Summary of Contents for Radionode RN320-BTH
- Page 1 Wireless Temperature & Humidity Sensor ® 900MHz LoRaWAN RN320-BTH User Guide 2023 | Rev. 1.00 Keep this document nearby so that it may be referred to when needed.
-
Page 2: Table Of Contents
Turning on the RN320 & Setting Up Detailedm Configuration Instructions System Setup LoRaWAN Setup Alarm Setup Installation Magnetic Version Screw Version Strand-type Mount Version Registering on Radionode 365 Cloud Display LED Status Indicators Memory Card for Data Recording Maintenance Update... -
Page 3: About This Manual
About This document contains instructions for usage and installation of the RADIONODE RN320. Product specifications and certain features ® this herein may be subject to change without prior notice. Figures used in this manual are for explanatory purposes only, and may differ Manual from your system depending on installation conditions. -
Page 4: Certifications
Certifications FCC Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Digital Device Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 5: Intellectual Property Rights
Intellectual © 2011-2023(주)DEKIST CO.,Ltd All rights reserved. Property All information in this guide is protected by copyright law. Whereby, no organization or individual shall copy or reproduce the whole or Rights part of this user guide by any means without written authorization from Xiamen DEKIST IoT Co., Ltd. -
Page 6: Introduction
Introduc- The RN320 is a compact temperature & humidity sensor that supports LoRaWAN communication and is easy to use. It is equipped tion with high-precision sensors for accurate detection of temperature and humidity data in various environments. Not only does it use low-power LoRaWAN technology, but it also includes a large-capacity battery that can be used for up to 10 years without replacement. -
Page 7: Exterior
Exterior ❶ ❷ ❸ E-Paper display TEMP/RH Sensor Reset Button ❹ ❺ ❻ Setting Button Buzzer ❼ ❽ ❾ SD-Card USB-C Port Magnet ❿ Anti-slip Pad Product Components RN320 USB C-TYPE Cable Magnetic Mount C-TYPE 3.6V batteries, 2EA (built-in) When purchasing the product, two C-type 3.6V batteries are installed in the device. -
Page 8: Specification
Specification Model RN320-BTH LoraWAN V1.0.3 ,OTAA/ABP ClassA ® CN470/IN865/RU864/EU868/US915/AU915/ Wireless KR920/AS923 Telecommunications TX : 20dBm Sensitivity : -137 dBm @ 300 bps CH1: Temp (-40 ~ 80℃) I n t e r n a l Te m p / R H... - Page 9 Battery Life Service life CONFIRM MODE DISPLAY 5 Years 7 Years 10 Years Based on a measurement interval of 10 minutes Please refer to the following URL for the payload decoder: https://github.com/radionode/RN300-Series-Lorawan...
-
Page 10: Configuration
The RN320 device can be configured using a USB cable. Follow these steps to complete the setup : the RN320 & Setting Up Download and install the “Radionode Configuration change Terminal Program” from the Radionode website (www. radionode365.com). Run the “Radionode Configuration change Terminal Program.”... - Page 11 [Display upon entering USB CONNECT MOD] Once the device is successfully recognized, the screen of the “Radionode Configuration Change Program” will change to green, and you should enter the command “ATSCON” in uppercase. The device’s basic information and settings will be displayed.
-
Page 12: Detailedm Configuration Instructions
LoRaWAN settings is used for configuring the transmission parameters in LoRaWAN network. ® Setting RN320- After running the Radionode Configuration Change Terminal Program and typing “ATSCON,” you can check the default settings of BTH Default the RN320 device. Settings Please enter the number to select a menu. -
Page 13: System Setup
System To change the system settings of the device, select menu 1 - SYSTEM SETUP. SYSTEM SETUP. Options along with the current settings will be Setup displayed. To return to the main menu, enter “x” 1 - SEND INTERVAL [ 5Min ] 1 - SEND INTERVAL [ 5Min ] Set the data transmission interval in minutes. - Page 14 a - TIMEZONE MINUTE [ 0 ] a - TIMEZONE MINUTE [ 0 ] Settings for adjusting the minutes in a specific timezone. b - TIMESTAMP [ 0 ] b - TIMESTAMP [ 0 ] You can set the UNIX TIMESTAMP time. c - FACTORY RESET c - FACTORY RESET Resets the device to its factory default settings.
-
Page 15: Lorawan Setup
LoRaWAN To change the LoRaWAN communication settings of the device, select menu 2 - LoRaWAN SETUP. Setup [ 2 - LORAWAN SETUP MENU. ] [ 2 - LORAWAN SETUP MENU. ] 1 - LORA BAND [ KR920 ] 1 - LORA BAND [ KR920 ] Select the frequency band specific to a country. - Page 16 a - MANUAL JOIN a - MANUAL JOIN Manually attempt to connect with a LoRa Gateway. b - MANUAL TIME SYNC b - MANUAL TIME SYNC Manually attempt to synchronize time with a LoRa Gateway. x - back to Main Menu x - back to Main Menu Return to the previous menu.
-
Page 17: Alarm Setup
Alarm Setup To set the alarm conditions, select menu 3 - ALARM SETUP. [ 3 - ALARM SETUP MENU.] [ 3 - ALARM SETUP MENU.] 1 - TEMP OFFSET 1 - TEMP OFFSET You can set the temperature calibration value. The measured temperature will be displayed with the calibration value added. -
Page 18: Installation
Installation Magnetic Attach the device to metal surfaces such as refrigerators, freezers, or cargo containers. The device is equipped with anti-slip pads on Version the back to ensure a firm and sturdy installation. Screw Turn the product counterclockwise to detach the mount on the back. -
Page 19: Strand-Type Mount Version
Strand- Turn the product counterclockwise to detach the mount on the back type Mount Version Then, align and attach the stand-type mount to the guide at the lower back of the product. -
Page 20: Registering On Radionode 365 Cloud
LoRa gateway registered with Radionode365. Once you have a LoRa gateway, set up the RN320 product to connect wirelessly, and then scan the QR CODE on the side of the product to proceed with Radionode registration on the displayed screen. 365 Cloud Check the QR code and device information on the side of the RN320. -
Page 21: Display
Display The display located on the front of the device shows important information including the model number, measurement values, and the status of the device. Utilizing electronic paper, this display has low power consumption and characteristics such as flickering during screen transitions. - Page 22 W h e n t h e d e v i c e i s t u r n e d o n , t h e Radionode logo is displayed along with a buzzer sound.
- Page 23 L o R a Gateway. RN320-BTH DISPLAY TYPE : A I n t h e d e f a u l t s e t t i n g s t a t e , t h e...
- Page 24 How to switch Short press the front button once. Press the power button on the display briefly once to put it into standby mode.At this time, the from OFF to ON green LED light will blink. display status Long press the front button once. Press the power button on the display long once to forcefully enter the menu.During this process, the green and orange LED lights will alternate blinking.
-
Page 25: Led Status Indicators
LED Status Refer to page 13, the system setup page (7. LED MODE), for instructions on how to change the display settings. Indicators LED OP MODE: In the most basic state, the data is transmitted, ● or the front button is pressed, a green LED will blink. LED AQ+OP MODE: When the temperature and humidity values ●... -
Page 26: Memory Card For Data Recording
Memory The device has the SD-WRITE function enabled by default. Card for Data Recording When an SD card is installed in the data logger, the measured data is recorded in CSV format as follows: Measurement date and time, timestamp, DEVEUI address, channel 1 value, channel 2 value. -
Page 27: Maintenance
Maintenance Update Use the C to A type cable included with the product purchase to connect the C type terminal at the bottom of the RN320 to the A type terminal of the PC. USB CONNECTION [Display upon entering USB CONNECT MOD] While pressing the button on the front of the product, press the reset button located at the bottom of the product twice in succession to enter firmware update mode. - Page 28 ⓒ 2024 DEKIST Co., Ltd. Telephone 1566-4359 Fax (+82) 31-8039-4400 Email master@dekist.com #A1801, 13, Heungdeok 1-ro, Giheung-gu, Yongin-si, Gyeonggi-do, Korea 16954...
