Cellvision Systems RAL SMEARBOX Quick Start

QUICK START - RAL
1. UNPACKING
Items
QuickStart - REF. 22000
Bench Guide - REF. 22005
Protection cardboard
Protection bag
RAL SmearBox instrument
®
RAL SmearBox Slide Spreaders
®
Power supply
2. INSTALLATION
1 - Remove the « Wheel stopper ».
6 - Open the lid and put a blank
slide in the slide receptacle.
Note: Do not put a RAL
SmearBox Slide Spreader or a
blood tube in the device.
3. USE
1 - Put a blood sample tube in
the tube receptacle.
Make sure that the tube
is in position.
5 - Choose an operating mode.
For more details, see
RAL SmearBox Instructions
®
for use Ref.: PM-11056.
Ref. : 22000-V06 Rev: 07/2023
SMEARBOX
®
Quantity
1
1
1
1
1
4x48
1
2 - Close the lid and plug 3
the power supply into the supply and the power cord
RAL SmearBox. (provided by our distributor)
®
before connecting to the
electrical outlet.
7 - Close the lid. 8
button for a minimum of 10
seconds. All mode LEDs turn blue
and the status flashes green.
The running-in cycle begins.
2 - Install carefully a slide up to 3
the stop. in the spreader receptacle.
Check that the frosted part is
directed towards you.
6 - Launch the automatic 7
spreading cycle. the blood smear and the blood
sample tube.
- Connect the power
4
receptacle.
- Press and hold the start 9
LED turns solid green and the
running-in cycle is complete.
- Put a RAL SmearBox Slide Spreader
®
Check that the consumable
is in position.
- Remove the slide with
Remove the
slide carefully.
- Put the waste bin in the 5
is complete and status
LED turns blue.
- After about 30 minutes status 10
the slide.
4 - Close the lid.
- Wait until start-up
- Open the lid and retrieve
