- Page 1 DJI DRONE MicroUSB EXTENSION CABLE Installation instructions English (en-US) Date: 10-2020 Document number: 87398-3 © 2020 Raymarine UK Limited...
- Page 3 Please check the website to ensure you have the latest documentation. Publication copyright Copyright ©2020 Raymarine UK Ltd. All rights reserved. No parts of this material may be copied, translated, or transmitted (in any medium) without the prior written permission of Raymarine UK Ltd.
-
Page 5: Table Of Contents
Contents Chapter 1 Important information..................7 Water ingress ..........................7 Disclaimer ............................7 EMC installation guidelines ...................... 8 Declaration of Conformity......................8 Product disposal ........................8 Warranty registration ......................... 9 IMO and SOLAS ......................... 9 Technical accuracy ........................9 Chapter 2 Product and system overview...............11 2.1 Document information ...................... - Page 6 Chapter 9 Maintenance ....................31 9.1 Service and maintenance....................32 9.2 Routine equipment checks ....................32 Chapter 10 Technical support..................33 10.1 Raymarine product support and servicing ..............34 10.2 Learning resources......................35 Chapter 11 Technical specification................37 11.1 Technical specification...................... 38...
-
Page 7: Chapter 1: Important Information
Raymarine. Raymarine is not responsible for damages or injuries caused by your use or inability to use the product, by the interaction of the product with products manufactured by others, or by errors in information utilized by the product supplied by third parties. -
Page 8: Emc Installation Guidelines
EMC performance throughout the installation. Declaration of Conformity FLIR Belgium BVBA declares that the DJI Drone Extension Cable, part number A80630, is in compliance with the EMC Directive 2014/30/EU. The original Declaration of Conformity certificate may be viewed on the relevant product page at www.raymarine.com/manuals. -
Page 9: Warranty Registration
In addition, our policy of continuous product improvement may change specifications without notice. As a result, Raymarine cannot accept liability for any differences between the product and this document. Please check the Raymarine website (www.raymarine.com) to ensure you have the most up-to-date version(s) of the documentation for your product. -
Page 11: Chapter 2: Product And System Overview
Chapter 2: Product and system overview Chapter contents • 2.1 Document information on page 12 • 2.2 Applicable products on page 12 • 2.3 Product overview on page 12 Product and system overview... -
Page 12: Document Information
• install and connect your product as part of a wider system of connected marine electronics; • troubleshoot problems and obtain technical support if required. This and other Raymarine product documents are available to download in PDF format from www.raymarine.com/manuals. -
Page 13: Compatible Uavs
5. Captive 1 m (3.28 ft) USB cable — connects to the Accessory port on an Axiom MFD. 6. Axiom MFD The DJI Drone Extension Cable has a waterproof rating of IPx6 / IPx7 (with the lid closed). Compatible UAVs Currently the UAVs listed below are supported: •... -
Page 15: Chapter 3: Parts Supplied
Chapter 3: Parts supplied Chapter contents • 3.1 Parts supplied on page 16 Parts supplied... -
Page 16: Parts Supplied
3.1 Parts supplied The parts supplied with this product. 1x DJI Drone Extension Cable (consists of Micro USB port extender, with a 1 m (3.28 ft) Micro USB captive cable). 2. 1x Foam gasket. 3. 1x Lock ring. -
Page 17: Chapter 4: Product Dimensions
Chapter 4: Product dimensions Chapter contents • 4.1 Product dimensions on page 18 Product dimensions... -
Page 18: Product Dimensions
4.1 Product dimensions * 29 mm (1.14 in) diameter cut-out hole required. -
Page 19: Chapter 5: Location Requirements
Chapter 5: Location requirements Chapter contents • 5.1 Switch off power supply on page 20 • 5.2 Potential ignition source on page 20 • 5.3 Location requirements on page 20 • 5.4 EMC installation guidelines on page 20 Location requirements... -
Page 20: Switch Off Power Supply
This product is NOT waterproof when the lid is open. 5.4 EMC installation guidelines Raymarine equipment and accessories conform to the appropriate Electromagnetic Compatibility (EMC) regulations, to minimize electromagnetic interference between equipment and minimize the effect such interference could have on the performance of your system Correct installation is required to ensure that EMC performance is not compromised. -
Page 21: Chapter 6: Installation
Chapter 6: Installation Chapter contents • 6.1 Flush mounting on page 22 • 6.2 Surface mounting on page 23 Installation... -
Page 22: Flush Mounting
Important: For CNC machining CAD data is available on the Raymarine website. 7. Ensure that the unit fits into the removed area and then remove rough edges. 8. Attach the gasket to the rear of the reader. -
Page 23: Surface Mounting
6.2 Surface mounting When surface mounted the product protrudes slightly from the mounting surface, usually by the thickness of the bezel. 1. Check the selected location for the unit. A clear, flat area with suitable clearance behind the panel is required. 2. -
Page 25: Chapter 7: Connections
Chapter 7: Connections Chapter contents • 7.1 General cabling guidance on page 26 • 7.2 Connections overview on page 27 • 7.3 Do NOT connect generic USB devices on page 27 Connections... -
Page 26: General Cabling Guidance
• Unless otherwise stated only use cables supplied by Raymarine. • Where it is necessary to use non-Raymarine cables, ensure that they are of correct quality and gauge for their intended purpose. (e.g.: longer power cable runs may require larger wire gauges to minimize voltage drop along the run). -
Page 27: Connections Overview
7.2 Connections overview Your DJI Drone Extension Cable connects to the Micro USB Accessory port located at the rear of your Axiom MFD. Compatible drone (UAV) controller — connects to the USB port extender via the controller’s Micro USB cable (not supplied). 2. -
Page 29: Chapter 8: Operation
Chapter 8: Operation Chapter contents • 8.1 Inserting the drone controller cable into the port extender on page 30 • 8.2 Do NOT connect generic USB devices on page 30 Operation... -
Page 30: Inserting The Drone Controller Cable Into The Port Extender
8.1 Inserting the drone controller cable into the port extender To correctly insert the Drone controller’s Micro USB cable into the port: 1. Press the tab in and pull the lid open to expose the extender’s Micro USB port. 2. Orient the Micro USB plug the correct way up and then gently insert it into the Micro USB port. 3. -
Page 31: Chapter 9: Maintenance
Chapter 9: Maintenance Chapter contents • 9.1 Service and maintenance on page 32 • 9.2 Routine equipment checks on page 32 Maintenance... -
Page 32: Service And Maintenance
9.1 Service and maintenance This product contains no user serviceable components. Please refer all maintenance and repair to authorized Raymarine dealers. Unauthorized repair may affect your warranty. 9.2 Routine equipment checks It is recommended that you perform the following routine checks, on a regular basis, to ensure the correct and reliable operation of your equipment: •... -
Page 33: Chapter 10: Technical Support
Chapter 10: Technical support Chapter contents • 10.1 Raymarine product support and servicing on page 34 • 10.2 Learning resources on page 35 Technical support... -
Page 34: Raymarine Product Support And Servicing
You can obtain this product information using diagnostic pages of the connected MFD. Servicing and warranty Raymarine offers dedicated service departments for warranty, service, and repairs. Don’t forget to visit the Raymarine website to register your product for extended warranty benefits: http://www.raymarine.co.uk/display/?id=788. United Kingdom (UK), EMEA, and Asia Pacific: •... -
Page 35: Learning Resources
Russia (Authorized Raymarine distributor): • E-Mail: info@mikstmarine.ru • Tel: +7 495 788 0508 10.2 Learning resources Raymarine has produced a range of learning resources to help you get the most out of your products. Video tutorials Raymarine official channel on YouTube: • YouTube LightHouse™... -
Page 37: Chapter 11: Technical Specification
Chapter 11: Technical specification Chapter contents • 11.1 Technical specification on page 38 • 11.2 Compliance on page 38 Technical specification... -
Page 38: Technical Specification
11.1 Technical specification Environmental specification -25 ºC to +55 ºC (-13 ºF to 131 ºF) Operating temperature Storage temperature -30 ºC to +70 ºC (-22 ºF to 158 ºF) Relative humidity Maximum 93% Waterproof rating IPx6 & IPx7 (lid closed) Power Power consumption 5 V dc... - Page 41 Index Servicing..............32 Support forum ............35 Surface mounting ............23 Cable Bend radius............26 Protection ............26 Technical specification ........37–38 Routing ..............26 Technical support..........34–35 Security ..............26 Temperature range ..........38 Strain relief............26 Training courses ............35 Compatible MFDs.............13 Connections ............27 General cabling guidance........26 Connectors, Connections Contact details............
- Page 44 Raymarine Marine House, Cartwright Drive, Fareham, Hampshire. PO15 5RJ. United Kingdom. Tel: +44 (0)1329 246 700 www.raymarine.com a brand by...
