Summary of Contents for Sapphire Audio Splash Wizard Basic
- Page 1 Splash Wizard Basic Installation and User Manual...
-
Page 2: Table Of Contents
Table of contents Splash Wizard Basic Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -
Page 3: Splash Wizard Basic Warning
Splash Wizard Basic Warning The Splash Wizard Basic is designed for use in connection with residential and commercial water features . Proper installation, use, and maintenance are essential for optimal performance and to reduce the risk of accident or injury . Follow the installation instructions carefully . - Page 4 . The Splash Wizard Basic Controller has been tested before leaving the manufacturing plant . A blown circuit board is not covered under any warranty of this product . It is important that a licensed electrician installs the Splash Wizard Basic Controller, they read the instructions provided, and examine the diagrams to ensure that the circuit board is not damaged during installation .
-
Page 5: Overview
11 for more . 2. Power Cable: The main power cord 6. Reset Button: Use when adjusting the provides power to the Splash Wizard Basic Splash Wizard Basic program sequence or control panel . changing dip switch configuration . Push and hold to reset . -
Page 6: Device Introduction And Dimensions
7 .25" Device Feature Summary A single unit of the Splash Wizard Basic can control 1 to 9 valves . It can also be networked with a second unit to increase the total number of valves from 10 to 18 . -
Page 7: Electrical Specifications
Electrical Specifications ATTRIBUTE VALUES Controller Voltage 120VAC Controller Max Amperage 834 mA Operating Amperage 100 mA Wire Gauge Range 24AWG…16AWG Strain Relief Diameter .475" Valve Specifications TYPE OPERATING VOLTAGE Solenoid Valve 24V AC Number of Relays WARNING: Do not exceed the rated voltage or amperage of the relays . Doing so will damage them, and void the warranty . -
Page 8: Mounting Instructions
Mounting Instructions To mount the Splash Wizard Basic Controller, first remove the lid and disconnect the power button cable . Ensure the Controller is mounted within five feet of an electrical outlet . If the Controller is mounted further than five feet from an outlet, an extension cord will be needed . -
Page 9: Wiring Introduction
For main power, plug the cord into a GFCI outlet . For Valves, the Splash Wizard Basic has a row of terminals running along the bottom of the board . To connect the first valve to the Controller, wire it into terminals 1 and 2 . For the second valve, wire to terminals 3 and 4 . -
Page 10: Run Configuration
Start-up Methods The Splash Wizard Basic has two sets of dip switches . Only the left side set next to the speed dial (labeled S2) is in use. The top corner of the dip switches says “ON” . If the switches are pushed up toward the top, they are on, otherwise they are off . -
Page 11: Sequence Options
Sequence OPTIONS The Splash Wizard Basic Includes 3 standard programs . Press the control button to cycle through them . 1. All On: Turns all valves on, always . 2. Patterns: Valves are set to run in a specific pattern, pre-programmed by Sapphire Fountains .
