Laser Sentinel
INSTRUCTION MANUAL
Safety Laser Scanner
PROFINET/PROFIsafe

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LASER SENTINEL and is the answer not in the manual?

Questions and answers

Summary of Contents for Datasensing LASER SENTINEL

  • Page 1 Laser Sentinel INSTRUCTION MANUAL Safety Laser Scanner PROFINET/PROFIsafe...
  • Page 2 Datasensing website (www.datasensing.com). Disclaimer Datasensing has taken reasonable measures to provide information in this manual that is complete and accurate, however, Datasensing shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the use of this material. Datasensing reserves the right to change any specification at any time without prior notice.

  • Page 3: End User License Agreement

    1.5 Any use of the Software outside of the conditions set forth herein is strictly prohib- ited and will be deemed a breach of this Agreement resulting in immediate termination of this Agreement. In the event of a breach of this Agreement, Datasensing will be enti- INSTRUCTION MANUAL...
  • Page 4 (additional) license fees due and any further damages, if any. 2. License Fee License fees shall be due by End User to Datasensing according to the terms provided for in the relevant contract for the purchase of the Datasensing Product.
  • Page 5 Technical Data and Computer Software clause at DFARS 252.227-7013(c)(1)(ii), which- ever is applicable. 8.2 If End User is using the Datasensing Product outside of the United States, End User must comply with the applicable local laws of the country in which the Datasensing Product is used and with U.S.
  • Page 6 11. General Provisions. 11.1. Entire Agreement; Amendment. This document contains the entire agreement between the parties relating to use of the Datasensing Products and the licensing of the Software and supersedes all prior or contemporaneous agreements, written or oral, between the parties concerning the use of the Datasensing Products and licensing of the Software.
  • Page 7 The validity, interpretation and construction of the Agreement shall be governed by and construed in accordance with Laws of the Republic of Singapore. Parties expressly dis- claim the application of the United Nations Convention for International Sale of Goods. Any dispute arising out of or in connection with this contract, including any question regarding its existence, validity or termination, shall be referred to and finally resolved by arbitration administered by the Singapore International Arbitration Centre (“SIAC”) in accordance with the Arbitration Rules of the Singapore International Arbitration Cen-...

  • Page 8: Table Of Contents

    Manual Conventions ........................... xi Technical Support ......................xii Support Through the Website ......................xii GENERAL VIEW....................... XIII Laser Sentinel PROFINET/PROFIsafe ................xiii SLS-M5-PP-BA (Back/Rear connector model) ................xiii SLS-M5-PP-BO (Bottom connector model) ................... xiv LEDs and Indicators ......................xv Model Selection and Order Information ................xvi Connectors used ......................
  • Page 9 SLS-Fieldbus connection ....................39 Machine Interface Connections ......................40 Power Supply Connections ..................... 42 PC Connections ......................42 CHAPTER 7. LASER SENTINEL SETUP AND CONFIGURATION ........43 Installing DLSentinel GUI ....................43 Minimum System Requirements ......................43 Program Installation .........................44 Choosing the Application ....................44 CHAPTER 8.
  • Page 10 Firmware Update ......................109 Checks after Firmware Update ......................110 TECHNICAL DATA ....................111 OVERALL DIMENSIONS ..................116 Laser Sentinel Back Model .................... 116 Laser Sentinel Bottom Model ..................117 ACCESSORIES ......................118 Mounting Brackets ....................... 118 Ethernet Cables ......................119 Electrical Cables ......................

  • Page 11: Preface

    PREFACE ABOUT THIS MANUAL This Instruction Manual is provided for users seeking advanced technical information, including connection, programming, maintenance and specifications. The Quick Refer- ence Guide (QRG) and other publications associated with this product can be down- loaded free of charge from the website listed on the back cover of this manual. Manual Conventions The following conventions are used in this document: The symbols listed below are used in this manual to notify the reader of key issues or...

  • Page 12: Technical Support

    TECHNICAL SUPPORT Support Through the Website Datasensing provides several services as well as technical support through its website. Log on to (www.datasensing.com). For quick access, from the home page click on the search icon , and type in the name of the product you’re looking for.

  • Page 13: General View

    GENERAL VIEW LASER SENTINEL PROFINET/PROFIsafe SLS-M5-PP-BA (Back/Rear connector model) Figure 1 - Back/Rear Model 1. I/O connector (8 poles) 4. Direct Mounting Holes (2) 2. PROFINET/PROFIsafe connectors 5. Bracket Mounting Holes (4) (FBUS1, FBUS2) 3. Ethernet Connector (configuration PC or host)

  • Page 14: Sls-M5-Pp-Bo (Bottom Connector Model)

    GENERAL VIEW SLS-M5-PP-BO (Bottom connector model) Figure 2- Bottom Connector Model 1. I/O connector (8 poles) 4. Direct Mounting Holes (2) 2. PROFINET/PROFIsafe connectors 5. Bracket Mounting Holes (4) (FBUS1, FBUS2) 3. Ethernet Connector (configuration PC or host) SAFETY LASER SCANNER...

  • Page 15: Leds And Indicators

    LEDS AND INDICATORS LEDS AND INDICATORS Figure 3 - Laser Sentinel LEDs and Indicators SYMBOL DEFINITION COLOR MEANING Green No intrusion in any safety zone of the monitored zone set Status of the Orange Intrusion in any of the warning zone of the monitored zone set...

  • Page 16: Model Selection And Order Information

    GENERAL VIEW MODEL SELECTION AND ORDER INFORMATION MODEL DESCRIPTION CODE Laser Sentinel PROFINET/PROFIsafe 5.5m 70 zone SLS-M5-PP-BA 958000012 sets (Back/Rear connector model) Laser Sentinel PROFINET/PROFIsafe 5.5m 70 zone SLS-M5-PP-BO 958000013 sets (Bottom connector model) CONNECTORS USED MODEL CONNECTORS M12 8-poles connector (power, I/O)

  • Page 17: Chapter 1. General Information

    CHAPTER 1 GENERAL INFORMATION GENERAL DESCRIPTION The Laser Sentinel is an electro-sensitive protective equipment (ESPE). It employs active opto-electronic protective devices responsive to the diffuse reflection of a radiation (AOPDDRs), according to the definition and requirements of international safety stan- dard IEC 61496-3.

  • Page 18: Reference Standards And Regulations

    GENERAL INFORMATION REFERENCE STANDARDS AND REGULATIONS The safety laser scanner is a safety system used as an accident-prevention protection device and is manufactured in accordance with the international Standards in force for safety, in particular: STANDARD DESCRIPTION Harmonisation of the laws of the Member States 2014/30/EU EMC Directive relating to electromagnetic compatibility.

  • Page 19: Package Contents

    PACKAGE CONTENTS Package contains the following objects: • Laser Sentinel • Quick Reference Guide of Laser Sentinel • Periodical checklist and maintenance schedule BASIC INFORMATION The user can follow the indications related to typical application configurations that facilitate the device programming. Two types of configuration have been developed on DL Sentinel so far: 1.

  • Page 20: Chapter 2 Typical Applications

    This area cannot be used for safety pur- poses. The possible applications to employ the Laser Sentinel are: Horizontal (to monitor an area that must be crossed in order to reach the hazardous point) and Vertical (to moni- tor an access point).

  • Page 21: Horizontal Application Configuration

    The device uses a horizontal protective field (the red area in the figures) to detect the presence of an object or a person. The Laser Sentinel will scan the environment surrounding the hazardous point to detect approaching objects or people. If someone is detected in the safety zone (with a given detection capability), the safety laser scanner switches all safety outputs to the OFF state through the safety fieldbus protocol.

  • Page 22: Vertical Application Configuration

    TYPICAL APPLICATIONS VERTICAL APPLICATION CONFIGURATION Figure 3 - Vertical application The device uses a vertical protective field (the red area in the figure) to detect someone passing through it. In this example the only way to reach the hazardous point is to pass through an open- ing: all other access points to the machine are protected by some physical barrier or other sensors.

  • Page 23: Chapter 3. Safety Information

    (e.g. motor power supplies, inverters, etc.). • Do not connect any of the Laser Sentinel inputs to DC power sources outside of the declared range or to any AC power source, to avoid the risk of electric shock. INSTRUCTION MANUAL...
  • Page 24 SAFETY INFORMATION • Every access to the configuration tools must be allowed only to restricted and highly qualified personnel. The configuration upload through the GUI is only allowed by password. • Periodically monitor the optical window during the entire product life-cycle check- ing for any damage, scratches or dirt spots.

  • Page 25: Chapter 4. Installation

    CHAPTER 4 INSTALLATION INSTALLATION PRECAUTIONS Make sure that the protection level assured by the Laser Sentinel is com- patible with the danger level of the working machine, according to EN ISO 13849-1 or EN 62061. WARNING • It must not be possible for operators to approach the dangerous zone without being detected by the Laser Sentinel.
  • Page 26 INSTALLATION • Make sure that the Laser Sentinel output window is not obstructed by any object (do not obstruct the front highlighted in the figure below). SAFETY LASER SCANNER...

  • Page 27: Getting Started

    GETTING STARTED Here are the basic steps to start a safety configuration. • Package Contents: Check that the Laser Sentinel and all parts supplied with the equipment are present and intact when opening the packaging (refer to " Package Contents" on page 3 •...

  • Page 28: Light Interference

    INSTALLATION Light Interference Reflecting surfaces located near the safety device may cause passive reflections. These can affect the detection of an object inside the safety zone. The passive light sources can be an incandescent lamp, sunlight, a fluorescent light, a strobe light or other infra- red light sources (e.g.

  • Page 29: Highly Reflecting Background

    If there is a highly reflecting background within 3 meters of the safety zone boundary, e.g. a metallic glossy surface, the Laser Sentinel might fail to recognize the exact dis- tance of the detected object because of an increase in the measure error.

  • Page 30: Zone With Limited Detection Capability

    INSTALLATION ZONE WITH LIMITED DETECTION CAPABILITY Laser Sentinel may not properly detect an object located at a distance of 10 cm or less from the safety zone origin. This zone is called “zone with limited detection capability.” In this circumstance, a risk assessment is recommended taking into account the possi- bility that an object can cross a zone with limited detection capability.

  • Page 31: Device Positioning And Minimum Distance Calculations

    DEVICE POSITIONING AND MINIMUM DISTANCE CALCULATIONS The Laser Sentinel must be carefully positioned to fulfill its safety function. In fact, access to the dangerous area must only be possible by passing through the safety zone. Under standard operating conditions, starting the machine must not be possible while operators are inside the safety area.

  • Page 32: Minimum Safety Distance Calculations For Horizontal Applications

    INSTALLATION Minimum Safety Distance Calculations for Horizontal Applications The Minimum Safety Distance cannot exceed the nominal maximum limit of the Safety Zone for the scanner (5.5 m). NOTE If the device is mounted with a detection angle of less than 30° with respect to the hori- zontal plane (floor), the application is considered horizontal (parallel approach).
  • Page 33 Example of additional distance due to Height: With a given machine stopping time of 0.4 s and a selected Laser Sentinel Response Time of 94 ms, detection capability = 70 mm and without any ambient interference: S = [(1600 mm/s*(0.094 s+0.4 s)] + [(1200 mm –...
  • Page 34 INSTALLATION Example of additional distance due to Ambient Interference: From the previous example with a height of 300 mm, but in the presence of high reflec- tive backgrounds and/or direct bright light: Minimum safety distance S - C = [(1600 mm/s*(0.094 s + 0.4 s)] + (1080 mm + 100 mm) = 1970.4 AMBIENT INTERF = 200 mm for “dust filter level”...

  • Page 35: Minimum Safety Distance Calculations For Vertical Applications

    K = 1600 mm/s or 2000 mm/s (see Note) T = t C = 8(d -14 mm) or 850 mm (see Note) = Response time of the Laser Sentinel (s) (see " " on page 77 = Machine stopping time (s) (see machine specifications)
  • Page 36 Figure 7 - Access protection Figure 7 shows the use of Laser Sentinel as a whole-body safety device where the refer- ence boundary is the edge of the safeguarded aperture. In this application we have to take into account the tolerance zone of the safety laser scanner and the dimensions of a possible unprotected zone due to the physical installation (a), taking additional precau- tions by another means, for example additional mechanical protection.

  • Page 37: Minimum Safety Distance Calculations For Mobile Applications

    DEVICE POSITIONING AND MINIMUM DISTANCE CALCULATIONS Minimum Safety Distance Calculations for Mobile Applications Laser Sentinel can be installed on a mobile machine, e.g. an AGV, in order to constantly monitor the absence of persons along the driving direction of the vehicle, detecting their presence in the safety zone parallel to the direction of approach.
  • Page 38 = Braking distance (depending on vehicle characteristics, load and floor characteristics and condition) = Space traveled during vehicle controller response time = (controller response time) * Speed = Space traveled during Laser Sentinel response time = T * Speed SAFETY LASER SCANNER...
  • Page 39 DEVICE POSITIONING AND MINIMUM DISTANCE CALCULATIONS T = response time of the Laser Sentinel, as set by the user according to the number of scans (see " " on page 77 Also when calculating the minimum width of the safety zone, increases must be taken into account to compensate for possible environmental interference and the increase due to the lack of aperture between the AGV and the floor.

  • Page 40: Unprotected Zone

    INSTALLATION UNPROTECTED ZONE The unprotected zone (a) must be small enough to ensure that a person cannot approach the danger zone or stay between the danger zone and the safety zone without being detected. This can require additional mechanical protection. SAFETY ZONE MACHINERY Figure 9 - Safety Distance Example (Top View)

  • Page 41: Distance To Wall

    DISTANCE TO WALL DISTANCE TO WALL The Safety Zone must maintain a tolerance of at least 40 mm from any wall or fixed object (a and b in the image above). This value is generally enough to guarantee normal operation, however accord- NOTE ing to the real reflectance characteristics of the wall, a higher value may be necessary.

  • Page 42: Devices Orientation

    Specific mounting requirements must be followed to prevent a dangerous failure. • Tilt the Laser Sentinel so that the scanning plane does not enter the output win- dow of any other scanner. Figure 11 - Scanner mounted ad different scanning angles •...
  • Page 43 DEVICES ORIENTATION • Set the devices to different response time. • Install a shielding plate to block scanning signal interference. Figure 13 - Shielding plate between scanners • Make the safety area smaller. INSTRUCTION MANUAL...

  • Page 44: Checks After First Installation

    To test the detection capability of the device(s), the user can use a suitable test piece, e.g. an optically dark, opaque cylinder. The effective diameter should match the configured resolution. Datasensing suggests adopting the following proce- dure: Place the test piece on several points at the edges of the safety area. The safety laser scanner must detect the test piece at each position and go to STOP.
  • Page 45 Test the device by triggering the safety function, e.g. the machine builder can observe the reaction of Safety Outputs on the process image. • For all device applications: check if the Laser Sentinel shows the interruption of the safety field using the LEDs and/or the display. •...

  • Page 46: Chapter 5 Mechanical Mounting

    CHAPTER 5 MECHANICAL MOUNTING For mechanical mounting, the Laser Sentinel has two different procedures depending on the operation necessities. The two mounting possibilities are: • direct mounting, OR • angle adjustment bracket mounting (if the pitch and the roll angles need to be adjusted).
  • Page 47 DIRECT MOUNTING Figure 1 - Direct Mounting Back Model Figure 2 - Direct Mounting Bottom Model The M5 UNI 5933 screws used for mounting the brackets to a wall are not supplied in the SLS bracket mounting kits; they must be supplied by the user.

  • Page 48: Protection Bracket Mounting (Sls-Bracket-C) (Optional)

    Fasten the Protection Bracket (1) on the back of the Laser Sentinel, by using two M5 screws (2) (Maximum 2.9-3.1 Nm Torque).

  • Page 49: Angle Adjustment Bracket Mounting

    ANGLE ADJUSTMENT BRACKET MOUNTING ANGLE ADJUSTMENT BRACKET MOUNTING First, provide two M5 holes with 73 mm spacing on the intended wall or mounting sur- face. The M5 UNI 5933 screws used for mounting the brackets to a wall are not supplied in the SLS bracket mounting kits;...

  • Page 50: Pitch Angle Adjustment Bracket (Sls-Bracket-B)

    MECHANICAL MOUNTING Pitch Angle Adjustment Bracket (SLS-BRACKET-B) Mount the pitch adjustment bracket (3) to the wall or panel by inserting two M5 UNI 5933 screws (not included), and tighten them, repeatedly alternating between one and the other, until they are completely tight. Figure 6 - Pitch Angle Adjustment Bracket SAFETY LASER SCANNER...

  • Page 51: Scanner Mounting And Pitch Angle Adjustment

    SCANNER MOUNTING AND PITCH ANGLE ADJUSTMENT SCANNER MOUNTING AND PITCH ANGLE ADJUSTMENT Make sure to use the specific Torques indicated for the different proce- dures to avoid damaging the device permanently. CAUTION The pitch angle adjustment is a procedure related to both SLS-BRACKET-A and SLS-BRACKET-B.
  • Page 52 MECHANICAL MOUNTING To mount the device with 90° vertical inclination: 1. Mount the Positioning Memory Bracket (8) with the M4 screw (and washer) (9) to the main bracket (3) but do not tighten it. 2. Align the Positioning Memory Bracket with the center of the main bracket slot, then tighten the M4 screw (9) (1.5-1.6 Nm Torque).

  • Page 53: Roll Angle Adjustment

    ROLL ANGLE ADJUSTMENT ROLL ANGLE ADJUSTMENT The roll angle adjustment is a procedure related only to SLS-BRACKET-A. NOTE Rotate the brackets to reach the desired roll angle within the allowed range (+/-8.5 °) and then tighten the M4 Roll Adjusting Screws (5) (1.4 - 1.5 N/m Torque). Figure 9 - Roll Angle Adjustment The memory group is tightened to the scanner with captive screws, so the operator only needs to loosen them to extract it from the scanner.

  • Page 54: Safety Information Regarding Mounting

    MECHANICAL MOUNTING SAFETY INFORMATION REGARDING MOUNTING Make sure that the protection level assured by the Laser Sentinel is compatible with the danger level of the working machine, according to EN ISO 13849-1 or EN 62061. For further information refer to Chapter 4, Installation .

  • Page 55: Chapter 6. Electrical Connections

    CHAPTER 6 ELECTRICAL CONNECTIONS SLS-FIELDBUS CONNECTION Both models of the SLS-Fieldbus include: M12 8-poles connector (machine interface: power supply and configurable inputs/ outputs) (2x) M12 4-poles connector (PLC interface: fieldbus ports) M12 4-poles connector (programming and monitoring of safety laser scanner with Graphic User Interface) INSTRUCTION MANUAL...

  • Page 56: Machine Interface Connections

    ELECTRICAL CONNECTIONS Machine Interface Connections The Laser Sentinel Fieldbus has four signals configurable as inputs/outputs and one sig- nal configurable as input. The pin-out of the standard M12-8 poles connector (Figure 1) is the shown in Table 1. Figure 1 - Connector (M12, 8-pole Male) One pin can be exclusively assigned as input (pin 3).
  • Page 57 SLS-FIELDBUS CONNECTION TYPE FUNCTION DESCRIPTION CONNECTION Active Muting functional signal MUTING LAMP 1 for Safety Zone 1. Connect LED lamp providing it with 24 Vdc ALARM 1 Clean Window MULTI-OUT ALARM 2 Device Error OVERRIDE STA- Status of override for Safety Zone 1 NO FUNCTION Not used...

  • Page 58: Power Supply Connections

    ELECTRICAL CONNECTIONS POWER SUPPLY CONNECTIONS All power connections to the Laser Sentinel must strictly comply with standard regula- tions. The device requires a supply voltage of 24 Vdc. Power must be supplied in accor- dance with SELV/PELV (IEC 60204-1) for all the devices electrically connected to the safety laser scanner.

  • Page 59: Chapter 7. Laser Sentinel Setup And Configuration

    LASER SENTINEL SETUP AND CONFIGURATION This chapter is dedicated to the Laser Sentinel setup and configuration using the DLSen- tinel software. The aim of this chapter is to guide the user through all the fundamental procedures of configuring the device.

  • Page 60: Program Installation

    When the installation is complete, the DLSentinel entry is created in the Start > All Pro- grams menu under “Datasensing” along with a desktop icon. Double-click the desktop icon to run it. A dedicated computer running DLSentinel must be connected to a Safety Laser Scanner through the Ethernet port to perform the configuration and monitoring features.

  • Page 61: Chapter 8. Integration Into The Profinet-Profisafe Network

    CHAPTER 8 INTEGRATION INTO THE PROFINET- PROFISAFE NETWORK The device is suitable for the following network topologies: • Star • Daisy-chain • Tree • Ring Addressing The safety laser scanner needs two IP addresses, one for the DLSentinel configuration (standard ethernet port), one for the FBUS1/FBUS2 ports. The safety laser scanner also requires a PROFINET name and an F-destination address.

  • Page 62: Profinet/Profisafe Data

    The value is 4 octets identical to IM_Signature (I&M4). PROFINET/PROFIsafe data The cyclical data transmission between the controller and the Laser Sentinel is per- formed via the process image. The Safety Laser scanner provides I&M parameters and alarms. SAFETY LASER SCANNER...

  • Page 63: Process Image

    Process image The users can select among different process images through the DLSentinel (F-I/O Data in the Profinet/Profisafe configuration section): • Default: 12 bytes (Input/Output) • 7 bytes (Input/Output) • 12 bytes (Output) • 7 bytes (Output) Input/Output is referred to the Safety Laser Scanner perspective (e.g., process image output is sent by the Safety Laser Scanner to the controller, process image input is sent by the controller to the Safety Laser Scanner).
  • Page 64 INTEGRATION INTO THE PROFINET-PROFISAFE NETWORK The process image input (sent by the PLC to SLS) is represented in the following table (for 7 bytes size): BYTE BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0 Stop Event Reserved...
  • Page 65 The process image input (sent by the PLC to SLS) is represented in the following table (for 12 bytes size): BYTE BIT 7 BIT 6 BIT 5 BIT 4 BIT 3 BIT 2 BIT 1 BIT 0 Stop Event Reserved Shut-off Reserved Wink...
  • Page 66 INTEGRATION INTO THE PROFINET-PROFISAFE NETWORK The content of the process image (referred to 7 bytes input/output) is detailed in the following table: SAFETY PROCESS IMAGE INPUT (FROM PLC TO SLS) SAFETY BYTE.BIT NAME DATATYPE DEFINITION RANGE IMPLIC ATIONS 0: Wink deacti- Activate wink vated Additional...
  • Page 67 SAFETY PROCESS IMAGE INPUT (FROM PLC TO SLS) SAFETY BYTE.BIT NAME DATATYPE DEFINITION RANGE IMPLIC ATIONS Override 0: No Activation Activation (default) Activate Override Zone function for the 0-1: Activate Safety Safety Rele- B4.x (x=0..6) Boolean safety area X of (maximum Override (dura- function...
  • Page 68 INTEGRATION INTO THE PROFINET-PROFISAFE NETWORK SAFETY PROCESS IMAGE OUTPUT (FROM SLS TO PLC) SAFETY BYTE.BIT NAME DATATYPE DEFINITION RANGE IMPLIC ATIONS Status of the optics cover. If 0: no contami- contamination nation error Contamina- Safety error is active (1) Safety Rele- B0.1 Boolean 1: contamina-...
  • Page 69 SAFETY PROCESS IMAGE OUTPUT (FROM SLS TO PLC) SAFETY BYTE.BIT NAME DATATYPE DEFINITION RANGE IMPLIC ATIONS 0: Intrusion in Status of the the Safety zone Status Safety Rele- Safety safety zone X of (or Lockout) B2.x (x=0..7) Safety Zone Boolean function the monitored vant...

  • Page 70: Chapter 9 Functions

    The detection capability is the ability to detect an object of given dimensions within the detection zone. In particular, for the Laser Sentinel, the test piece taken as reference is an opaque cylinder with at least 300mm height and the diameter equal to the detection capability measured in millimeters.

  • Page 71: Response Time And Scan Cycle Setting

    RESPONSE TIME AND SCAN CYCLE SETTING RESPONSE TIME AND SCAN CYCLE SETTING The response time of the SLS is the time from when an object enters the safety zone to when the safety output goes to the safe state due to the detection of the object. The SLS scans cyclically the surrounding area at constant speed.

  • Page 72: Anti-Interference Coding

    WARNING If the application requires changes, this may require reconfiguration of the safety zones or re-installation of the Laser Sentinel. NOTE ANTI-INTERFERENCE CODING Anti-interference coding allows using four different emission modes to minimize inter- ference among scanners working in the same environment.

  • Page 73: Dust Filtering

    INPUTCFx error may occur. Laser Sentinel allows the user to set up to 70 Zone Sets. Only one Zone Set can be acti- vated at a time by using the “Area Switch No.” byte of the Process Image. When it changes, the new Zone Set assigned to this new combination will be monitored.
  • Page 74 FUNCTIONS admissible Zone Set is the first one, otherwise, if Zone Set No. is set to 0, the error INPUTCF2 is shown on the display. To start the Zone Set switching on the device, the user must: • Configure at least two Zone Set No. •...

  • Page 75: Reference Points Monitoring Settings

    Example application for movable structure protection When the reference points (minimum 3), are set on the position of a movable structure, such as a door, the safety outputs go in safe state if the Laser Sentinel detects a change in the position of the door.

  • Page 76: Dynamic Reference Point

    GUI gives a warning message indicating that this configuration is not valid for whole body protection applications (greater than 1.6 m/s). To safely apply the Laser Sentinel in applications with normal approach (i.e. when the monitored plane is vertical), refer to IEC 61496-3 Annex A.12.

  • Page 77: Automatic And Manual Restart

    AUTOMATIC AND MANUAL RESTART AUTOMATIC AND MANUAL RESTART If Laser Sentinel detects an opaque object, the Safety Outputs switch to the safe state (SafetyStatusZoneX = 0). The restart mode allows the safety laser scanner to return to a normal operating condition.
  • Page 78 FUNCTIONS There are two intermediate states (internally controlled) between the stop and the restart of the safety laser scanner: • the Interlock Status ON (device normal operation can be restored because the detected object has been removed from the Safety zone) •...
  • Page 79 AUTOMATIC AND MANUAL RESTART FREE SAFETY AREA X INTERCEPTED InterlockReqZoneX SafetyStatusZoneX RestartSafetyZoneX T_min_Restart <t<T_max_Restart t<T_min_Restart Figure 3 - Restart timing (fieldbus) Timings of restart function activations can be evaluated according to the following val- ues: • T_min_restart = 0.5 s •...

  • Page 80: Reset

    FUNCTIONS RESET Reset is a function that allows restoring normal operation after a failure lockout condi- tion, due to system error, without disconnecting the power supply. The aim of the Reset is to return the system to a power-on phase, by resetting all the variables and starting a new integrity test session.

  • Page 81: Muting

    MUTING MUTING The Muting feature allows the automatic deactivation of the safety status overall (Total Muting) or part (Partial Muting) of the safety area. This feature is particularly suitable when an object, but not a person, must pass through the dangerous area. This allows carrying out definite cyclical operations without blocking a working machine.

  • Page 82: Muting Signaling Devices

    FUNCTIONS Carefully select the configuration, because a wrong one can cause the incorrect functioning of the Muting feature and a reduction of the safety level. To correctly use the Muting feature, please refer to the relevant ref- WARNING erence standard. The Muting sensors must be placed so that during the activation of the Muting feature it is not possible for a person to pass through the desired zone.
  • Page 83 (V): d2max[cm] = V[m/s] * T12[s] * 100, where “T12” is the delay between Muting 1 and Muting 2. The user should select the minimum value of T12 max (DLSentinel, parameter Max Muting Inputs Delay) that guarantees the Muting function. Laser Sentinel 24Vdc 24Vdc ESPE...

  • Page 84: Unidirectional Muting

    The figure below shows this operation: the pack moves from the right to the left only. “V” indicates a constant speed; therefore, “d1” is a fixed value according to the follow- ing formula: d1[cm] = V[m/s] * T12[s] * 100 24Vdc ESPE Laser Sentinel MUTING1 24Vdc MUTING2 SAFETY LASER SCANNER...

  • Page 85: Configuring The Muting Function On Dlsentinel

    MUTING Configuring the Muting Function on DLSentinel To enable the Muting function on DLSentinel and configure the Muting area, follow the procedure below: 1. On the Output Configuration page, set the Muting Function to ENABLED. If Muting sensors connected to the SLS are used for Safety Zone 1, set to ENABLED the Phys- ical Configuration.
  • Page 86 FUNCTIONS 3. On the Zone Configuration page, first draw your Safety Area, the click on Muting label in the panel on the left side. A warning message is display informing the user that any change to the Safey Area will remove the Muting zone. Click OK to pro- ceed.
  • Page 87 MUTING 5. If a Total Muting Zone was created, the Muting zone (colored blue) will overlap the Safety Area, as illustrated in the picture below. 6. A Total Muting zone can be turned into a Partial Muting zone by dragging and dropping the points of the shape.

  • Page 88: Override

    FUNCTIONS OVERRIDE The Override feature allows the use to force the safety output to ON state (SafetySta- tusZoneX = 1) whenever it is necessary to restart the machine. The aim is clearing the protected area of any working materials blocked ahead of the device, because this inter- ference may cause a work cycle anomaly.
  • Page 89 OVERRIDE Single Line Pattern The input sequence to be followed for activation is indicated in the figure below: FREE SAFETY ZONE INTERCEPTED OVERRIDE STATUS FELEASED (24Vdc) OVERRIDE SINGLE LINE PATTERN PRESSED (0Vdc or floating) <1s <1s <1s <1s <1s >1s Level Triggered Pattern The input sequence to be followed for activation is indicated in the figure below: OVERRIDE...
  • Page 90 FUNCTIONS Edge Triggered Pattern The input sequence to be followed for activation is indicated in the figure below: OVERRIDE CONDITIONS 24Vdc OVERRIDE2 0Vdc 24Vdc OVERRIDE1 0Vdc OVERRIDE STATUS t<400ms t<400ms Please not that when you enable Override, you disable the safety function on the relevant safety zone and for all Zone Sets.

  • Page 91: Shut-Off

    SHUT-OFF SHUT-OFF The Shut Off function allows energy saving, which can be particularly useful when the Safety Laser Scanner is used in battery-powered applications (e.g., AGV9). When the Safety Laser Scanner is in Shut Off status, some of its functions are deacti- vated, but the device is still active and ready to restore to normal operation when needed.

  • Page 92: Safety Report Generation And Acceptance

    FUNCTIONS SAFETY REPORT GENERATION AND ACCEPTANCE The Safety Report is a file that sums up all the parameters selected for a configuration and is generated by the GUI after creating a configuration. The Report file is displayed on the right side of the panel. It is possible to save it as a PDF file and print it.

  • Page 93: Stop Event Report

    STOP EVENT REPORT STOP EVENT REPORT It is possible to limit the generation of the events in the diagnostic log (see " Diagnostic ) using the bit2 of byte0 “Stop Event Report” of the process image input Log" on page 89 (from PLC to SLS).

  • Page 94: Chapter 10 Diagnostics

    CHAPTER 10 DIAGNOSTICS ALARMS ON OUTPUT PIN In the Output configuration page of DLSentinel, it is possible to associate two alarms function to physical pins: Clean Window: activation indicates that the optic cover status is contaminated. The dis- play will show the icon CLEANW1 and the safety outputs go to safe state. The status of the optical window can be also monitored through the process image output (from SLS to PLC) on bit1, byte0 (“Contamination Error”).

  • Page 95: Monitoring By Display

    MONITORING BY DISPLAY MONITORING BY DISPLAY DISPLAYED ICON NAME DESCRIPTION Configuration Configuration valid pending acceptance The device is correctly func- tioning. No presence ON State detected in the Safety and Warning Area. The device is correctly func- Warning for tioning. The device has intrusion into WARNING WARN...

  • Page 96: Diagnostic Notes, Warnings, And Errors

    DIAGNOSTICS DIAGNOSTIC NOTES, WARNINGS, AND ERRORS SAFETY DISPLAYED DISPLAYED DEVICE ZONE DESCRIPTION ICON FAULT CODE STATUS STATUS DLDNF NORMAL Downloading new firmware. DLDNC NORMAL Downloading new configuration. It is suggested to clean the window CLEANW2 NORMAL to avoid entering lockout condition. CLEANW Interlock.
  • Page 97 DIAGNOSTIC NOTES, WARNINGS, AND ERRORS SAFETY DISPLAYED DISPLAYED DEVICE ZONE DESCRIPTION ICON FAULT CODE STATUS STATUS OVERRIDE NORMAL The Override function is active OVERRIDE The external temperature is above OVERTEMP NORMAL the limit. OVERTEMP The Override timeout function has OVR TIMEOUT NORMAL expired.
  • Page 98 DIAGNOSTICS SAFETY DISPLAYED DISPLAYED DEVICE ZONE DESCRIPTION ICON FAULT CODE STATUS STATUS The device is waiting for Zone Set WAIT FOR INPUT NORMAL No. from PLC. Window needs to be cleaned. Repeat this action until the normal CLEANW1 NORMAL condition is restored. Otherwise contact our Technical Support to CLEANW1 replace the damaged part.
  • Page 99 DIAGNOSTIC NOTES, WARNINGS, AND ERRORS SAFETY DISPLAYED DISPLAYED DEVICE ZONE DESCRIPTION ICON FAULT CODE STATUS STATUS The Master device has no configu- ration stored on board. Create a DEVICE EMPTY BOOT new configuration from GUI or restore the configuration from the DEVICE EMPTY Memory Group.
  • Page 100 DIAGNOSTICS SAFETY DISPLAYED DISPLAYED DEVICE ZONE DESCRIPTION ICON FAULT CODE STATUS STATUS If the safety conditions have not been restored after the fast replace- RES ABORT BOOT ment restore phase, the user can abort the restore phase and create RES ABORT a new configuration via GUI.

  • Page 101: Anti-Tamper Function

    ANTI-TAMPER FUNCTION ANTI-TAMPER FUNCTION The SLS continually monitors for conditions caused by tampering in the work area and/ or the device itself that may create interference or improper operation leading to a potential loss or reduction of the safety function. Once these conditions are found, the device is forced to STOP and the display indicates this until the conditions cease.

  • Page 102: Safety

    DIAGNOSTICS SAFETY Hazard due to lack of effectiveness of the safety device. Operators to be protected may not be recognized in case of nonobservance. WARNING • Immediately put the machine out of operation if the behavior of the machine can- not be clearly identified.

  • Page 103: Leds And Display

    LEDS AND DISPLAY LEDs AND DISPLAY The safety laser scanner is equipped with three lateral buttons, a graphical display and five status LEDs located below the display. Diagnostic and Status LEDs The safety laser scanner has diagnostic LEDs for initial diagnostics. The OFF state and ON state LEDs can be found below the safety laser scanner display.

  • Page 104: Display Menu

    DIAGNOSTICS Display Menu To enter the Display Menu, push the squared button. By using the up and down arrows button, it is possible to browse the menu. To select an area, press the squared button. To exit every menu option, push the squared button after selecting it. The menu is divided into three main areas: Information, Settings and Exit: INFORMATION Device Name...

  • Page 105: Diagnostics Using The Display

    DIAGNOSTIC LOG Diagnostics Using the Display The display supplies information about the status of the safety laser scanner, and for diagnostics and troubleshooting. The refresh rate of the display is slower than the switching rate of the safety outputs. Therefore, it may occur that the display may not be syn- chronized with the safety outputs in the case of rapidly switching states.
  • Page 106 DIAGNOSTICS A log file in .csv format will be created. DLSentinel will prompt you to select a folder where the log file will be saved. After clicking Save, the following information window is displayed: Once the log file creation is completed, the following information window is displayed: You can now view your log file.
  • Page 107 DIAGNOSTIC LOG The following categories of logged events are included: • Output events (intrusions into safety areas) • Input events (Muting and Override events) • Fault events • Update events (e.g. new firmware, new configuration, etc.) • Fast Replacement events •...

  • Page 108: Periodical Checks

    If any of these checks are not verified, it is not allowed to continue to work on the machine. In this case the installation of the laser Sentinel must be checked by qualified safety personnel and tested following the “CHECKS AFTER FIRST INSTALLATION” proce- dure as indicated.

  • Page 109: Chapter 11. Device Maintenance

    DEVICE MAINTENANCE GENERAL INFORMATION AND USEFUL DATA The Laser Sentinel does not include any repairable components; avoid repairing or replacing device parts not mentioned in this manual. Failing to observe this instruction may cause malfunction due to severe device damage.

  • Page 110: Window Cleaning

    DEVICE MAINTENANCE WINDOW CLEANING The Laser Sentinel optical window needs periodical cleaning, and the frequency depends on the type of environment in which the device operates. Contamination of the optical window (due to dust, oil, etc.) in the presence of background reflection may impair the detection capability of the safety laser scanner.
  • Page 111 WINDOW CLEANING It is necessary to clean the underside of the end cap (the black surface under the yellow cap on top of the scanner). NOTE INSTRUCTION MANUAL...

  • Page 112: Window Replacement

    Order the replacement window from Datasensing and carefully follow the procedure below. In all other cases, please contact Datasensing for device repair or replacement. Warning Terms - Disclaimer for Window Replacement and Calibration PLEASE READ CAREFULLY THIS STATEMENT. BY REPLACING AND CALI- BRATING THE WINDOW, YOU ACKNOWLEDGE AND ACCEPT THE FOLLOWING WARNING TERMS.

  • Page 113: Prerequisites For Window Replacement

    THE POTENTIAL RISKS AND LIABILITIES ARISING FROM THE WINDOW REPLACEMENT PROCEDURE, AS WELL AS FROM FAILURE TO COMPLY WITH THE INSTRUCTIONS PRO- VIDED BY DATASENSING IN THIS RESPECT. TO THE FULLEST EXTENT PERMITTED BY LAW, DATASENSING (AND ITS DIRECTORS, OFFICERS, AFFILIATES) SHALL NOT BE HELD LIABLE...

  • Page 114: Window Replacement Procedure

    DEVICE MAINTENANCE Window Replacement Procedure After establishing that the replacement of the optical window is necessary and after making sure that all above-mentioned prerequisites are met, start the window replace- ment procedure. The new optical window package contains the following parts: •...
  • Page 115 WINDOW REPLACEMENT Take the utmost care to avoid touching or damaging the internal parts of the device. CAUTION 4. Remove the seal positioned on the device body. Avoid touching or damaging the internal parts of the device. After removing the damaged window, avoid contaminating all the internal optical parts with fingerprints, dirt, scratches, dust, and polluting agents.
  • Page 116 DEVICE MAINTENANCE 7. Snug the 4 Tuflok® screws down (do not overtighten them). Use a 2.5x100 ball- end hex screwdriver with a shank long enough to avoid damaging the optical win- dow. 8. Tighten the screws with a torque wrench (tightening torque 0.6 Nm, bit 2.5 mm). 9.

  • Page 117: New Window Calibration

    WINDOW REPLACEMENT New Window Calibration A 2-meter free area around the 275° angle range of the Laser Scanner is necessary to calibrate and validate the new optical window. Keep this area free for the whole duration of the procedure. NOTE 10.
  • Page 118 DEVICE MAINTENANCE 13. Select the device undergoing window replacement and enter the serial number of the new window. 14. Window calibration will start now. Make sure that the device has a 2-meter free area around its 275° angle range. When window calibration is in progress, the device first switches to offline status (black display), then to offline test mode, displaying the following message.
  • Page 119 WINDOW REPLACEMENT 15. If the test area is not compliant, an error message will be displayed. Clear the required area and retry. 16. To validate the calibration procedure, the user must test the device detection capability with a test configuration. INSTRUCTION MANUAL...
  • Page 120 DEVICE MAINTENANCE The test area is automatically configured. To test the detection capability of the device(s), use a suitable test piece, e.g. an optically dark, opaque cylinder, with a diameter of 40 mm. Place the test piece on several points at the edges (distance from the device = 1 meter) of the 275°...
  • Page 121 DLSentinel displays the following error message. NOTE Repeat the procedure described above. Should the calibration fail again, replace the window or contact Datasensing to repair or replace the device. 17. After window calibration has successfully completed, the following fault message is displayed. Click OK.
  • Page 122 DEVICE MAINTENANCE The device display will show the “Commit On Field” warning message. COMMIT ON FIELD 18. Restore the Safety Laser Scanner on field. See , and Chapter 4 Chapter 5 Chapter 6 Perform a field test to commit the configuration (see " Checks After First Installa- ), then go to Scanner>Window Replacement and click “Done”...

  • Page 123: Fast Replacement

    FAST REPLACEMENT FAST REPLACEMENT Fast replacement allows the user to quickly replace a device or a Memory Group when these have suffered irreparable damage (see Chapter 10 The user is recommended to contact our Technical Support before perform- ing Fast Replacement to assess the severity of the damage. NOTE This procedure must be performed by authorized personnel only.

  • Page 124: Fast Replacement Of The Safety Laser Scanner

    ), then restore power to the device; Chapter 5 2. If the new Device has no configuration stored (e.g., it comes from Datasensing fac- tory), the device display will show the “DEVICE EMPTY”. The Device can be aligned with the Memory Group configuration either - with a restore configuration (“Restore cfg”) copied from the Memory Group to...

  • Page 125: Firmware Update

    5. In the Firmware update section (Package section), click on ZIP Archive to search and select a previously downloaded new firmware version (from the Datasensing website). 6. Once the new firmware version is selected, click on Load (Configuration Upload).

  • Page 126: Checks After Firmware Update

    Graphic User Interface of the laser scanner. • Check if the Laser Sentinel shows the interruption of the safety field through the LEDs and/or display. • It is recommended to follow the same testing approach of detection capability mentioned before also for different safety areas, checking if the device reaction is as expected.

  • Page 127: Technical Data

    APPENDIX A TECHNICAL DATA PHYSICAL CHARACTERISTICS Protection class III (EN 61140 / IEC 61140) Supply voltage (Uv) 24 Vdc (16.8 Vdc...28.8 Vdc) (SELV/PELV) Residual ripple ± 5% Start-up current (1) < 0.6 A To meet the requirements of the relevant product standards (e.g. EN 61496-1), the external voltage sup- ply for the devices (SELV) must be able to bridge a brief mains failure of 20 ms.
  • Page 128 TECHNICAL DATA OUTPUT (WARNING AND GENERIC) Output logic and protection PUSH-PULL, Overcurrent protection Output voltage for ON status (HIGH) ≥Uv-1.5V @ 400 mA Output voltage for OFF status (LOW) ≤ 0.4V Output current for ON status (HIGH) max. 300 mA Leakage current <...
  • Page 129 MECHANICAL DATA Dimensions (W × H × D) 112.5 x 152 x 102 Weight (including system plug) 1.5 kg Housing material Aluminum Alloy Housing color YellowRAL1003 Optics cover material Optics cover surface Acrylic ENVIRONMENTAL DATA Max 95% non-condensing According to Humidity IEC 61496-1 5.4.2 IEC 61496-3 5.4.2;...
  • Page 130 TECHNICAL DATA FEATURES 5.5 m Models 0.05 … 5.5 m for 70/150 mm of detection capa- bility 0.05 … 4 m for 50 mm of detection capability Safety protective zone range 0.05 … 3 m for 40 mm of detection capability 0.05 …...
  • Page 131 Maximum homogeneous contamination of the optics cover without preventing the detection - 30% of nominal optic power capability SAFETY DATA Type Type 3 (EN 61496-1) Safety integrity level SIL 2 (IEC 61508) Category Category 3 (EN ISO 13849-1) Maximum SIL SIL 2 (EN 62061) Performance level PL d (EN ISO 13849-1)

  • Page 132: Overall Dimensions

    APPENDIX B OVERALL DIMENSIONS LASER SENTINEL BACK MODEL SAFETY LASER SCANNER...

  • Page 133: Laser Sentinel Bottom Model

    LASER SENTINEL BOTTOM MODEL LASER SENTINEL BOTTOM MODEL INSTRUCTION MANUAL...

  • Page 134: Accessories

    APPENDIX C ACCESSORIES MOUNTING BRACKETS MODEL DESCRIPTION CODE SLS-BRACKET-A Complete bracket system 95ASE2920 SLS-BRACKET-B Pitch regulation bracket system 95ASE2930 SLS-BRACKET-C Head protective bracket 95ASE2940 Figure 1 - Kit A Figure 2 - Kit B Figure 3 - Kit C SAFETY LASER SCANNER...

  • Page 135: Ethernet Cables

    ETHERNET CABLES ETHERNET CABLES MODEL DESCRIPTION CODE CAB-ETH-M01 M12-IP67 ETHERNET Ethernet cable to Host 1 m 93A051346 CAB. (1M) CAB-ETH-M03 M12-IP67 ETHERNET Ethernet cable to Host 3 m 93A051347 CAB. (3M) CAB-ETH-M05 M12-IP67 ETHERNET Ethernet cable to Host 5 m 93A051348 CAB.

  • Page 136: Safety Units

    ACCESSORIES SAFETY UNITS MODEL DESCRIPTION CODE SE-SR2 Safety Unit 95ACC6170 CSME-03VU24-Y14 Forcibly guided relay interface 95ASE1270 The CSME interface requires the activation and correct wiring of an EDM signal on the Safety Laser Scanner. NOTE MAINTENANCE ACCESSORIES MODEL DESCRIPTION CODE SLS-WINDOW Replacement window 95ASE2971...

  • Page 137: Glossary

    APPENDIX D GLOSSARY NAME DESCRIPTION Active opto-electronic A device whose sensing function is performed by optoelectronic protective device emitting and receiving elements. These detect the diffuse reflec- responsive to diffuse tion of optical radiations generated within the device by an reflection (AOPDDR) object located in a detection zone (specified in two dimensions).
  • Page 138 A High Dust Filter Level is used in dirty environments to filter (ignore) detection of airborne particles from being confused with objects to detect. The Laser Sentinel is less sensitive to Dust Filtering dust and therefore avoids shutting down the machinery unnec- essarily.
  • Page 139 This number depends on the parameter set in the configuration. State in which the output circuit is interrupted and does not per- mit the flow of current. When Laser Sentinel detects an object in OFF-state the safety zone it switches to this state which causes the dan- gerous machinery to stop working.
  • Page 140 This is the area around the Safety Zone; the device can signal a Warning Zone warning lamp or siren if it detects an object in this area. This is an area (zone) that is controlled by the Laser Sentinel. Zone Set More than one zone can be defined and therefore switched (set) by a combination of inputs.
  • Page 141 NOTES INSTRUCTION MANUAL...
  • Page 142 GLOSSARY SAFETY LASER SCANNER...
  • Page 144 © 2024 Datasensing S.r.l. • All rights reserved • Without limiting the rights under copyright, no part of this documentation may be reproduced, stored in or intro- duced into a retrieval system, or transmitted in any form or by any means, or for any purpose, without the express written permission of Datasensing S.r.l.

This manual is also suitable for:

Sls-m5-pp-baSls-m5-pp-bo

Table of Contents
