MODEL 600023A
ADJUSTABLE DISSECTING
TABLE
CAUTION
• Inspect unit and all components
for any loosening that may have
occurred during shipping •
ATTENTION
Review entire manual before
starting assembly
Mortech™ Manufacturing Inc.
411 North Aerojet Avenue, Azusa, CA 91702
(626) 334-1471 www.mortechmfg.com
™
Technical Users' Manual
Installation and Operating Instructions
ISO Doc. #OM600023A (REV B)
JULY 2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 600023A and is the answer not in the manual?

Questions and answers

Summary of Contents for MORTECH 600023A

  • Page 1 ™ Technical Users’ Manual Installation and Operating Instructions MODEL 600023A ADJUSTABLE DISSECTING TABLE CAUTION • Inspect unit and all components for any loosening that may have occurred during shipping • ATTENTION Review entire manual before starting assembly JULY 2010 Mortech™ Manufacturing Inc.

  • Page 2: Safety Information

    • Do the moving parts operate smoothly? Modifying the equipment can cause injury and damage. • Is unit draining properly? Use the equipment only as designed by Mortech. • Are all nuts, bolts, and pins secured in place? If unit has an issue contact customer relations.

  • Page 3: Parts Listing

    600023-A Adjustable Dissection Table Parts listing SLOPED FOR DRAINAGE ADJUSTABLE FRONT AND REAR LEGS OPTIONAL ACCESSORY HOLDER (4) LIQUID DRAIN HOLE REMOVABLE UTILITY SHELF SIMPLY LIFT TO REMOVE (4) 6 INCH CASTER w/BRAKE LIQUID DRAIN HOLE ALLOWS FLUID TO DRAIN AFTER CLEANING All measurements in inches MODEL 600023-A...
  • Page 4 Parts listing 600023-A Adjustable Dissection Table REMOVAL OF LOWER SHELF STAINLESS STEEL SHELF IS REMOVED BY LIFTING UPWARDS ON BOTH ENDS SIMULTANEOUSLY Stainless steel shelf is optional. Your order may or may not include a removable shelf. JULY 2010 MFGISO Doc. #OM600023A (Rev. B)
  • Page 5 600023-A Adjustable Dissection Table Parts listing ADJUSTING THE MODEL 600023-A When adjusting the cart, grasp the adjustable locking pin (as seen below) and pull outward. Pull upward on the adjustable • Height adjustment should be done without cadaver leg to the desired height, then replace the pin to secure on table.
  • Page 6 Parts listing 600023-A Adjustable Dissection Table STAINLESS STEEL INSTRUMENT TRAY Stainless steel instrument tray can be provided as an optional feature on any of our dissection tables. Units are fabricated entirely of stainless steel. They feature a locking knob at the pole base and at the rear of the instrument tray which allows the pole to be locked in a variety of positions.
  • Page 7 LEG SUPPORT BLOCK ADJUST TO HEIGHT DESIRED AND LOCK IN PLACE KNOB LOCK 600023-A Adjustable Dissection Table Parts listing STAINLESS STEEL BOOKSTAND Stainless steel bookstands can be provided as an optional feature on any of our dissection tables. Units are fabricated entirely of stainless steel.
  • Page 8 Parts listing 600023-A Adjustable Dissection Table STAINLESS STEEL LEG SUPPORTS Stainless Steel Leg Supports Stainless steel leg supports can be provided as an optional feature on any of our dissection tables. Units are fabricated entirely of stainless steel. The “U” shaped leg support can be swiveled.
  • Page 9 600023-A Adjustable Dissection Table Parts listing STAINLESS STEEL DRAIN PAIL Stainless steel pails can be provided to accept table drainage. All tables come equipped with some mounting area for the pails. Mounting types include: lower shelves, hook on underside of table or drop-in-pail holders. Type of table will determine which type of holder can be used.

  • Page 10: Component Data

    Debris in this area will cause the wheel to not function properly. METRIC CAP M8 X 1.25 X 50L Brake Lock METRIC NYLOC NUT TIGHTEN AND SECURE Brake Lock Release Mortech™ Manufacturing Inc. 411 North Aerojet Avenue, Azusa, CA 91702 (626) 334-1471 www.mortechmfg.com...

  • Page 11: Maintenance Instructions

    600023-A Adjustable Dissection Table Maintenance MAINTENANCE INSTRUCTIONS Shop Oil and Grease - These soils may be corrosive and may not allow the surface to maintain passivity, and so MAINTENANCE SCHEDULE removal is a necessity. Soap or detergent and water may be The unit requires regular maintenance and follow the used or a combination of detergent and water plus a solvent.

  • Page 12: Maintenance Record

    Maintenance record 600023-A Adjustable Dissection Table MAINTENANCE RECORD Date JULY 2010 MFGISO Doc. #OM600023A (Rev. B)

  • Page 13: Training Record

    600023-A Adjustable Dissection Table Training record TRAINING RECORD Date JULY 2010 MFGISO Doc. #OM600023A (Rev. B)

  • Page 14: Warranty

    Customer Relations. FAX (626) 334-1704 www.mortechmfg.com PROPRIETARY NOTICE info@mortechmfg.com The information in this manual is the property of Mortech © COPYRIGHT MORTECH MANUFACTURING INC., ALL Manufacturing. Mortech Manufacturing reserves all patent RIGHTS RESERVED. rights, proprietary design rights, manufacturing rights,...
