- Page 1 BELLA SMART SECURITY SERIES #Simplesmartsecure...
- Page 3 WELCOME TO HOGAR IOT WORLD Welcome to Hogar Controls © – Smart IoT Solutions for Smart Spaces. Thank you for trusting us with your space & choosing Bella, the Video Door Bell. This manual is designed to help you install your Bella in an easy and hassle-free manner.
-
Page 4: Table Of Contents
BELLA SMART SECURITY SERIES TABLE OF CONTENTS USAGE NOTICE 1.1. Warnings and Considerations 1.2. Precautions PRODUCT DETAILS 2.1. Description 2.2. Features 2.3. Contents in the Box 2.4. Technical Specifications... - Page 5 INSTALLATION & SETUP 3.1. Pre-installation mandatory checklist 3.2. Installation 3.3. Wiring instruction for Bella 3.4. App Installation and Setup 3.5. Answering a call 3.6. Streaming live video of the Bella 3.7. Ring Module 3.8. Factory Reset WARRANTY...
-
Page 6: Usage Notice
USAGE NOTICE 1.1. WARNINGS AND CONSIDERATIONS Caution symbols highlighted across the manual represent the following: Indicates the highlighted precautions to be followed to prevent any high level of severity. Indicates the instructions to be followed during installation. Indicates suggestions and tips. Please follow the notices to ensure your safety as well as to prevent property loss. - Page 7 Using this product in any manner other than how it is referred to in this document voids your warranty. Further, Hogar Controls is NOT liable for any damage incurred with the misuse of the product.
-
Page 8: Precautions
1.2. PRECAUTIONS Ensure the below DOs & DON'Ts are adhered to enjoy a seamless product experience: - Format the SD card before inserting for the first time. - Please keep the door unit at least 3 to 5 meters away from the answering unit. - Check the polarity before powering Bella. -
Page 9: Product Details
- Live Streaming video of the visitor - Provides remote user access. - Constant Push Notifications/Alerts when someone passes through the door. - Manually captures snapshot/video. - Two-way audio and one-way video via Hogar SE App. - Cloud storage (In-App purchase). - Playback recorded video. -
Page 10: Contents In The Box
2.3. CONTENTS IN THE BOX - Bella - USB Cable - Screw Package - 3M Sticker - User Guide - Small Wrench - Wall Mount Box... -
Page 11: Technical Specifications
2.4. TECHNICAL SPECIFICATIONS Transmission Frequency 2.4 GHz Image Sensor 1/4"Color CMOS Sensor Video Compression H.264 Two-Way Audio One-Way Video Yes/iOS and Android Push Notification Event List Yes/Snapshot and Video Playback App/iOS and Android Supported (4 IR LED, Night Night Vision visibility up to 3 meters) Audio Input/Output Speaker &... - Page 12 Data Storage Memory Card upto 128 GB View Angle H:110/V:90 Wireless Connectivity Wi-Fi 802.11b/g/n Inbuilt Battery 5000 mAH Li battery IP Ratings IP65 Display Resolution 2 Megapixels Lens f:2.8 mm, F:2.0 (IR Lens) 2mW in sleep mode & Power Consumption 1W when wake up Operating Temperature 10 - 55⁰...
-
Page 13: Installation And Setup
INSTALLATION & SETUP 3.1. PRE-INSTALLATION MANDATORY CHECKLIST - Ensure that you have a reliable cable internet connection for Bella to work at its best. Portable internet connections based on hotspots or a Wi-Fi dongle will not provide the best and consistent results. - Your experience with Bella will vary based on the quality of your router. - Page 14 Microphone Lens Light Sensor Motion Sensor (PIR) Right button...
-
Page 15: Wiring Instruction For Bella
3.3. WIRING INSTRUCTION FOR BELLA 12 Volts 500mA adapter Positive Negative WIRING DIAGRAM... -
Page 16: App Installation And Setup
- Use a 5V power supply to charge the battery. You can place the door bell once it is fully charged. Recharge whenever the battery gets discharged. - Press the power button on the rear to TURN ON the device. - Open the Hogar SE app and register if you are a new user. - Page 17 ” icon - Login to the Hogar SE app and select “ROOM” from the dashboard and then “ on the top right of the screen.
- Page 18 - Select Security → Video Door Bell → Select the option and continue to the next step.
- Page 19 - Connect to your home Wi-Fi Network and select “NEXT”.
- Page 20 - Point Bella to the application screen to scan the displayed QR Code. - Bella makes a prompt sound indicating a successful configuration.
- Page 21 - Rename the device and add it to the Room.
- Page 22 - Select Bella to stream live video.
- Page 23 The following options are available on the live stream screen: a) Screenshot: With this option you can save the screenshot at the present time. b) Speak: Press the speak button and it will be highlighted in BLUE to indicate that the speaker is enabled and the audio can be heard by the visitor.
- Page 24 - In edit option, Device information show the detailed information of device.
- Page 25 Basic function settings: Flip screen: Flips the live view screen, Talk mode: To select the communication mode (Half duplex/Full duplex). PIR: Select the sensitivity of PIR Motion Power management settings: Indicates battery percentage, and low battery alert notifications settings. Storage settings: Displays the SD Card memory status. Share device: To share the device with other users.
-
Page 26: Answering A Call
3.5. ANSWERING A CALL - The screen will appear when a visitor presses the bell button. - You can Ignore or Accept the call. - On accepting the call, you can directly view the person in front of the door via the Mobile phone/Tablet. - Page 27 Calling Interface...
-
Page 28: Streaming Live Video Of The Bella
3.6. STREAMING LIVE VIEW OF THE BELLA... -
Page 29: Ring Module
3.7. RING MODULE Volume Control: Press the volume button on the Chime to change the Volume of the ringtone it increases initially and decreases in a continuous loop. Paring additional Chimes to the door bell: The ringtone can be set differently for different doorbells. - Page 30 - Power it by plugging into the 230V. - Select your favourite ringtone before pairing, by using the forward/back buttons. - Press and Hold the Volume button for 5 Seconds until a Ding-Dong is heard and LED indicator starts flashing and it enters into pairing mode. - Press the door bell ring button to pair it with the Chime.
-
Page 32: Specification
SPECIFICATION Working voltage AC 85-256V Wireless range 80 FEET Audible range 150 FEET Selectable ringtones Volume range 25-110 DB, 4 LEVELS 433.92MHZ+-20KHZ Working frequency Working temperature -30° C-70° C... -
Page 33: Factory Reset
3.8. FACTORY RESET - Press and hold the reset button for 5 seconds until it makes a "di" sound indicating successful reset of the device... -
Page 34: Warranty
Warranty Hogar offers an Exclusive 18-Month Warranty on any product that covers defects in materials and quality under normal use of the Product. The Terms and Conditions of this 1.5 YEARS LIMITED WARRANTY can be viewed on www.hogarcontrols.com or scan the... - Page 35 CONGRATULATIONS You've successfully installed your Bella. Now you can experience seamless control of your Bella with your Hogar SE App. Add more to your home from our range of smart home automation solutions and live the smart life.
