- Page 1 Thermorail Towel Rail 12Volt Ladder Heated Towel Rail Installation Guide Please read these instructions carefully and in full before installation. Installation should be carried out by a qualified electrician.
-
Page 2: Table Of Contents
Contents What’s in the box? Installation Wiring Diagram Technical Specifications Safety & Care Information Warranty Information Warranty Registration Contact Us 1300 368 631 | www.thermogroup.com.au... -
Page 3: What's In The Box
Please note these parts are not to scale You will also need: • Cross Head Screwdriver • Pencil • Spirit Level • Tape Measure • Drill Bits (6mm x 15mm) • Cordless Drill • Electrical Supply 1300 368 631 | www.thermogroup.com.au... -
Page 4: Installation
If mounting in the wall cavity, the transformer must be behind an access plate or a timer/switch to enable access and the transformer must have adequate ventilation. Test that there is 240Volt power coming into the transformer. 1300 368 631 | www.thermogroup.com.au... - Page 5 7. Fix the Thermorail to the Wall Fit the Thermorail to the mounting brackets installed on the wall. You may need assistance to hold the rail in place. Tighten using the grub screws and the allen key provided. 1300 368 631 | www.thermogroup.com.au...
-
Page 6: Transformer Wiring Diagram
Wiring Diagram Transformer Wiring Diagram 240V 12V 1. Wall Cavity 2. Transformer 3. Switch/Timer 4. Thermorail 1300 368 631 | www.thermogroup.com.au... -
Page 7: Technical Specifications
W600 x H800 x D122 IP55 SRB4412 W600 x H800 x D122 IP55 SS4412 W600 x H800 x D120 IP55 Supply Voltage 240V 50Hz Transformer Voltage Wiring Side Left or Right Wiring Method Hardwired Warranty on Transfomer 1 Year 1300 368 631 | www.thermogroup.com.au... -
Page 8: Safety & Care Information
The finish of your Thermorail Heated Towel Rail is hard wearing and easy to maintain. However, any harsh scrubbing, scratching or acid based cleaning products will damage the surface of your towel rail. Cleaning with a soft cloth and a non-abrasive cleaning agent will give the best results. 1300 368 631 | www.thermogroup.com.au... -
Page 9: Warranty Information
If the product develops a fault within the warranty period due to normal wear and tear, Thermogroup at its discretion will recognise whether it’s a faulty product or not. If it is impossible or not economical for the manufacturer to repair the product, the manufacturer... -
Page 10: Warranty Registration
Timer / Isolating Switch / None Fill out and sign below to declare that all the information recorded on this form correlates to the installation Installer Customer Name: Name: Email: Email: Address: Address: Postcode: Postcode: Phone: Phone: Signature: Signature: 1300 368 631 | www.thermogroup.com.au... - Page 11 Notes 1300 368 631 | www.thermogroup.com.au...
-
Page 12: Contact Us
Contact Us Phone: 1300 368 631 | Technical Helpline: 1300 989 464 sales@thermogroup.com.au | www.thermogroup.com.au...
