Summary of Contents for EVOS Fleet22
- Page 1 Fleet22 - Installation Manual Australia Page 1/1 EVOS Fleet22 Installation Manual - Australia...
-
Page 2: Table Of Contents
5. Connect QUICKON Connector to the charger 6. Connect Charging Cable 7. Register and configure (mandatory) 8. Install Shield 9. Power ON 10. Electrical Tests 11. Test Charge USING FLEET22 CHARGER STATUS INFORMATION WI-FI SETUP PROCESS (OPTIONAL FOR FLEET22) CHECKLIST... -
Page 3: Qualifications
Page 3/17 Qualifications The EVOS Fleet22 is designed to only be connected to a dedicated AC supply. The EVOS Fleet22 requires only Type A RCD + MCB upstream protection. The use of adapters or conversion adapters are not permitted with EVOS Fleet22. -
Page 4: Product Specification
Fleet22 - Installation Manual Australia Page 4/17 Product Specification Communication Charging Mode Protocol OCPP 1.6 Wired Ethernet 10/100Mbit Wi-Fi: 2.4GHz IEEE 802.11.b/g/n Wireless Bluetooth: 4.1 Optional: LTE CAT-M1 Compliance Certification CE Certified, CB Certification Protection Class IEC 61851-1, IEC 61851-21-2... -
Page 5: Installation Preparation
+ M3 Security Bit Power Input Cable - Terminated QUICKON Connector Charger Adoption Key Supply Wiring - Input Connector One of two options may be provided with the Fleet22. OPTION A. Phoenix QUICKON Nut Conductor Size 2.5mm² ... 6mm² Typical installation will use a 6mm² 4C+E heavy duty flex cable. -
Page 6: Electrical Safety
Fleet22 - Installation Manual Australia Page 6/17 Installation Preparation Audience This document is intended for consumption by licenced electricians. Electrical Safety Upstream protection must be installed for safe operation. 1. Only type A RCD (as per AS3000) Recommended 30mA Type A 1 Phase Installation 2. -
Page 7: Installation
Fleet22 - Installation Manual Australia Page 7/17 Typical Installation Example Installation Tools 1 x Power Drill 1 x M4 Drill Bit 1 x Phillips Head Screw Bit 1 x 3mm Post Hex Security Bit 1 x Standard Electrical Test Equipment... -
Page 8: Component Guide
Fleet22 - Installation Manual Australia Page 8/17 Component Guide Charging Cable with Type 1 Plug Charging Cable with Type 2 Plug Installation Steps Please check off the items on the checklist located on the last page of this document. 1. Remove shield from station (if secured). -
Page 9: Mark Fixing Point
Fleet22 - Installation Manual Australia Page 9/17 (1) Slide the shield away from the base. Place the shield face up where it will not be marked, scratched or damaged. 2. Mark fixing point Use a level across the top of the base... -
Page 10: Option B - Terminated Quickon Connector With 1M Cable
Fleet22 - Installation Manual Australia Page 10/17 Confirm wiring conductor size is within limits of the QUICKON Nut specifications. Fix wires in conductor supports of the splice body corresponding with the L1, L2, L3, N and PE designation. Cut off excess wire flush to slice... -
Page 11: Register And Configure (Mandatory)
The station output connector has dangerous voltages present when a vehicle is charging. 7. Register and configure (Mandatory) Connect to the EVOS App using your mobile phone, scan the QR code on the base and register the station. If the QR code does not work, enter this URL into a browser. - Page 12 If you have an installer account, please sign in, otherwise register an account. Sign In Enter your username and password, then click “Sign In” (1) to access the EVOS App. Register Click “Register” (2) to create a login for the EVOS App as an Installer.
-
Page 13: Install Shield
Fleet22 - Installation Manual Australia Page 13/17 8. Install Shield Align the shield with the docking port facing the right-hand side. Slide the shield over the four locating edges of the station base. Shield should gently slide until flush. Use the 4 x M5 fasteners saved... -
Page 14: Using Fleet22
4. Check the charging cable for damage and the plug for damage or contamination. 5. Insert the plug into the vehicle inlet. Check the plug is fully inserted. 7. Start of charging session, check EVOS Fleet22 status LED is Blue. (Charger Status Information in the next page.) 8. -
Page 15: Charger Status Information
Fleet22 - Installation Manual Australia Page 15/17 Charger Status Information The LEDs on the EVOS Fleet22 convey the state of the station as listed below. -
Page 16: Wi-Fi Setup Process (Optional For Fleet22)
Step 4: Select your network Step 5: Set-up Wi-Fi Network Connecting 3) Your Fleet22 is now connected to Wi-Fi and you can unlock all its capabilities. Step 5: Success page If your charger didn’t connect successfully to the Wi-Fi, the App will show this alert, also the charger will blink with a white and cyan light. -
Page 17: Checklist
Fleet22 - Installation Manual Australia Page 17/17 EVOS Support If you require support during your installation, we’re happy to help. Please call +61 7 3543 0064. For general email enquiries, sayhi@evos.com.au Checklist Please use this checklist to ensure the station has been installed safely.
