Installation Procedure:
CAUTION. Read this note before proceeding
1. Avoid using large amount of pipe putty on pipe joints. Putty is damaging to all automatic flush
valves.
2. After installing stop valve and prior to installing flush valve, purge stop valve at high pressure
for one minute, (purge into a bucket if available). Purging valve in this way will remove particles
that would otherwise find their way into the flush valve causing immediate damage.
NOTE: Do not use sharp
tools, that can cause damage
to the finish on the flush
valves
Please remember the following: Valves are shipped with batteries pre-installed and a cover over the sensor
eye. When necessary to remove batteries never attempt to remove batteries by pulling hard on battery wire.
1. Place tube sleeve over supply bib that is
present in the wall.
2. Slide supply flange over tube sleeve, press
against wall. Using Allen wrench fasten supply
flange to tube sleeve.
3. Using plumber's putty, fasten stop to pipe bib.
4. Mount spud coupling (spud flange, rubber
washer, thrust washer, spud nut) to urinal or
toilet spud. Keep spud nut loose in preparation
for step 5.
5. Install flush connection to spud coupling by
inserting connection through spud nut. Tighten
spud nut
6. Insert vacuum breaker into flush connection as
shown in drawing.
7. Run water through stop valve at high volume
for 1-2 minutes in order to clear dirt and
debris out of pipes prior to installing flush
valve. Use a container to capture running
water.
User Manual
Models AUV-2 and ATV-2
8. Place flush valve on top of flush connection,
mate valve body with stop valve.
9. Hand tightens both connection nut and stop nut
a few turns each at a time. This will ensure that
the nuts are threaded properly to their
prospective male counter parts. (Do not cross
thread).
10. Place heavy cloth over nuts in order to protect
the finish and tighten using wrench.
11. Loosen the Allen anchors using supplied
wrench (1 or 2 turns), align sensor window so it
is facing forward and looking over toilet or
urinal. Tighten Allen screw (Do not
over-tighten).
12. Turn water on and check for leaks.
13. Water flow rate is adjusted with flow adjuster
screw within stop valve.
14. For urinal application turn water flow rate (DE
method).
15. Remove cover that covers sensor window in
order to begin operation.
PAGE | 01
