- Page 1 Operating Instructions Magnetic Drilling Machine MB 351 F MB 351 F...
- Page 2 Stürmer Maschinen GmbH. Passing on as well as copying of this docu- ment, the use and distribution of its content are prohibited if not explicitly per- mitted. Contraventions are liable to compensation. Subject to technical modifications and error. MB 351 F | Version 1.07 | EN...
-
Page 3: Table Of Contents
8.3 Disposing of lubricants................ 12 9 Spare parts.................13 9.1 Spare parts orders ................13 9.2 Spare parts drawing................14 10 Electrical circuit diagram..........15 11 EC Declaration of Conformity ........16 12 Notes ................17 MB 351 F | Version 1.07 | EN... -
Page 4: Introduction
0049 (0) 951 96555-119 E-Mail: ersatzteile@stuermer-maschinen.de We are always interested in valuable experience and knowledge gained from using the application-which then could be shared and be valuable to develop our products even further. MB 351 F | Version 1.07 | EN... -
Page 5: Limitation Of Liability
. NOTE! This combination of symbol and signal words indicate a pos- sibly dangerous situation which may lead to property and en- vironmental damages if they are not avoided.. MB 351 F | Version 1.07 | EN... -
Page 6: Safety Markings On The Magnetic Drilling Machine
The personal protective equipment is explained in the following paragraph: Hearing protection The hearing protection protects the ears against damages of hearing due to noise. Face shield The face shield protects the face from flying parts. MB 351 F | Version 1.07 | EN... -
Page 7: Intended Use
Weldon shaft holder 19 mm Overload protection Dimensions of the magnetic base 165 x 80 mm Dimensions 300 x 210 x 210 mm Weight 10,5 kg Min. working thickness 12 mm MB 351 F | Version 1.07 | EN... -
Page 8: Type Plate
Dispose of these substances at a recycling centre or hand them over to the re- levant waste disposal company. 4.3 Storage Store the magnetic drilling machine thoroughly cleaned in a dry, clean and frost-free environment. MB 351 F | Version 1.07 | EN... -
Page 9: Assembly And Function
4. Magnetic switch 9. Annular cutter 5. Motor switch 10. Chuck Scope of delivery - Safety device - Operating tool - Plastic carrying case Not included in delivery: - Annular cutter - Centring pin MB 351 F | Version 1.07 | EN... -
Page 10: Functions
- The operator must not work when under the influence of al- cohol, drugs or medication. The operator must not work if he is under the influence of alcohol, drugs or medication. - Operator must have sufficient stability and freedom of mo- vement MB 351 F | Version 1.07 | EN... -
Page 11: Quick-Release Device
7.1 Care by cleaning Always keep your magnetic drilling machine in a clean condition. Use protective gloves Wear suitable protective gloves when cleaning the machine in order to protect yourself against injuries caused by chips. MB 351 F | Version 1.07 | EN... -
Page 12: Maintenance
In case of doubt, contact your local waste disposal authority. Consult a spe- cialist disposal agent for recycling if needed. 8.3 Disposing of lubricants Lubricant manufacturers provide disposal information for the lubricants used. If necessary, request product-specific data sheets. MB 351 F | Version 1.07 | EN... -
Page 13: Spare Parts
Example The handle for the magnetic drilling machine MB 351 F must be ordered. The handle has the number 55 in the spare part drawing. By ordering spare parts, send a copy of the spare parts drawing (-) with the... -
Page 14: Spare Parts Drawing
Spare parts 9.2 Spare parts drawing Fig. 5: Spare parts drawing MB 351 F | Version 1.07 | EN... -
Page 15: Electrical Circuit Diagram
Electrical circuit diagram 10 Electrical circuit diagram Fig. 6: Electrical circuit diagram MB 351 F | Version 1.07 | EN... -
Page 16: Ec Declaration Of Conformity
DIN EN 61029-1/A11:2011-11 Safety of transportable motor-operated electric tools - Part 1: General requirements Responsible for the documentation: Kilian Stürmer, Stürmer Maschinen GmbH, Dr.-Robert-Pfleger-Str. 26, D-96103 Hallstadt Hallstadt, 13.10.2020 ______________________ Kilian Stürmer Managing Director MB 351 F | Version 1.07 | EN... -
Page 17: Notes
Notes 12 Notes MB 351 F | Version 1.07 | EN... - Page 18 www.metallkraft.de...
