- Page 1 User Manual Residential Lithium Battery System Type: BHF-S series BHF-S-series.R110.V1.0...
-
Page 3: Table Of Contents
Contents 1. About This Manual ......................1 1.1 Products Covered by This Manual .................1 1.2 Target Group.........................1 1.3 Symbols Used .......................1 1.4 Storage of the Manual ....................1 2. Safety ..........................2 2.1 Important Safety Instructions ..................2 2.2 Response to Emergency Situations .................3 2.2.1 Leaking Batteries .......................3 2.2.2 Wet Batteries or Damaged Batteries ..............3 2.2.3 Fire ..........................4... - Page 4 5.4.1 Unpack and Check for Transport Damage ........... 16 5.4.2 Pre-installation check ................... 16 5.4.3 Procedure for Inverter ..................16 5.4.4 Procedure for BHF-S series Application ............17 6 Electrical Connection ..................... 22 6.1 Overview of the Connection Area ............... 22 6.2 Battery Power Connection ..................
-
Page 5: About This Manual
About This Manual 1.1 Products Covered by This Manual Li-ion Battery: BHF-S Series energy storage system. 1.2 Target Group This manual is intended for a qualified electrician. Any electrical installation and maintenance on the battery must be performed by qualified electricians in compliance with standards, wiring rules or requirements of local grid authorities or bodies. -
Page 6: Safety
The information in this manual www.LIVOLTEK.com is subject to change without notice. Please check more information. Safety The manual describes the installation, commissioning, maintenance of the battery. Please read it carefully before operating. To prevent personal injury... -
Page 7: Response To Emergency Situations
discharge; any damage caused by ESD is not warranted by the manufacturer. 2.2 Response to Emergency Situations 2.2.1 Leaking Batteries If the battery leaks electrolyte which is corrosive, avoid contact with the leaking • liquid or gas. Direct contact may lead to skin irritation or chemical burns. If one is exposed to the leaked substance, do these actions: General Advice: Immediate medical attention is required. -
Page 8: Fire
• 2.4 Limitation of Liability Any product damage or property loss caused by the following conditions • LIVOLTEK does not assume any direct or indirect liability. Product modified, design changed or parts replaced without LIVOLTEK • authorization; Changes, or attempted repairs and erasing of series number or seals by non... - Page 9 LIVOLTEK technician; System design and installation are not in compliance with standards and • regulations; Failure to comply with the local safety regulations; • The Product has been improperly stored in distributor’s or end user’s premises; • Transport damage (including painting scratch caused by movement inside •...
-
Page 10: Scope Of Delivery
Scope of Delivery 3.1 Battery subassembly The table below lists the quantity of each component Object Description Quantity Battery Pack Wall-Mounting Bracket A Bolts for Bracket Locating Pin Certificate... -
Page 11: Control Box & Mounting Base Subassembly
3.2 Control box & Mounting Base subassembly The table below lists the quantity of each component Object Description Quantity Control Box Mounting Base bolts for Bracket Power cable Communication cable Locating Pin Wall-Mounting Bracket C Wall-Mounting Bracket B Perforating paper... -
Page 12: Subassembly Of Tandem Optional Kit
Expansion anchor bolts SDS Document User Manual 3.3 Subassembly of Tandem optional kit The table below lists the quantity of each component Object Description Quantity Tandem optional kit 1 pair Wall-Mounting Bracket B Expansion anchor bolts Locating Pin Bolt for Bracket Wall-Mounting Bracket C Perforating paper NOTE: Accessories for different applications may be different. -
Page 13: Product Description
Product Description Thank you for choosing the LIVOLTEK battery. The BHF-S Series battery is a series of High Voltage Lithium-ion battery. It is designed for residential and commercial energy storage system. It must only be connected with an officially tested inverter. - Page 14 If the battery is not used or not installed for a long time, it is recommended to measure the voltage and charge it before use for better maintenance. Icons on the Nameplate Symbol Explanation Caution, Risk of Danger Caution, Risk of Electric Shock CE marking The battery complies with the requirements of the applicable EU directives.
- Page 15 Icons on the warning label Symbol Designation Refer to the Operating Manual before using Caution, Risk of Danger Caution, Risk of Electric Shock Keep the battery away from open flame or ignition sources. Keep the battery away from children. Do not short circuit the battery. WEEE Mark.
-
Page 16: Mounting
Mounting 5.1 Environment Requirements Install the Battery System on the surface with sufficient bearing capacity and flatness, wooden surface is prohibited. Increase the bearing capacity and flatness of the surface by laying the foundation, adding bearing plates and so on. Keep children away from the battery. -
Page 17: Tools
5.2 Tools These tools are required to install the battery system. Drill Screw Driver Marker Hexagon keys Tap measure Multi-meter Utility knife... -
Page 18: Angle And Space Requirements
It is recommended to wear the following safety gear when dealing with the battery system. Insulated Safety Goggle Safety shoes Dustproof Mask Gloves 5.3 Angle and Space Requirements 5.3.1 Angle requirement Never install the Battery horizontally, or with a forward tilt or with a backward tilt or even with upside down. -
Page 19: Space Requirement For The Battery
5.3.2 Space requirement for the battery The horizontal space between 2 adjacent batteries should not exceed mm, the horizontal space between 2 adjacent wall- mounted brackets should not exceed mm, otherwise the length of parallel power cables will be insufficient. -
Page 20: Mounting The Battery
5.4 Mounting the Battery 5.4.1 Unpack and Check for Transport Damage Unpack the battery package and make sure the battery is intact during transportation. If there are any visible damages, such as cracks, or missing parts, please contact your dealer immediately. 5.4.2 Pre-installation check •... -
Page 21: Procedure For Bhf-S Series Application
5.4.4 Procedure for BHF-S series Application STEP 1: Anchor Battery Bracket Make sure the wall is strong enough to withstand the weight of battery. • Take out the perforating paper and put the bottom of perforating paper • parallel to the floor, then stick the perforating paper on the wall. - Page 22 STEP 3: Hammer the expansion anchor bolts Hammer the expansion anchor bolts into the holes to lock Wall-Mounting • Bracket C; Make sure Wall-Mounting Bracket is locked correctly according to shapes • in perforating paper.
- Page 23 STEP 4: Screw the bolts Screw the expansion bolts clockwise tightly; • STEP 5: Screw the Locating Pin Screw the Locating Pin to the Battery and Mounting Base. • STEP 6: Install the battery to the bracket Connect Ground wire to the Mounting base and ground firstly; •...
- Page 24 below, make sure different part is locked tightly to each other.
- Page 25 STEP 7: Install more packs If more than 4 packs need to be installed, divide them into two columns of • which has no more than four packs for each column. Using tandem optional kit to replace Control Box and Mounting Base. •...
-
Page 26: Electrical Connection
Electrical Connection 6.1 Overview of the Connection Area Position Definition BMS COM 1 Power Switch Battery- BMS COM 2 LED Indicator Battery+ DC Breaker... -
Page 27: Battery Power Connection
6.2 Battery Power Connection Battery connection diagram Red /Blue/Yellow solid line: Positive / Negative power/grounding cable Black dotted line: CAN communication cable. Procedure: Before connecting the power cables, make sure the DC breaker of the battery is disconnected. STEP 1: Install the Quick-Plugs of power cable to the battery. -
Page 28: Bms Communication Connection
6.3 BMS Communication Connection Please check whether the BMS communication cable in the accessory box is appropriate for the battery. If you are not sure for that, please confirm with your vendor. Procedure: STEP 1: Please insert the connector of the communication cable into the BMS Communication COM2 port of battery. -
Page 29: Operating Of The Battery
Operating of the Battery 7.1 LED Indicator The LED indicates the operating status of the battery. Explanation Green Green light indicates the battery works well. Fault occurs in the battery. SOC ≤8% When red light is on for more than 6 hours indicates fault occurs in the battery, please contact technical support for help. -
Page 30: Commissioning Procedure
7.3 Commissioning Procedure ➢ Manually connect the DC breaker of all the batteries, then switch all the batteries on. Then BMS will enter the self-test state. Wait until the indicator is steady on in green, which indicates that the battery system is powered on and runs normally. -
Page 31: Technical Data Of Bhf-Series
Max. Charge/Discharge 48A/48A Current@25℃ Max. Number of a Cluster 6 Units General Data Communication 0~55℃ charge / -20~55℃ discharge Operating Temperature Dimension(W*H*D) 870*208.7*288.5mm Weight 62kg IP Protection Type IP65 10 Technical Data of Battery System Product BHF- BHF-S10 BHF-S15 BHF-S20 BHF-S25 model Nominal... - Page 32 Nominal 10.2 12.8 15.4 Power (kW) Max power 14.7 19.7 24.6 29.5 (kW) Rated Charge/Disch arge Current （A） charge/Discha rge Current Depth of Discharge Operating CH:0~55℃ Temperature DCH:-20℃~55℃ Operating 5%~95% Humidity Operating ＜4000m Altitude Communica tion Cooling Type Natural Ingress IP65 Protection 870*208...
- Page 33 1418-35 Moganshan Road, Hangzhou, 310011, China info@livoltek.com www.livoltek.com...
