O p e r a t i o n M a n u a l
G X - 6 5 G r i n d e r

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GX-65 and is the answer not in the manual?

Questions and answers

Related Manuals for XINGYI GX-65

Summary of Contents for XINGYI GX-65

  • Page 1 O p e r a t i o n M a n u a l G X - 6 5 G r i n d e r...

  • Page 2: Table Of Contents

    GX65 Floor Counter Rotary Grinder Manual 1. Introduction 1.1 Summary 1.2 Responsibility 1.3 Accessories 1.4 Package acceptance 1.5 Machine name plate 1.6 Handling and storage 1.7 Warranty items 2. Safety Instructions 2.1 Overview 2.2 Operational safety guidance 2.3 Electrical safety guidance 3.
  • Page 3 5.2.4 Note 5.3 Cleaning 5.3.1.Clean switch 5.3.2 Clean the grinding disc cover 5.3.3 Clean up the grinding disc and conversion block 5.3.4 Note 5.4 Overload protection 5.5 Maintenance 6. Frequently Asked Questions and Solutions 7. Technical Data 8. Warranty...

  • Page 4: Responsibility

    1. Introduction 1.1 Summary Xingyi machine are used to handle the floor surface. The scope of use of the machine depends on the choice of the tool. In addition to the use and general functions, this manual describes information on the use, repair and maintenance of the grinder. You can contact your local retailer for further information.

  • Page 5: Machine Name Plate

    For complete information on the manufacturer's warranty period, please refer to the current warranty terms of Xingyi. Local retailer may has special warranty terms. If you have any uncertainty about the warranty terms,...

  • Page 6: Safety Instructions

    All maintenance must be done by qualified professional technician. Any machine parts that need to be changed must be provided by XINGYI. Xingyi machines only can be used in the way of xingyi recommended. And they only can be used for commercial purposes.

  • Page 7: Operational Safety Guidance

    10. Ensure no explosive flammable materials and steam nearby when operate machine. Do not operate machine nearby the place with fuel, grain dust, solvents, dilution agent or other flammable items. 2.2 Operation safety guidance 1. Operators should wear protective equipment when using the machine, such as dust masks, protective gloves, overalls, helmets, insulated shoes and so on.

  • Page 8: Electrical Safety Guidance

    results in the input power and working power is not the same, then manufacturers warranty is unavailable.) 15. Connecting with vacuum to achieve dust free working condition. 16. Install appropriate abrasive. Improper abrasive may cause personal injury and floor damage. 17.

  • Page 9: Machine Description

    When dry grinding, In order to being exposed to air and posing a threat to the health of the operator and nearby people.Make sure that the vacuum cleaner is connected to grinder (equipped with a vacuum cleaner manufactured by Xingyi makes better effect) Due to inhalation of dust is harmful in the course...
  • Page 10 Dust is harmful, so please wear protectively. The machine can used with different Xingyi abrasive. Due to the different ground materials, the abrasive discs used in grinding are also different.

  • Page 11: Parts Description

    3.2 Parts description 1. Operating handle 12. Frame 2. Control panel 13. Additional weight iron 3. Motor governor 14. Wheels 4. Start button 15. Grinding plate 5. Emergency stop button 16. Gear box 6. Display screen 17. Velcro-iron accessories 7. Water tank 18.

  • Page 12: Swing Lever Assembly

    3.3 Swing lever assembly 3.3.1 Overview 1. Swing lever angle adjustment handle: adjust the angle of swing lever to corresponding location. 2. Speeder: adjust the rotation speed of motor. 3. Emergency stop switch: When the device is in a dangerous state or needs to stop working, press the emergency stop switch to cut off the power and stop the operation of the device to protect of personal and equipment safety.

  • Page 13: The Angle Adjustment Of Swing Lever

    3.3.2 The angle adjustment of swing lever Use the swing lever position adjusting handle to adjust the position of swing lever to realize conversion of the machine placement mode in different states(Different equipment states are as follows). Hold the handle tightly with one hand to support the swing lever, turn the other hand counterclockwise and press down the adjustment handle, rotate according to the hole location on sector plate, and release the adjusting handle when it reaches required position.

  • Page 14: Water Tank

    Note: After adjusting the position of the swing rod, it is necessary to check whether the swing rod has been limited before operating the machine. 3.4 Water tank There is a water injection port on the top of the water tank, which can be filled with water. When the equipment needs to perform water grinding work, turn the water switch clockwise to start water grinding work.

  • Page 15: Vacuum Hose Installation

    Note: Do not add too much water to avoid water overflow. When water grinding, always pay attention to the amount of water in the water tank. 3.5 vacuum hose installation This machine is a dual-purpose model of dry grinding and wet grinding. When dry grinding, connect one end of a 50mm vacuum house to the connection of the vacuum port on the gear box cover, lock it with a throat hoop, and connect one end to the vacuum cleaner.

  • Page 16: Additional Weight Iron

    3.6 Additional weight iron The additional weight iron has two different positions, which correspond to the working position and the tilting position on the equipment respectively. The adjustment of the position of the Additional weight iron is mainly based on the rotation and the fixed position of the silicone pad support and the dead weight to achieve the purpose of limit.

  • Page 17: Foot Pedal

    3.7 Foot pedal The foot pedal has two different positions, which correspond to the working position and the tilt position on the equipment respectively. The adjustment of the pedal position is mainly for the purpose of rotating and positioning the beads to the limit. ①Working position ②Tilting position Notice:...

  • Page 18: Machine Operation

    4. Machine Operation 4.1 Overview The following part mainly describes: When the mode is switched to manual operation, grinding machines in different positions, and the main operation of the grinder and how to install the grinding pads. Note: 1. Grinders can only be used or repaired by person who have learned the necessary theoretical and practical training and have carefully read the user manual.

  • Page 19: Machine Transport Position

    4.2.2 Machine Transport position During the transportation of the machine, if it is necessary to lift the machine, loosen the adjustable and tightening handles on both sides of the frame, pull out the lifting rod, and then tighten it. Then one person uses the lifting rod to lift the machine, and the other uses the handle to lift the machine.

  • Page 20: Machine Package Position

    4.2.3 Machine package position When packing, can adjust the position of swing rod, pedal, handle, so that it reaches the packing position. The minimum packing size is as follows, which can be packed according to its size.

  • Page 21: Machine Upright Position

    When you put down the machine, pay attention to your own strength, and do your best to ensure the safety of the machine and the person. XINGYI company does not assume any responsibility for machine damage and personal injury caused by improper operation.

  • Page 22: Start And Stop The Grinder

    2、At the adjustment process, we must make sure the lock device reset, before the operation of the machine. 3、when the machine is located at the transport or packaging position, there is the risk of extrusion, be sure to be careful. 4、At the grinding process, the dust inhalation is harmful, please bring a professional masks in operation to ensure personal safety.
  • Page 23 2. Stop the grinder Press the emergency stop switch to stop the equipment (remember to reset the motor forward and reverse switch and unplug the power plug). Notes: When stopping the machine, it is recommended to unplug the power supply for safety reasons.

  • Page 24: Replace Abrasives

    Please note that the emergency stop switch can only be pressed or rotated. Prohibit upward pull. When starting the machine, it is recommended to press the handle to make the machine slightly raise and tilt back, reduce the pressure on the grinding disc, and reduce the friction between the grinding disc and the ground, so that the motor will not be overloaded when starting the machine.

  • Page 25: Method Of Machine Wire Winding

    When the equipment is running for a period of time, the abrasives, grinding discs, and gearboxes will generate high temperatures. Please pay attention when changing abrasives to avoid scalding. Make sure to replace the grinding disc after the power is unplugged and the emergency stop is pressed.

  • Page 26: Grinding Route (For Reference)

    4.6 Grinding route（for reference） When grinding the ground, it should be in accordance with the # method to grind the ground to get better effect. And according to # to grind ground, the machine grinding direction makes the wire more and more farther away, so that you can further avoid the interference of the wire to the normal work of the grinding machine.

  • Page 27: Maintenance Items

    5. Maintenance Items 5.1 Overview We recommend that the grinding machine be checked regularly to extend the service life. Note: During the maintenance and repair process, the power of the grinder must be disconnected. Wear protective outfit such as safety shoes, protective gloves, protective masks, etc. 5.2 Daily check 5.2.1 Check the switches The emergency stop switch should be rotated along the rotation direction on the switch.

  • Page 28: Cleaning

    which will affect grinding efficiency even lead to abrasive drop and cause accident. In view of this situation, please remember to clean up in time. 5.2.4 Note Be sure to wear protective outfit for maintenance checking such as protective gloves, protective masks, insulated shoes, etc.

  • Page 29: Clean The Grinding Disc Cover

    5.3.2 Clean the grinding disc cover Remove the vacuum house connection, illuminate the dust nozzle with a flashlight, clean the dust nozzle with brush. So that it will not clog the dust nozzle and affect dust collection efficiency. 5.3.3 Clean up the grinding disc and conversion block Tilt the machine and use a cross screwdriver to remove the pads, and use shovel to remove dust.

  • Page 30: Note

    In this case, just disconnect the power plug and then reconnect it. 5.5 Maintenance Any repairs must be performed by Xingyi Service Center trained service person and use original Xingyi accessories. If your machine needs repair, please contact with your retailer.

  • Page 31: Frequently Asked Questions And Solutions

    6. Frequently asked Questions and Solutions This chapter describes some of the possible failures and how to handle them. If you still can not resolve and have an error, please contact your nearest retailer. Problem Possible reason Solution Emergency stop switch is pressed Turn on the emergency stop switch Overload Unplug the power cord and plug it in...

  • Page 32: Technical Data

    7. Technical Data The table and picture show the technical data and dimensions of the grinder. GX65 KW 13 Engine power P220 P380 Rated voltage Rated current HZ 60 Input hertz KW 15 Inverter power Working width   Diameter of grinding disk Grinding speed Grinding and pressing (additional 224kg...

  • Page 33: Warranty

    8. Warranty Warranty Regulations Xingyi does not bear the cost of machine damage caused by improper transportation, unpacking and improper use. Local distributors may be subject to specific warranty terms, please contact with your local distributor for specific warranty terms.
