Installation Guide
Rugged VT7-GE
Version 1.4E - July 2024
Overview ....................................................................................................... 2
Equipment Checklist ................................................................................ 3
Wiring Diagram ......................................................................................... 5
Installation .................................................................................................... 6
Tablet Setup ................................................................................................. 8
Tablet Installation with Headwind MDM ....................................... 9
Advertisement
Table of Contents
Summary of Contents for Smartmove VT7-GE
-
Page 1: Table Of Contents
Installation Guide Rugged VT7-GE Version 1.4E – July 2024 Overview ....................... 2 Equipment Checklist ................3 Wiring Diagram ..................5 Installation ....................6 Tablet Setup ....................8 Tablet Installation with Headwind MDM ........9... -
Page 2: Overview
Receive a signal from the physical duress alarm and trigger the panic functionality in SmartMove (i.e. make a silent call to the base so the base can hear what is going on inside the car). Send fares directly to an EFTPOS terminal (when using the built-in Soft Meter). -
Page 3: Equipment Checklist
Components: 1 x VT7 GE device Includes screw for securing SIM card door 1x Panic Switch Available from SmartMove or other suppliers 1 x VT7 Cradle with loom Note that the cradles are not cross compatible between the Pro/GE/GA models 1 x VT7 Mounting Bracket Supplied with RAM mount by default. - Page 4 SmartMove Installation Guide DB9 Male RJ12 6P6C 1 x VT7 to EFTPOS adapter Connect to Blue RJ12 plug on CabCharge loom. Supplied by SmartMove as needed. DB9 Male RJ12 6P6C 1 x VT7 to other Taxi Meter adapter Configured adapter available from SmartMove Version: 1.4E –...
-
Page 5: Wiring Diagram
SmartMove Installation Guide Wiring Diagram Serial cable – Meter connection: Use null modem with CabCharge External USB, Can1/Can2: Not used Common GND: Not required Meter Power: Optional Dome Light: Optional ** Meter Input: Not used Panic Input: 12V +’ve input *** Constant 12V: Inner +’ve... -
Page 6: Installation
Connecting to a CabCharge EFTPOS system requires a special adapter, likewise for other taximeter systems. Contact SmartMove for the appropriate cable. The Ignition Wire (yellow) allows the device to automatically turn on/off based on the ignition. - Page 7 SmartMove Installation Guide On the GPIO, a ground wire is available. If GPIO are being used, connecting the GND wire is recommended. GPIO Outputs switch from floating to GND and must be connected via a Relay: The maximum sink current rating of GPIO output is 300mA.
-
Page 8: Tablet Setup
SmartMove Installation Guide Tablet Setup The device requires SmartMove Go to be installed. This is most commonly done via MDM or Kiosk software, which allows devices to be managed in bulk. Alternatively, navigate to the Google Play store, search, and install SmartMove Go: https://play.google.com/store/apps/details?id=com.smartmovetaxis.driver.smartmove&hl=en... -
Page 9: Tablet Installation With Headwind Mdm
The VT7 GE is intended to be used with Headwind MDM (mobile device management). We can provide a login if needed; this service is included with the standard SmartMove fees. 1. Setup the device with a QR code as described here.
