Groz LED-660 Instruction Manual

Sitelamp 360 swivel

Advertisement

Quick Links

Sitelamp
360° Swivel
5 HRS
3000
at lowest intensity
Multi-mode super bright 36W 72 SMD site lamp
Light Output
Single button controlled high quality output in
multiple modes
INTENSITY
HIGH
MEDIUM
LUMEN
3000
RUN TIME
1.5 hours
2.5 hours
Sturdy Construction
a. IP65 Rated
Protected against dust and effects of low
pressure water jets from any direction
b. Corrosion resistant aluminium die cast
construction in premium powder coated
finish
c. Impact proof ABS frame
d. Tempered glass lens
e. Steel handle with foam grip
f. Sturdy steel stand for balanced positioning
in the toughest of job site conditions
Swivel & tilt design
Patented 360° swivel & tilt mechanism. Ball joint
mechanism allows
a. Swivelling of light full 360°
b. Tilt
Charging of Battery
Battery can be recharged using dual voltage
(110V-240V) AC adaptor
Charge Your Phone
Rechargeable battery pack also doubles as a
power bank
POWER SOURCE
Li-Ion
7.4V 4400 mAh
CAT
NR.
(INCH)
LED/660
8.7 × 8.7 × 12.2
4.5 HRS
45M / 150'
LOW
1500
750
5 hours
SIZE (L×H×D)
(MM)
223 × 223 × 309
INSTRUCTION MANUAL
120˚
Tilt & swivel to 360°
SCAN TO
S3020, REV B
LED-660
RoHs
3 LED battery level
indicator
H
D
WATCH
IP65
360°
Rotation
L

Advertisement

loading
Need help?

Need help?

Do you have a question about the LED-660 and is the answer not in the manual?

Questions and answers

Summary of Contents for Groz LED-660

  • Page 1 INSTRUCTION MANUAL S3020, REV B Sitelamp LED-660 360° Swivel RoHs 5 HRS IP65 4.5 HRS 3000 45M / 150' 120˚ at lowest intensity Multi-mode super bright 36W 72 SMD site lamp Light Output Single button controlled high quality output in...
  • Page 2 SAFETY INFORMATION INSTALLATION • Follow workshop health & safety rules, (Refer “EXPLODED VIEW”) regulations and conditions when using the 1. Place the site lamp on a plane surface and rechargeable site lamp. open the charging socket cover (11) located on •...
  • Page 3 EXPLODED VIEW PART LIST REF NO. DESCRIPTION QTY. REF NO. DESCRIPTION QTY. Front housing 7.4v (4400 mAh) battery pack Battery cover Tempered glass Indicator support Sealing ring Plastic Reflector "X" stand 72 LED PCB Rubber cap Mains housing Bottom Ball solid board Handle Rotating support Switch...
  • Page 4 Groz Engineering Tools Pvt. Ltd. Groz Net Industries Village Kherki Daula, National Highway-8, Gurugram-122001, Haryana, INDIA +91.124.282.7700 E-Mail info@groz-tools.com www.groz-tools.com The GROZ name, GROZ logo and the mark are trademarks of GROZ Engineering Tools Pvt. Ltd., India...
