Sophos XGS 4500 Mounting Instructions

Power Supply Module Mounting Instructions
Please note: The secondary power supply can be installed with the primary power supply still being
active. Hence you don't need to remove the power cord from the primary power supply nor shut down
the appliance. This is only needed if you want to remove/replace an already installed power supply.
Step 1
Lose the screw and remove the blank plate
covering the slot for the redundant power supply.
Step 2
Insert the redundant power supply module into
the slot and lock it.
Step 3
Plug a power cord into the new module. Check
that the LED on each module is green. If one LED
is red then the module is either defective or not
connected properly.
*
