Pyle PYGTWIR06 User Manual

Please read this manual carefully before using.
PRECAUTION
Location
Using the product in the following environments could cause the unit to malfunction:
• Locations with extreme temperature or humidity
• Excessively dusty or dirty environments
Power Supply
Be sure to power o the product when it is not in use. Charge the product when the low
battery light is illuminated. When the product is not used for a long period of time,
charge the unit every six months to extend the cycle life of the batteries.
Interference with other electrical devices
Avoid close proximity with other wireless devices using the same frequency.
Handling
To avoid breakage, please do not apply excessive force to the switch, buttons, or other
controls.
Care
If the exterior becomes dirty, wipe it with a clean and dry cloth. Do not apply liquid
cleaning solutions such as: benzene, diluter, or other cleaners that contain ammable
compounds.
Other Contaminants
Do not set beverages or liquids of any kind close to the unit. If liquid gets into the device,
it may cause a malfunction, re, or electrical shock. Keep the device and charging ports
clean from dirt, metal shavings, sand, lint, and dust to avoid a malfunction.
Keep this owner's manual
After reading this manual, please keep it for later reference.
www.PyleUSA.com
MAIN FEATURES
The Wireless Instrument System consists of two parts:
the Transmitter and the Receiver, which use the 5.8GHz frequency.
1. Suitable for violin, guitar, bass and all instruments with a 6.35mm (¼") audio jack.
2. Four built-in channels.
3. Delay time less than 5.6 ms.
4. Mute function
5. Transmitter and Receiver have large capacity built-in lithium batteries.
6. Multi-way charging mode.
7. Wireless distance: Guaranteed 20 meters (unobstructed) - can reach up to 100 meters.
PARTS NAMES AND FUNCTION
Transmitter
1
2
6
3
7
4
8
5
Transmitter charging for receiver
Transmission working
1. Pairing indicator (orange color). The orange indicator ashes when not paired, and
turns o when paired successfully.
2. Channel indicator (red, green, blue, purple)
3. CHANNEL button. Press the button to switch between di erent channels of wireless
transmission.
4. POWER button
5. Charging port via micro USB cable
6. Audio jack to instrument
7. Magnetic connector.
Charging connection point between the Transmitter and the Receiver.
8. MUTE button. Press and hold for 2 seconds to mute. The sign " " on the screen will
ash. Another press and hold will unmute.
9. Screen. Displays information about battery level, channel ID, etc..
The screen turns o after 10 seconds when successfully paired.
Receiver
9
Mute status
Transmission working Transmitter charging for receiver
www.PyleUSA.com www.PyleUSA.com
1
7
8
2
5
9
6
3
4
All screen contents
