Summary of Contents for HKBN 5G CPE Pro 3
- Page 1 Last Updated: 18 Jul 2023 Router Configuration Guide (Version 1.1)
- Page 2 5G CPE Pro 3 - Router Configuration Guide Getting Started: 1. Connect the router’s power adaptor to a power supply. The router will then start up automatically and connect to the Internet. 2. Connect your Wi-Fi device to the Wi-Fi network of the router. For the default Wi-Fi name and password, refer to the nameplate on the bottom of the router.
- Page 3 5G CPE Pro 3 - Router Configuration Guide Basic Setting: Log in to the web-based management page to manage your router, such as changing the Wi-Fi name or password. 1. Use browser to access 192.168.8.1. (The default login password can be found on the nameplate on the bottom of the router.)
- Page 4 5G CPE Pro 3 - Router Configuration Guide 2. Read the “Mobile Broadband Devices Privacy Notice” and press “Next” to continue. Version 1.1...
- Page 5 5G CPE Pro 3 - Router Configuration Guide 3. Set the Wi-Fi name and password. Default Wi-Fi name and password can be found at the nameplate on the bottom of the router. (Password length cannot be less than 8 characters)
- Page 6 5G CPE Pro 3 - Router Configuration Guide Set the device login password Note: “Same as Wi-Fi password" is enabled – The password for 5GHz, Wi-Fi and the web-based management page will be the same. “Same as Wi-Fi password” not enabled – The password for web-based management page will be set to “New password” which is different from WiFi password.
- Page 7 5G CPE Pro 3 - Router Configuration Guide 5. Basic setting is completed and the router should work properly. Reset: When the router is powered on, use a needle-type object to press and hold the Reset button, until the ambient light strip starts to flash. Release the button, and the router will restore to its factory settings.
- Page 8 5G CPE Pro 3 - Router Configuration Guide APN Setting for fix IP SIM Card: (may skip this session with DIP plan) Scroll to the bottom. Press “+” to add a new Profile Version 1.1...
- Page 9 5G CPE Pro 3 - Router Configuration Guide Fill in the info as stated below: APN = rmvpn512 Version 1.1...
- Page 10 5G CPE Pro 3 - Router Configuration Guide Version 1.1...
- Page 11 5G CPE Pro 3 - Router Configuration Guide The IP using can be found under “Advanced” → “System” → “Device Information” → “WAN IP Address”. Version 1.1...
- Page 12 5G CPE Pro 3 - Router Configuration Guide Wi-Fi Setting: Basic SSID/password can be changed under “Wi-Fi Settings” → “Wi-Fi Basic Settings” Version 1.1...
- Page 13 5G CPE Pro 3 - Router Configuration Guide If need to turn on/off Wi-Fi, define Channel/Mac options, or etc., related pages can be found under “Advanced” → “Wi-Fi” → “Wi-Fi Advanced Settings”. Version 1.1...
-
Page 14: Lan Setting
5G CPE Pro 3 - Router Configuration Guide LAN Setting: LAN IP / DHCP setting can be changed under “Advanced” → “Router” → “DHCP” Version 1.1... - Page 15 5G CPE Pro 3 - Router Configuration Guide NAT Setting: Port Forward setting can be changed under “Advanced” → “Security” → “Virtual Server” Version 1.1...
- Page 16 5G CPE Pro 3 - Router Configuration Guide For example: (1) IP of internal LAN device is 192.168.8.100 with service port as 3389; and (2) external LAN use the same port, may set as follow: Version 1.1...
- Page 17 5G CPE Pro 3 - Router Configuration Guide If need to use DMZ (or 1-to-1 NAT), may set under “Advanced” → “Security” → “DMZ Settings”: ***** Note: With DMZ set, device will be directly explored in internet. ***** Version 1.1...
