Index
Connecting the Sennheiser Microphone
Using the ProSound radio microphone
Connecting devices by cable
Connecting devices by Bluetooth
N.B. Using the Sennheiser Microphone (see page 2)
is the simplest way to set up the PA system
1
Instructions on how to use the U3A Trust Fiesta Plus Speaker-Amplifier
page 1
page 2
page 3
page 4
page 5
Contents checklist for accessories with the Speaker Amplifier
Microphone cable (3 pin XLR to 6.25mm jack plug)
Sennheiser microphone
Mains cable
Aux cable – jack to jack (uses microphone input)
Aux cable – Phono plugs to 6.25mm jack plugs
Aux cable – Phono plugs to 3.5mm stereo jack
Contents checklist for accessories with the ProSound radio receiver
Channel B Radio microphone
12-volt power supply
Jack-to jack to connect receiver to amp'
'Tie microphone' & 'Headset microphone'
Bodypack radio transmitter
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Trust Fiesta Plus U3A
Summary of Contents for Trust Fiesta Plus U3A
- Page 1 Instructions on how to use the U3A Trust Fiesta Plus Speaker-Amplifier Contents checklist for accessories with the Speaker Amplifier Index page 1 Microphone cable (3 pin XLR to 6.25mm jack plug) Connecting the Sennheiser Microphone page 2 Sennheiser microphone Using the ProSound radio microphone...
-
Page 2: Volume Control
3 hours) 3. Plug the jack plug of the ‘jack plug to XLR socket’ cable into the microphone input of the Trust amp’ and the XLR end into the microphone 4. Set the master volume control initially to about 70%. (You can... -
Page 3: Microphone Volume Control
Connecting the Radio Microphone Plug one end of the ‘jack to jack’ cable into the microphone socket of the Trust amp’ and the other end into the jack socket on the back of the receiver Make sure the either the microphone or the bodypack has two working alkaline AA batteries inserted into it in the right way Switch on the Trust amp’... - Page 4 3 hours) 3. Plug one of the cables that uses two phono plugs cable into the AUX input of the Trust amp’ and the other end into your device which has an output or headphone socket and might be a keyboard, mobile phone, or iPad 4.
- Page 5 Top indicator goes green when amp’ is switched on Connecting by Bluetooth 5-volt USB Power if needed Bluetooth blue led Bluetooth button Master volume Instructions to use Bluetooth Shows amp’ is connected to control mains (but not switched on) 1. Plug in mains cable into back of amp’. The lower led on the front panel should turn green 2.
