys.no...
-
Page 2: Table Of Contents
PAGE 2 OF 12 USER MANUAL 117038-ICS-PD-UMN-0001 REVB SUBSEA CAMERA TONGA CONTENTS 1. INTRODUCTION ....................3 1.1....................3 PURPOSE AND SCOPE 1.2....................... 3 ABBREVIATIONS 1.3................3 SUPPLIER CONTACT INFORMATION 1.4..................3 DOCUMENT REFERENCES 2. HEALTH, SAFETY AND ENVIRONMENT ............4 2.1. -
Page 3: Introduction
PAGE 3 OF 12 USER MANUAL 117038-ICS-PD-UMN-0001 REVB SUBSEA CAMERA TONGA 1. INTRODUCTION 1.1. PURPOSE AND SCOPE This document outlines and defines the configuration and operation of the Subsea Camera Tonga. The manual is to be used by trained and competent personnel only. -
Page 4: Health, Safety And Environment
PAGE 4 OF 12 USER MANUAL 117038-ICS-PD-UMN-0001 REVB SUBSEA CAMERA TONGA 2. HEALTH, SAFETY AND ENVIRONMENT 2.1. GENERAL Safety Notes and General Precautions shall be presented to all personnel concerned prior to testing, operation, maintenance, and repair. The operations shall be performed by the responsible engineer/supervisor. -
Page 5: Technical Information And Data
The Subsea Camera Tonga is designed to be used subsea down to 4000 m. It sends a live video feed via Ethernet. 3.2. TECHNICAL DATA General Manufacturer Ixys AS Ixys Part Number 117038 Description Subsea Camera Tonga Weight in air... -
Page 6: Drawing
PAGE 6 OF 12 USER MANUAL 117038-ICS-PD-UMN-0001 REVB SUBSEA CAMERA TONGA 4. DRAWING Ixys AS Langmyra 11, 4344 Bryne, Norway post@ixys.no, www.ixys.no Org.nr: 913 498 194 +47 514 22 222... -
Page 7: Configuration And Operation
PAGE 7 OF 12 USER MANUAL 117038-ICS-PD-UMN-0001 REVB SUBSEA CAMERA TONGA 5. CONFIGURATION AND OPERATION 5.1. MAIN PAGE The camera can be configured through a built-in web interface by opening the IP address of the camera in a browser (default http://10.13.37.243), This interface allows changing the camera's video stream, network, and image settings. -
Page 8: About Page
PAGE 8 OF 12 USER MANUAL 117038-ICS-PD-UMN-0001 REVB SUBSEA CAMERA TONGA 5.2. ABOUT PAGE Figure 2 – About web interface page The About page shows the current firmware version, and allows uploading new versions, performing a factory reset and reboot of the camera. -
Page 9: Api
PAGE 9 OF 12 USER MANUAL 117038-ICS-PD-UMN-0001 REVB SUBSEA CAMERA TONGA 5.3. API The screenshot below shows the commands available through the API. The web interface includes a full documentation interface on the /swagger URI (default http://10.13.37.243/swagger/). Ixys AS Langmyra 11, 4344 Bryne, Norway post@ixys.no, www.ixys.no... -
Page 10: View Rtp Udp Stream In Vlc Player
PAGE 10 OF 12 USER MANUAL 117038-ICS-PD-UMN-0001 REVB SUBSEA CAMERA TONGA 5.4. VIEW RTP UDP STREAM IN VLC PLAYER To view RTP UDP stream in VLC Player with default settings, make a .sdp file with the following content: Open the file with VLC Player. - Page 11 PAGE 11 OF 12 USER MANUAL 117038-ICS-PD-UMN-0001 REVB SUBSEA CAMERA TONGA Ixys AS Langmyra 11, 4344 Bryne, Norway post@ixys.no, www.ixys.no Org.nr: 913 498 194 +47 514 22 222...
-
Page 12: Heartbeat
PAGE 12 OF 12 USER MANUAL 117038-ICS-PD-UMN-0001 REVB SUBSEA CAMERA TONGA 5.5. HEARTBEAT Heartbeat messages are sent once per second as UDP packets to IP 255.255.255.255 port 65000. These messages can be detected to find IP address of the camera if it’s not known.
