D-Link CM269IRICR-1K User Manual

Specification
CM269IRICR-1K
Model
SNY
Pick up Element 1/3" 1.3 Megapixel Sensor
Effective Picture Elements
1305(H) X1049(V)
(H×V)
Resolution 1000TVL
0.01 Lux/F1.2
Minimum Illumination
0 Lux (with IR LED ON)
More than 50dB
S/N Ratio
Scanning System Progressive
Internal, Negative sync.
Synchronous System
Auto Electronic Shutter NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
Gama Characteristic 0.45
40 Meters (with ￠5X36 PCS Infrared LED)
IR Distance
Video Output 1Vpp, 75Ω
Auto
Auto Gain Control
DC12V(+/-10%)/500mA
Power/Current
Lens 2.5-10mm（2.0 Megapixel）Manual Zoom Lens
￠131x 93(H)
Dimension (mm)
800
Weight (g)
Storage Temperature -30~+60℃ RH95% MAX
Operating Temperature -10~+50℃ RH95% MAX
Packing List
No
Name
1.
Bullet IR ICR Color Camera CM269IRICR-1K
2.
CM269IRICR-1K
User Guide
Franchiser：
Model Number
1
1
CM269IRICR-1K
Color Camera
Easily Adjustable Bullet IR ICR
Color Camera
Notes:
Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
