- Page 1 WIRELESS HEADSET TO INTERCOM CONVERSION KIT How to connect a wireless headset to an Intercom with a transceiver box adapter I NSTALL ATIO N I NSTR UCTIO N S RW-HS-OFF V1.0 - 09/2024...
- Page 2 Setting Up Equipment QTY (1) RW-HS-OFF Kit Kit Contents: Headset, Wireless Transceiver Box, Charging cable Headset Wireless Transceiver Box Step 1 Remove The Wireless Transceiver (WTX-710 or WTX-710D) and the wireless headset (WH56BP) from the box. Connect the power plug (red and back) with the fuse to the radio or power source, and connect the other power plug (red and black, no fuse) to the intercom.
- Page 3 Using the Headset & Box Functions Step 4 Turn on the headset by short pressing the power button on the headset. It should automatically connect to the transceiver box. Step 5 Use the 5pin plug cable on the transceiver Box to connect to the 5pin male cable or port on the intercom. Step 6 Use the red PTT button on the headset to transmit on the headset and the adjustable knob to control volume, and you’re ready to go transmitting on your headset wirelessly.
