Sealey EVCC2211KW Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instruction
manual
1. SAFETY
1.1. GENERAL SAFETY
Familiarise yourself with the product before using it for the first time. Read through the following operating and safety instructions
9
carefully before use. They form part of the product and must be available at all times.
KEEP OUT OF THE REACH OF CHILDREN!
9
This charging cable is only suitable for electric and hybrid cars with a Type 2 plug, 3 phase.
9
Intended use: Using the charging cable, electric and hybrid cars, can be charged from a charging infrastructure intended for this
9
purpose. Any other use is not permitted and is therefore regarded as improper use. The charging cable is only safe, if these operating
instructions and the documentation for the car are followed.
Before using the charging cable, you must read these operating instructions and the documentation for the car.
9
When the charging cable is being used, observe the instructions as described.
9
Failure to do this can lead to personal injury or damage to property, such as, for example, electric shock, short circuit or fire.
9
Any other use may cause damage to the device and expose the user to a risk of serious injury. The manufacturer is not liable for any
9
injury or damage resulting from improper use.
NOTE: In case of doubt, get a qualified electrician to check that the charging infrastructure is suitable.
The charging cable has been developed for consumer use and is not suitable for use in a commercial or industrial environment.
9
The product must only be used by people who have been trained to do so.
9
1.2. SPECIFIC SAFETY INSTRUCTIONS
1.2.1. PERSONAL SAFETY:
Keep children and animals away from the charging cable.
9
DO NOT allow children to play with the charging cable. Cleaning and day-to-day maintenance must not be performed by children.
8
Children must be supervised to ensure that they do not play with the device.
9
Within the working area, the user is responsible for any damage or injury to third parties that was caused by the use of the device.
9
during operation, never point the charging cable at yourself or other individuals, and keep the charging cable well way from your ears
and eyes. There is a risk of injury! Keep the device in a dry location and out of the reach of children.
1.2.2. OPERATIONAL SAFETY
DO NOT use the charging cable while driving the vehicle.
8
Before setup or first use, check the charging cable for any damage and do not use unless in perfect working order.
9
DO NOT immerse the charging cable in water. There is a risk of electric shock!
8
In hot weather, DO NOT leave the charging cable in a car. This could permanently damage the charging cable.
9
Both the charging cable and plug, may become warm during operation. There is a risk of burn injuries from touching the hot surfaces.
9
DO NOT operate the charging cable near to flammable liquids or gases. Failure to do so risks causing a fire or explosion!
8
Unplug the plug from the charging infrastructure and the plug from the car:
9
- When you are not using the charging cable; If you are doing cleaning work;
- If the connection cable is damaged;
- If foreign objects have got into the device or you notice unusual noises.
Only use the accessories supplied and recommended by the manufacturer.
9
DO NOT disassemble or modify the charging cable. The charging cable must only be repaired by a qualified maintenance technician.
8
DO NOT use the charging cable in areas with a risk of explosion, e.g. near flammable liquids, gases or powders.
8
DO NOT expose the charging cable to any source of heat.
8
DO NOT store in places where the temperature may exceed 50 °C.
8
DO NOT connect the charging cable to a faulty or unsuitable charging infrastructure, which, for example, is not designed for the
8
continuous use required.
Protect the plug connections and plug devices from moisture and liquids.
9
DO NOT step on or drive over plugs, charging cable connecting cables.
8
DO NOT jam or kink charging and connection cables.
8
DO NOT touch plugs with wet hands.
8
When the charging cable is not being used, always keep the cover caps onto the plugs.
9
The charging cable must not be used if it is not possible to operate it properly in accordance with the instructions. Refer to the
9
manufacturer, a responsible dealer or an electrician for advice.
1.3. ELECTRICAL SAFETY How to avoid accidents and injuries resulting from electric shock:
© Jack Sealey Limited
5M 16A (11KW) 3PH TYPE 2 TO TYPE 2 EV
CHARGING CABLE
EVCC2211KW
MODEL NO:
Original Language Version
EVCC2211KW Issue:1 02/09/24
