Lippert User Manual
Operation
The leveling system should only be operated under the following conditions:
1. The coach is parked on a reasonably level surface.
2. The coach parking brake is engaged.
3. The coach transmission should be in the park position.
4. Make sure all persons, pets and property are clear of the coach while LCI Class C Hydraulic Leveling System is in
operation.
Caution: After starting the automatic leveling cycle it is very important that you do not move around in the
coach until the coach is level and the green LED light illuminates in the center of the touchpad. Failure to
remain still during the leveling cycle could have an effect on the performance of the leveling system.
Selecting A Site
When the coach is parked on an excessive slope, the leveling requirements may exceed the jack lift stroke capability.
For angles greater than 1.0 degree, leveling blocks and jack pads may be required in order to level properly. If the coach
is parked on an excessive slope, the coach should be moved to a more level surface before the leveling system is
deployed. "EXCESS ANGLE" will appear on the LCD screen if the coach is 3.5 degrees out of level from front-to-rear, or
side-to-side.
Note: Leveling blocks and jack pads may be needed to achieve proper leveling if front to rear angles exceed
1 degree when the 4" maximum extension of the jack may not be enough.
Warning: While utilizing leveling blocks and jack pads, all the wheels MUST NOT leave the ground during the
leveling of the coach. Lifting all the wheels off the ground creates an unsafe condition that could result in
death, serious personal injury, severe product or property damage or voiding of the component warranty.
Zero Point Calibration
Before auto-leveling features can be made available, the Zero Point MUST be set. This is the point to which the system
