Summary of Contents for AAT Holding KaDe KDA-STRIKE12RN
- Page 1 Installation Manual ELECTRIC STRIKE KDA-STRIKE12RN, KDA-STRIKE12RNM, KDA-STRIKE12SN, KDA-STRIKE12SNM, KDA-STRIKE12S, KDA-STRIKE12SO, KDA-STRIKE12SP, KDA-STRIKE12SOP WERSJA 1.0...
-
Page 2: Preparation For Installation
AC (coil 12V AC) or DC (coil 12V DC or 24V DC). Fail safe electric strike (NO - normally open) and electric strikes dedicated for continuous work (100% ED) should be powered only with direct current (DC coil). All rights reserved. © AAT HOLDING S.A. -
Page 3: Installation
0,5mm² for less than 30 meters or cables with a cross section 1,0mm² for distances greater than 30 m but less than 100m. End of the cable should be connected to the ports SW1, SW2 in the control panel (Fig. 3). Fig 3. All rights reserved. © AAT HOLDING S.A. -
Page 4: Maintenance
The warranty does not cover damage caused by negligence, improper assembly, overexploitation or intentional destruction of the electric strike. Any interference in electric strike will void the warranty. The basis for the recognition of the guarantee is proof of purchase. All rights reserved. © AAT HOLDING S.A. - Page 5 Electric strike – User manual All rights reserved. © AAT HOLDING S.A.
