Smappee

Pay Station

Installation manual

English – Version 1.02 – August 2024

Table of Contents

Need help?

Do you have a question about the Pay Station and is the answer not in the manual?

Questions and answers

Summary of Contents for Smappee Pay Station

Page 1 Smappee Pay Station Installation manual English – Version 1.02 – August 2024...
Page 2 The specifications and other information in this document were verified to be accurate and complete at the time of its publication. Due to ongoing product improvement, this information is subject to change at any time without prior notice. For the latest information, see our online documentation: smappee.com/downloads...
Page 3: Table Of Contents
Table of contents Introduction ............................4 Safety instructions ........................... 5 Overview of the Pay Station ......................6 Preparing the installation of the Pay Station ................. 11 Installation and configuration ......................13 Using the Pay Station ........................21 Annexes ..............................23...
Page 4: Introduction
Smappee CPO services. This installation manual tells you how to install, configure and use the Pay Station. We advise you to read the content of this manual carefully, to ensure a safe and proper installation and enable you to use all the advanced features of this product to their full extent.
Page 5: Safety Instructions
 Do not expose the Pay Station to heat, flame or extreme cold.  Do not attempt to open, repair, or service any parts. Contact Smappee or your service partner for further information.  Only use the Pay Station under the specified operating conditions.
Page 6: Overview Of The Pay Station
3. Overview of the Pay Station Models Article no. Description PAY-STATION 5425036934467 Smappee Pay Station Components The Smappee Pay Station has the following primary components:  Housing  Payment terminal at the front of the Pay Station  Frame ...
Page 7 Identification label of the Pay Station Position of the Pay Station label The identification label is attached to the inner structure. Figure 2: Position of the identification label Smappee Pay Station – Installation manual – English...
Page 8 Article number Serial number IP rating and IK rating Operating temperature Electrical rating Manufacturing date Address of the manufacturer QR code containing article number and serial number Waste disposal symbol EAN code Smappee Pay Station – Installation manual – English...
Page 9 -25 °C to 50 °C Storage temperature -25 °C to 60 °C Relative humidity 0 % - 95 %, non-condensing Maximum installation altitude 0 – 2.000 m Access Locations with restricted and non-restricted access Smappee Pay Station – Installation manual – English...
Page 10 Where products are exposed to the elements of nature, the enclosure can be subject to gradual aging of the material, which can result in product discolouration over time. Therefore, wherever possible, place the product in a sheltered place to optimise the life of the materials. Smappee Pay Station – Installation manual – English...
Page 11: Preparing The Installation Of The Pay Station
4. Preparing the installation of the Pay Station The first step is to prepare the physical installation of the Pay Station as described in this chapter. Installation prerequisites  Obtain all necessary permits from the relevant local authority.  Local regulations may be applicable and can vary depending upon the region or country.
Page 12: Transport And Storage
Disconnect electrical power supply before removing the Pay Station for storage or relocation.  Only transport and store the Pay Station in its original packaging. No liability for damage incurred will be accepted if the Pay Station is transported in non-standard packaging.
Page 13: Installation And Configuration
The Pay Station contains electric components that may still contain electrical charge after being disconnected. Wait at least 10 seconds after disconnection before commencing work. This procedure describes the required steps for the physical installation of the Pay Station: Prepare the Pay Station (page 13) 2.
Page 14 Make sure to keep all fasteners. Figure 5: Rear view on the Pay Station 5. Remove the top part of the Pay Station and set it aside in a safe location. No wires need to be disconnected, nor components removed.
Page 15 As a result, you can assemble the anchor. Assemble the anchor of the Pay Station Context The Pay Station is designed to be installed at ground level using the supplied anchor. It is mandatory to use this anchor. Instructions Proceed as follows.
Page 16 IEC 60204-1 standard. The open side of the inner structure gives the rear of the Pay Station. The top of the lip gives the bottom of the Pay Station. The top of the lip should be level or slightly below ground level.
Page 17 Depending on the subsoil, the size may vary. Please refer to the technical specifications of size and weight to determine the dimensions for a solid foundation for the Pay Station. 2. Route the power supply and optional Ethernet cable in a flexible conduit system through the inner structure of the Pay Station.
Page 18 Figure 9: Rear view on the Pay Station assembly Proceed as follows. If you have divided the Pay Station into two parts when you unboxed it, attach the top part (6) to the bottom part (1). Make sure to use the fasteners (4).
Page 19 Start the power supply to the Pay Station Prerequisites CAUTION Risk of electric shock. Make sure no tools are in the Pay Station and persons stand free from the Pay Station. Instructions Proceed as follows. Take a photo of the identification label.
Page 20 As a result, Smappee Services will configure the Pay Station of your charging hub and contact you when the Pay Station can be used. For more information, refer to Using the Pay Station (page 21). Smappee Pay Station – Installation manual – English...
Page 21: Using The Pay Station
6. Using the Pay Station The users of a charging square can start and stop charging sessions from the Pay Station. Start a charging session Use the payment terminal as follows to start charging: Connect your electric vehicle to the charging station.
Page 22 From the payment terminal. Refer to the following instructions. Instructions Proceed as follows. Enter your payment card and follow the instructions on the payment terminal display. 2. Select the charging station with your connected EV to stop the charging session. Smappee Pay Station – Installation manual – English...
Page 23: Annexes
Each charging station has a serial number in the format 6xxxxxxxxx. If the charging station has two connectors, repeat the serial number in the next row. Put an X in the column if the charging point must be shown on this Pay Station. Smappee Pay Station – Installation manual – English...
Page 24: Declaration Of Conformity
Declaration of conformity Smappee Pay Station – Installation manual – English...
