- Page 1 U-DVFE AUTO FREQUENCY SHIFT ANTI-HOWLING WIRELESS MICROPHONE REV Z0 14-05-2024...
-
Page 2: Safety Instructions
Congratulations on your purchase of the Hybrid U-DVFE Dual Wireless Microphone System, designed and engineered by Hybrid. In order to make our products more convenient and safe for customers, please read and take note of the instructions and regulations within this manual before using this product. - Page 3 Introducing the Hybrid U-DVFE Wireless Microphone System. These microphones adopt a precise circuit design, exhibit superb cardioid directivity and have high sensitivity output, low noise and a wide dynamic range. The Hybrid U-DVFE microphone is widely used in stage, speech and personal recordings.
-
Page 4: Troubleshooting
SAFETY 1: CARE AND MAINTENANCE Keep the device away from moisture, electromagnetic fields and high temperatures. Never expose the device to direct sunlight. Take the batteries out of the microphone and unplug the receiver when not being used. 2: CLEANING Unplug the receiver from the power and use a damp cloth to clean the device. -
Page 5: Rear Panel
USER MANUAL – HYBRID U-DVFE – UHF WIRELESS MICROPHONE SYSTEM DUAL RECEIVER FEATURES FRONT PANEL P R OFES S ION AL WIR ELES S M ICR OP HON E REC EIV E R POWER REAR PANEL DC 12-15V POWER switch: Press the button to power on or off LCD screen: Displays the receiver’s status... - Page 6 PAGE 6 PAGE 6...
- Page 7 USER MANUAL – HYBRID U-DVFE – UHF WIRELESS MICROPHONE SYSTEM DUAL MICROPHONE/TRANSMITTER FEATURES Grille LCD screen Power and mute switch IR sync LED Battery cover Battery compartment Antenna Charging socket SETTING UP THE WIRELESS MICROPHONE SYSTEM Turn the volume of the mixer all the way down before turning the microphone on, then turn on the receiver.
- Page 8 RECEIVER LCD DISPLAY Radio frequency signal strength Audio frequency signal strength RF frequency Channel number Mute status display USING THE WIRELESS MICROPHONE SYSTEM 1. TO SELECT THE RF CHANNEL To set the channel of either microphone on the receiver, press and hold the UP button of the corresponding microphone until the CHANNEL number flashes.
- Page 9 USER MANUAL – HYBRID U-DVFE – UHF WIRELESS MICROPHONE SYSTEM DUAL 2: TO SYNCHRONISE THE MICROPHONE’S CHANNEL WITH THE RECEIVER’S CHANNEL First, unscrew the battery cover of the microphone and align the IR LED of the microphone with the IR LED of the receiver. Next, press the SET button on the receiver; the LCD screen will display “IA---”...
- Page 10 4: TO ADJUST THE VOLUME To adjust the volume of either microphone, use the UP or DOWN buttons of the corresponding microphone on the receiver. The indicated volume range is VOL. 00 to VOL. 20. 5: TO LOCK THE MIC SETTINGS ON THE RECEIVER Once you have set up your microphone system, you can lock the receiver’s display to ensure the settings are not changed.
-
Page 11: Technical Specifications
USER MANUAL – HYBRID U-DVFE – UHF WIRELESS MICROPHONE SYSTEM DUAL 6: TO MUTE THE HANDHELD MICROPHONE Press but don’t hold the power switch. The LCD display will show a mute symbol to indicate that the microphone is muted. Pressing the power switch once more will unmute the microphone. -
Page 12: Receiver Specifications
RECEIVER SPECIFICATIONS Power supply adapter input AC 100–240 V, 50/60 Hz DC Power supply adapter output 13–15 V, 500 mA Power consumption S/N ratio > 98 dB P/N ratio > 80 dB F/N ratio > 80 dB Receiver sensitivity 5 dBu MICROPHONE/TRANSMITTER SPECIFICATIONS Modulation mode Tunable bandwidth...
