- Page 1 Quick guide Easyzone...
-
Page 3: Table Of Contents
Power supply to the system ................10 Reset the system........................10 Change of battery .......................10 Checking the Installation ......................11 Initial Configuration ........................12 Airzone Blueface ........................12 Airzone Think ..........................13 Airzone Lite ..........................15 Checking the initial configuration ................16 System reset ..........................16 Zone reset ..........................16 Airflow Regulation ........................17... -
Page 4: Environmental Policy
Violations are subject to the penalties and measures stipulated in environmental protection law. Access all our technical documents and the self-diagnosis section, check the most FAQs, certificates and watch our videos at: myzone.airzone.es/products/ Access our declaration of conformity at: http://doc.airzone.es/ produc to/Gama_ AZ6 /Airzon e/Cer tif ica dos/Declaration_of_ conformity_AZ6.pdf... -
Page 5: Before Starting
2x0.5 mm wires for power supply). • A Blueface thermostat must be used to enable all the Airzone system functionalities. • Recommendations for the placing of the thermostats: • For equipment using R32 refrigerant, verify the compliance with the local refrigerant regulation. -
Page 6: System Installation
System Installation EASYZONE PLENUM ASSEMBLY Assembly in the indoor unit It is recommended to insulate all metal parts of the Easyzone that remain in contact with the outside to prevent condensation. Locate the drilling holes; if they are covered, use a screwdriver to uncover them to fix the Easyzone to the unit. -
Page 7: Fresh Air Intake (Cmv) Assembly
Remember that the motorized elements are numbered in the following manner: Connect duct from each zone corresponding damper. Follow the instructions for proper insulation. Make a cut in the duct to keep the motor outside. Fresh air intake (CMV) assembly If your Easyzone has CMV and you wish to use this function. -
Page 8: Additional Easyzone Information
ADDITIONAL EASYZONE INFORMATION Bypass damper assembly With a sharp blow, remove the pre-cut area Using a utility knife, remove the insulation on the sides corresponding to the bypass. covering the bypass area and uncover the bypass fixing slots. Fit the bypass damper into the slots and Fix the bypass damper to the plenum turn from left to right until it reaches the using a sheet metal screw (Ø: 3.9 mm). -
Page 9: Motorized Plenum With Blind Cover
8 will not be connected. SISTEM ASSEMBLY Innobus Pro6 Main Control Board (AZCE6IBPRO6) Description Airzone connection bus Wireless module Automation bus AC unit bus Actuator outputs Alarm input (normally close) -
Page 10: Thermostat Installation
Disconnect the power supply of the Daikin indoor unit and the Airzone system. Find the P1 P2 connection of the Daikin indoor unit (where the thermostat is connected). Connect the Airzone Gateway to the P1 P2 port of the Daikin unit using the cable supplied by Airzone. -
Page 11: Other Peripherals
Other peripherals Follow the instructions on their technical data sheet. Important: For elements with external power supply at 110/230 VAC, it is only necessary to connect poles "A" and "B" of the bus for communications. Power supply to the system Use power supply input to power the main control board at 110/230 ... -
Page 12: Checking The Installation
Checking the Installation Check the following items: Status of the main control board LEDs and of the other control elements connected. Consult the Self-diagnostics section on each element's technical fact sheet. The main control board LEDs indicating the opening of motorized elements light up in sequence. -
Page 13: Initial Configuration
Initial Configuration AIRZONE BLUEFACE Languages: Select the zone associated to The system allows you to • Spanish this thermostat. Each zone associate more than one • English has a corresponding control control output to a zone • French output (actuator output or if needed. -
Page 14: Airzone Think
AIRZONE THINK Wireless Think Open wireless association channel. To do so, click SW1. Once opened, have minutes perform the association. You can also open the wireless IMPORTANT: Remember Languages: association channel through not to have more than one • Spanish the Blueface thermostats. - Page 15 The system allows you to associate more than one control Master: Allows the control of output to a zone if needed. It is therefore possible to manage all installation parameters. several control outputs from a single thermostat. Zone: Only allows the control of the zone parameters.
-
Page 16: Airzone Lite
If you want to configure other thermostat settings must access zone advanced settings menu from an Airzone Blueface thermostat. The icon will blink 5 times in green to indicate that the association is correct. If the icon blinks once in red, this indicates... -
Page 17: Checking The Initial Configuration
AC unit-system communication: Set the Airzone system to Stop mode and verify that the AC unit turns off and dampers open. Opening/closing of the dampers and control outputs: Turn on and generate demand in all the zones. -
Page 18: Airflow Regulation
Airflow Regulation Important: Start the airflow adjustment from the central dampers and finalize at damper no. 1. AIRFLOW ADJUSTMENT (REG) Turn on and generate demand in all the zones to open all the dampers. Turn off the zone/damper to be adjusted. Adjust the desired maximum opening with the REG lever (I/II/III/IV). -
Page 19: System Advanced Settings
System Advanced Settings AIRZONE BLUEFACE Press and hold AIRZONE THINK Press and Press and hold hold... -
Page 20: System Parameters
- Webserver: firmware, IP address, gateway, MAC and PIN. • Reset system. (Only available for Airzone Blueface master thermostats). This allows you to reset the system by returning it to factory settings. To reconfigure the thermostats, go to the Initial configuration section. -
Page 21: Zone Parameters
ZONE PARAMETERS Note: Some parameters may vary depending on your system. • Associated outputs. This displays and allows you to select the control outputs associated to the thermostat. • Thermostat settings. This allows you to set up a thermostat as Master or Zone. *Note: It cannot be configured as Master if there is already another thermostat configured as such. -
Page 22: Self-Diagnose
Self-Diagnose INNOBUS PRO6 MAIN CONTROL BOARD (AZCE6IBPRO6) Nº Meaning Data reception from automation bus Blinking Green Data transmission from automation bus Blinking Main control board activity Blinking Green Data transmission from connection bus Blinking Data reception from connection bus Blinking Green AC unit On/Off Switches... -
Page 23: Innobus Pro6 Main Control Board (Azce6Ibpro6)
Data transmission to the indoor unit Error 11 Data reception from the indoor unit WIRELESS LITE THERMOSTAT (AZCE6LITER) In the case of Airzone Lite thermostats, if the On/Off icon blinks rapidly in red, it means communication with the main control board has been lost. - Page 25 airzonecontrol.com Marie Curie, 21 29590 Málaga Spain V 200...
