VRL-74 & VRL-91

LED MARINE RANGE LIGHT BEACONS

Version: 1.0.23

Date: December 17, 2020

VRL-74 & VRL-91

Date 17.12.2020 Version 1.0.23  Product Manual  0

SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com

Table of Contents

Need help?

Do you have a question about the VRL-74 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sabik Marine VRL-74

Page 1 VRL-74 & VRL-91 LED MARINE RANGE LIGHT BEACONS Version: 1.0.23 Date: December 17, 2020 VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  0 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
Page 2 Updated single optic GA. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  1 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
Page 3  USCG 1.0.18 2015/10/22 213+ 74-00002200+ Added GPS detected TVIR 91-00000050+ enquiry Removed description of Storage mode as not relevant to VRL-74 USCG 1.0.19 2015/10/28  213+ 74-00002200+ Performance table reformatting.  91-00000050+ Minor edits and US spelling corrections.
Page 4 Appendix A. Included error code & trouble- shooting information. 1.0.23 2019/3/30 Manual updated to include 24V operation as well as 12V. VRL-74 Serial Number: 74-00002950+ June 2017 VRL-91 Serial Number: 91-00000210+ VRL-74 Mini-Arrays Model Numbers VRL-91 Product Version 2.00...
Page 5 VRL-74 LED Versions by color, release date and serial number RED LED LED Version Release Date VRL-74 Serial Number VRL-91 Serial Number June 2012 74-00000120+ June 2017 74-00002950+ April 2011 91-00000010 GREEN LED LED Version Release Date VRL-74 Serial Number...
Page 6: Table Of Contents
Contents INTRODUCTION TO THE VRL-74 & VRL-91 LED MARINE BEACONS ........4 ...........................4 VRL-74 O VERVIEW ...........................4 VRL-91 O VERVIEW ........................4 ERFORMANCE AT A LANCE ............................5 ONSTRUCTION ELECTRICAL CONNECTION ......................5 ..........................5 OWER ONNECTION ........................5 ARDWIRE ONNECTION ......................6 GPS S...
Page 7 C.1 VRL-74 BEACON SPECIFICATIONS ..................77 PPENDIX C.2 VRL-91 BEACON SPECIFICATIONS ..................77 PPENDIX C.3 COMMON BEACON SPECIFICATIONS ................77 PPENDIX VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  3 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
Page 8: Introduction To The Vrl-74 & Vrl-91 Led Marine Beacons
The details of the application for this VRL-74 beacon are provided on the cover of this manual. The number of lenses required for any application is determined from the peak intensity of the flash character and the thermal constraints of the LEDs in the beacon design.
Page 9: Construction
Heat is dissipated through the heat sink that the LEDs are mounted on. The VRL-74 and VRL-91 are sealed against dust and moisture to the level of IP-67 and if either light is to be used outside will be fitted with bird spikes to prevent birds nesting. The lenses are fully sealed.
Page 10: Gps Synchronization Option
The only assembly required for the VRL-74 is fitting the bird spikes. The bird spikes are mounted on brackets; these need to be attached to the frame of the VRL-74. The location of the bird spikes depends on the orientation of the beacon – the three possible mounting arrangements are shown below.
Page 11: Vrl-91 Assembly
Please see Appendix E for overall dimensions of the VRL-91 units. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  7 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
Page 12 VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  8 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
Page 13: Mounting And Alignment
Mounting and Alignment The VRL-74 and VRL-91 are mounted via up to five 13.5mm slotted holes on a 200mm Pitch Circle Diameter (PCD). The mounting holes are slotted to allow either beacon type to be adjusted in the horizontal plane by up to ±6 degrees. The holes are arranged in two overlapping patterns of 90 degree and 120 degree spacing.
Page 14 A scope mount is also available to allow the customer to fit an optical sighting scope with a standard Weaver mount. The scope mount fits to the VRL-74 in exactly the same way as the fixed sight does. Fixed sight and beacon reference surfaces (mated) VRL-74 &...
Page 15: Programming
(see picture below). Please locate the label “Aim TVIR Remote Here” on the rear cover of the beacon. The directions provided by this label may differ between VRL-74 and VRL-91 beacons. To program or read back settings the TVIR Remote-02...
Page 16: Programming Syntax
After this the beacon will resume normal operation. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  12 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
Page 17: The Beacon Will Not Enter Programming Mode
(the default is Q 1s 0.3s, code 601). All configuration settings are stored in EEPROM so cycling the battery power will not reset these values. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  13 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
Page 18: Deciding Which Settings Are Required
Program Flash Character operation. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  14 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
Page 19: Custom Flash Character
 The termination code when the programming of the custom character is finished = 000 If an error occurs when entering a custom character the VRL-74 will flash the error code of 3 quick flashes. Programming a custom character creates a flash character with code 999. To get the VRL- 74 to use the custom character the value of 999 must be entered as the flash character.
Page 20: Synchronizing Options
This is done to achieve a wider range of programmable intensities, which makes the VRL-74 more versatile. The precise change-over intensity between all optics activated and only one optic activated depends on all of the beacon’s color and LED version, the flash character and the ambient temperature.
Page 21: Operation Mode
Setting the reconnect threshold to 999 will reset both it back to the default value. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  17 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
Page 22: System Information
The beacons contain details of manufacture including calibration details, firmware version, and LED type used. See Appendix A for the full list of data available For example the VRL-74 provides a reading of the supply voltage as a quick means of checking battery voltage.
Page 23: Routine Maintenance
Investigate any corrosion and take appropriate preventive action. User Notes VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  19 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
Page 24: Appendix Avrl-74 And Vrl-91 Programming Table
Appendix A VRL-74 and VRL-91 Programming Table Operation Feature Value 1 = Program Mode 0 = Flash Character 000 – Fixed character 9 = Read Settings 1YY – Iso phase (ISO) 2YY – Occulting (OC) 3YY – Flash (Fl) 4YY - Multiple Flash (Fl(x))
Page 25 7 – GPS option detected 001 – if GPS detected VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  21 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
Page 26 Peak Intensity Flash Mode (7-2-001)  Auto-storage and calendar modes are disabled. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  22 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
Page 27: Appendix Bintensity Settings And Currents
Note that the optics (both primary and secondary) in a VRL-74 Mini-Array product will always project parallel to each other. i.e. the widest divergence that can be ordered for a VRL-74 Mini-Array product is the same as the widest divergence available from a secondary lens.
Page 28  Currents are temperature-dependent, rising with increased temperature.  The VRL-74 is rated to operate over the ambient temperature range of at least -30ºC to +50ºC. Using the intensity programming tables: 1. The externally-controlled VRL-74 beacon is programmed for the peak intensity required.
Page 29: Appendix B.1.1 Vrl-74 Green Intensity Settings And Currents
Appendix B.1.1 VRL-74 GREEN Intensity Settings And Currents VRL-74 Range Light Performance Table 3 Sep 2015 GREEN 263 1x1 (No spreader) Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic...
Page 30 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  26...
Page 31 VRL-74 Range Light Performance Table 6 Sep 2015 GREEN 263 2x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 100,53 2.00...
Page 32 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  28...
Page 33 VRL-74 Range Light Performance Table 9 Sep 2015 GREEN 263 3x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 75,400 2.00...
Page 34 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  30...
Page 35 VRL-74 Range Light Performance Table 12 Sep 2015 GREEN 263 4x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 58,000 2.00...
Page 36 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  32...
Page 37 VRL-74 Range Light Performance Table 15 Sep 2015 GREEN 263 5x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 45,240 2.00...
Page 38 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  34...
Page 39 VRL-74 Range Light Performance Table 18 Sep 2015 GREEN 263 6x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 40,392 2.00...
Page 40 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  36...
Page 41: Appendix B.1.2 Vrl-74 White Intensity Settings And Currents
Appendix B.1.2 VRL-74 WHITE Intensity Settings And Currents VRL-74 Range Light Performance Table 3 Jun 2017 WHITE 465 1x1 (No spreader) Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic...
Page 42 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  38...
Page 43 VRL-74 Range Light Performance Table 6 Jun 2017 WHITE 465 2x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 274,20 2.40...
Page 44 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  40...
Page 45 VRL-74 Range Light Performance Table 9 Jun 2017 WHITE 465 3x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 174,50 2.40...
Page 46 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  42...
Page 47 VRL-74 Range Light Performance Table 12 Jun 2017 WHITE 465 4x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 133,90 2.40...
Page 48 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  44...
Page 49 VRL-74 Range Light Performance Table 15 Jun 2017 WHITE 465 5x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 115,20 2.40...
Page 50 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  46...
Page 51 VRL-74 Range Light Performance Table 18 Jun 2017 WHITE 465 6x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 108,60 2.40...
Page 52 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  48...
Page 53: Appendix B.1.3 Vrl-74 Red Intensity Settings And Currents
Appendix B.1.3 VRL-74 RED Intensity Settings And Currents VRL-74 Range Light Performance Table 3 Jun 2017 RED 168 1x1 (No spreader) Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic...
Page 54 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  50...
Page 55 VRL-74 Range Light Performance Table 6 Jun 2017 RED 168 2x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 99,000 1.38...
Page 56 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  52...
Page 57 VRL-74 Range Light Performance Table 9 Jun 2017 RED 168 3x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 63,800 1.38...
Page 58 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  54...
Page 59 VRL-74 Range Light Performance Table 12 Jun 2017 RED 168 4x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 50,700 1.38...
Page 60 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  56...
Page 61 VRL-74 Range Light Performance Table 15 Jun 2017 RED 168 5x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 38,800 1.38...
Page 62 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  58...
Page 63 VRL-74 Range Light Performance Table 18 Jun 2017 RED 168 6x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 32,400 1.38...
Page 64 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  60...
Page 65: Appendix B.1.4 Vrl-74 Yellow Intensity Settings And Currents
Appendix B.1.4 VRL-74 YELLOW Intensity Settings And Currents VRL-74 Range Light Performance Table 3 Jun 2017 YELLOW 366 1x1 (No spreader) Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic...
Page 66 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  62...
Page 67 VRL-74 Range Light Performance Table 6 Jun 2017 YELLOW 366 2x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 104,20 2.64...
Page 68 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  64...
Page 69 VRL-74 Range Light Performance Table 9 Jun 2017 YELLOW 366 3x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 66,000 2.64...
Page 70 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  66...
Page 71 VRL-74 Range Light Performance Table 12 Jun 2017 YELLOW 366 4x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 58,200 2.64...
Page 72 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  68...
Page 73 VRL-74 Range Light Performance Table 15 Jun 2017 YELLOW 366 5x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 40,400 2.64...
Page 74 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  70...
Page 75 VRL-74 Range Light Performance Table 18 Jun 2017 YELLOW 366 6x1 Spreader Prog Intensi Current (A) @25C, 12V Code VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- VRL-74- (six (Cd) digits) 1-optic 2-optic 3-optic 4-optic 5-optic 6-optic product product product product product product 36,000 2.64...
Page 76 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  72...
Page 77: Appendix B.2 Vrl-91 Optics
**The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  73...
Page 78 VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  74 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
Page 79: Appendix B.2.2
**The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  75...
Page 80 **The beacon intensity programming is not limited to the values shown. Any value can be set within the specified range and within the available precision of the programming code. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  76...
Page 81: Appendix Cbeacon Specifications
Appendix C BEACON Specifications Appendix C.1 VRL-74 BEACON SPECIFICATIONS Optical Light Source High-Intensity Light-Emitting Diodes Operating temperature controlled to protect LEDs Colors Available Red, Green, White, Yellow IALA Recommendation E-200-1 part1 Intensity See Appendix B IALA Recommendation E-122(2001) & E-200-3 Part 3 (2008) Intensity Settings ‘Peak intensity during the flash’...
Page 82 Design Life 12 years Warranty 1 year. See Vega warranty terms VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  78 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
Page 83 Insert the battery holder into the programmer case, and press it until the latch clicks into place. VRL-74 & VRL-91 Date 17.12.2020 Version 1.0.23  Product Manual  79 SABIK Oy · Höylänlastu 2 A · FI 06150 Porvoo · Telephone +358 -19- 560 1100 · sabik-marine.com...
