STS Touring Series Instruction Manual

Thank you for using WM-01 series wall mount stents.
Before you begin
Unpack the carton
Product Features
Installation Steps
Screw Accesorie A
M6 screws
Mount Acc.A with Acc.B with a Triangular Nut
Accesories A
Cabinet
Maintenance: Please check from time to time during use wall structure or whether it be shaken
loose screws, timely reinforcement to guard against the danger of falling.
Instruction Manual
The WM-01 has a simplified shape, compact structure and convenient
operation. In addition to forward and backward rotation, lateral angle
can be set up.
These stents are significantly different from conventional stents, so be
sure to read this owner's guide. It will help you set up and use your
stents properly, for the greatest enjoyment.
Contains: Accessories (A & B), 2 M6 Screws,
setscrews.
Horizontal rotation angle (±0.5°): -120°~+120 °
Vertical rotation angle (±0.5°): 0°~63 °
The biggest bearing: 15 KG
Farthest away from the wall: 90mm
Triangular nut
Accesories B
WM-01
Wall mount stents
Screw Accesorie B to the wall
Set Screws Accesories B
Focus to the audience and adjust the screw
English
1 allen spanner, 2 wall
Dowel
240°
63°
