PRIMA

THE MULTIFUNCTIONAL

SMART TOUCH PANEL

#Reimaginetheswitch

Table of Contents

Need help?

Do you have a question about the PRIMA and is the answer not in the manual?

Questions and answers

Summary of Contents for hogar PRIMA

Page 1 PRIMA THE MULTIFUNCTIONAL SMART TOUCH PANEL #Reimaginetheswitch...
Page 3 Smart Spaces. Thank you for trusting us with your space & choosing the Prima Touch Panels. This manual is designed to help you install your Prima Touch Panels in an easy and hassle-free manner. Please follow the manual and experience the safety...
Page 4: Table Of Contents
TABLE OF CONTENTS USAGE NOTICE 1.1. Warnings and Considerations 1.2. Precautions PRODUCT DETAILS 2.1. Description 2.2. Features 2.3. Contents in the Box 2.4. Prima Touch Panels 2.5. Technical Speciﬁcations INSTALLATION 3.1. Pre-Installation Mandatory Checklist 3.2. Installation & Conﬁguration Steps 3.3. Setup WARRANTY...
Page 5: Usage Notice
USAGE NOTICE 1.1. WARNINGS AND CONSIDERATIONS Caution symbols highlighted across the manual represent the following: Indicates highlighted precautions/warnings that MUST be followed to prevent any serious problems. Indicates the instructions to be followed during the installation. Indicates suggestions and tips. Please follow the notices to ensure your safety as well as to prevent property loss.
Page 6 Using this product in any manner other than how it is referred to in this document VOIDS your warranty. Further, Hogar Controls is NOT liable for any damage incurred due to the misuse of the product. DO NOT use an electric screwdriver to install this...
Page 7: Precautions
1.2. PRECAUTIONS Ensure the below DOs & DON'Ts are adhered to enjoy a seamless product experience: DOs: - Locate the antenna far from the metal elements. DON'Ts: - DON'T cut the antenna. - DON'T connect loads more than the recommended load rating in technical speciﬁcations below.
Page 8: Product Details
PRODUCT DETAILS 2.1. DESCRIPTION A Prima Touch Switch operates independently or as part of the Hogar Controls Smart Home System or with any certiﬁed Z-WAVE smart home system. It can be operated either in a bi-stable Relay mode or Touch Pulse mode for Scene Control with a maximum load current of 5A per each channel.
Page 9: Prima Touch Panels
2.4. PRIMA TOUCH PANELS 1 TOUCH PANEL 2 TOUCH PANEL 3 TOUCH PANEL...
Page 10 4 TOUCH PANEL 4+1 TOUCH PANEL 8 TOUCH PANEL...
Page 11 10 TOUCH PANEL 10+1 TOUCH PANEL 10+2 TOUCH PANEL...
Page 12: Technical Specifications
2.5. TECHNICAL SPECIFICATIONS 1,2,3,4 Touch: 2 Modular British Standard 4+1 Touch: 4 Modular British Standard Gang Box 8,10 Touch: 6 Modular British Standard Sizes 10+1 Touch: 8 Modular British Standard 10+2 Touch: 12 Modular British Standard Power Rating 60 HZ to 50 HZ 2 Module: 95 x 95 x 34.2 mm 4 Module: 162 x 95 x 34.2 mm Dimensions...
Page 13: Installation And Setup
2.5. TECHNICAL SPECIFICATIONS Storage -4°F to 158°F or 20°C to 70°C Temperature Humidity 0 - 90% Wireless 50m Outdoor - 30m Indoor Range Radio Protocol, Z - Wave Plus, 1mW Power Radio IN - 865.2 MHz | EU - 868.4 MHz Frequency BR/AU - 921.4 MHz | US - 908 MHz INSTALLATION &...
Page 14: Installation & Configuration Steps
Step 1: Remove the old faceplate or switchboard (if any) by unscrewing it from the wall. Step 2: Strip all the wires to the appropriate length, i.e., 5/8th of an inch from the wire end. Step 3: Open the frame of the Prima Touch Switch as shown below.
Page 15 - Step 4: Connect the wires to the appropriate terminals as per the diagram below. Make sure the wires of the cable are properly screwed to avoid loose connections. 1 TOUCH PANEL CONNECTION 2 TOUCH PANEL CONNECTION 3 TOUCH PANEL CONNECTION 4 TOUCH PANEL CONNECTION...
Page 16 Lorem ipsum 4+1 TOUCH PANEL CONNECTION 8 TOUCH PANEL CONNECTION...
Page 17 10 TOUCH PANEL CONNECTION 10+1 TOUCH PANEL CONNECTION...
Page 18 10+2 TOUCH PANEL CONNECTION L - Terminal for Live Lead I, II – Loop for Live Wire N - Terminal for Neutral Lead 1,2,3,4,5,6,7,8,9,10 Output Terminals for Individual Loads...
Page 19: Setup
TIP: If you are using the Hogar push-on (screwless) faceplate in a multi-gang installation, attach the back of the faceplate i.e., a sub-plate to all the devices that should be installed into the wall box before attaching the Prima Touch Faceplate.
Page 20 - Remove the glass faceplate. - Hold the conﬁguration button provided on the front PCB using the head of a screwdriver for about 5 seconds until the Touch Button LED blinks 3 times in PINK color. Release the button when all the LEDs turn to PINK color.
Page 21 Adjusting the backlight intensity Click on the conﬁguration button continuously for 8 seconds to adjust (increase or decrease) the backlight intensity to either 80% or 30%. Adding Touch Switch to Controller - Keep the device within Z-WAVE range and set the Home Controller in Add / Include Mode to Add (refer to the Controller manual).
Page 22: Warranty
Warranty Hogar offers an Exclusive 18-Month Warranty on any product that covers defects in materials and quality under normal use of the Product. The Terms and Conditions of this 1.5 YEARS LIMITED WARRANTY can be viewed on www.hogarcontrols.com or scan the QR code:...
Page 23 You've successfully installed your Prima Touch Panels. Now you can experience seamless control of your Prima Touch Panels with your Hogar Pro App. Add more to your home from our range of smart home solutions and live the smart life.
Page 24 Hogar Controls Inc, 46040 Center Oak Plaza, Suite 125, Sterling, Virginia 20166 | Phone : +1 703 844 1160 INDIA Techno-1, Khajaguda X Road, Radhe Nagar, Rai Durg, support@hogarcontrols.com Telangana 50008. www.hogarcontrols.com Phone : +91 844 844 0789...
