Model: 0960
Ride On
Official Licensed Product
INSTALLATIONANDOPERATING
INSTRUCTIONS
Children's electric cars
A
B
Executive standard:
En71 and En62115
ASTM F963-17
WARNING:
!
Assembled by an adult.
This toy is unsuitable for children under 3 years due to its maximum speed.
Licensee: Chuzhou Bettyma BabyCarrier Co.,Ltd.
Photos are for reference ONLY.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for jcb 0960
- Page 1 Model: 0960 Ride On Official Licensed Product INSTALLATIONANDOPERATING INSTRUCTIONS Children’s electric cars Executive standard: En71 and En62115 ASTM F963-17 WARNING: Assembled by an adult. This toy is unsuitable for children under 3 years due to its maximum speed. Licensee: Chuzhou Bettyma BabyCarrier Co.,Ltd.
-
Page 2: Installation Instruction
INSTALLATION INSTRUCTION The owner’s manual contains assembly, use and maintenance instructions. The illustrations in this instruction are used for easier understanding of the The vehicle must be assembled by an adult who has read and understands operation method of the product and the product structure. Please note there the instructions in this manual. - Page 3 3+ years The following safety hazards may result in serious injury or death to the user of the vehicle: Before using the vehicle the child should understand the vehicle controls • Use of a battery or charger other than the supplied 12V and safety issues.
-
Page 4: Specification
Damage to the battery may occur if it is allowed to drain completely. Do not allow the battery to drain completely. Check the battery and charger (supply cord, connector) for wear and damage before charging. Do not charge the battery if damage has occurred. - Page 5 1 set 1 set W(ceiling front pillar) X(ceiling rear pillar) M(Bucket fixed axle) N(Seat) Z(Ceiling Rear Pillar) Y(Ceiling) O(Rear digging arm support ) AD(Support wheel) P (4*12 self-tapping screw) R (Digging arm handle bar) Q(Digging arm) *An electric screwdriver is recommended for configuration A. CONFIGURATION B AB(Charger) AA (Instruction Book)
-
Page 6: Before Starting
Preparation work: Put the car upside down on a soft cloth or smooth plane firstly (Can't be directly placed on the surface of the cement, etc., which will scratch the surface of the plastic), then take off the cardboard, foam, nylon cable ties. - Page 7 1.All batteries should be inserted in the correct polarity. 2.Non-rechargeable battery cannot be recharged 3.Take out and properly deal with the dead battery. To avoid injury, please keep kids away from the battery. 4.The direct contact between the positive and negative terminals may result in fire or explosion.
- Page 8 [7] [6] [6] [7] Step 5-1: Install the bucket 1. Assemble the bucket frame as shown in the picture. 2. Turn the bucket over and tighten it with 10 J (4*16 self-tapping screws). Step 5-2: Install the bucket Step 5-3: Install the bucket 1.
- Page 9 Step 6: Install the seat Step 8: Assemble the digging arm support N Recline the seat first, Assemble the O(digging front part insert into the arm support) with 6 J body and push down hard (4*16 self-tapping on the back end of the screws) , as shown in the seat.
- Page 10 CONFIGURATION A Step 10: Assemble the digging arm Preparation work: I n s t a l l t h e Q ( d i g g i n g arm) to O(digging arm Put the Ceiling upside down on a soft cloth or smooth plane firstly support) , as shown in (Can't be directly placed on the surface of the cement, etc., which the figure.
- Page 11 CONFIGURATION B Step 11-2: Assemble the Ceiling 1. Assemble Z(Ceiling Rear Pillar) to X(ceiling rear pillar). 2. Fix it with 8 P(4*12 self-tapping screws) , tighten the screws, as shown in the figure. Step 11: Assemble the front bracket interchangeable cover Assemble T(front bracket interchangeable cover R), S (front bracket interchangeable cover L), U(Rear bracket interchangeable cover L) and V(Rear bracket interchangeable cover R) to car body, as shown in the...
- Page 12 Button Description: ▲: forward ▼: reverse ◀: turn left ▶: turn right S: Speed P:Emergency brake, press it and the running function will fail, press again, it release. Remote control operating instruction Remote control is priority (when the car is in Remote control, the remote control personnel can control the car forward and backward, high/Low speed, steering and other functions, the driver CAN NOT operate the car).
- Page 13 6. Bucket operation instruction 1&2. Horn button: press the button to play the horn. 3. Forward/Reverse switch: press the button for controlling the Vehicle to move forward, reverse. 4. Power switch: Turn on or turn off the power. 5. Foot pedal switch: Step on the foot pedal switch, the car will move forward; A.
- Page 14 step 7: Pull the handle of D bucket back, you can pour out the leaves and step 3: Scoop up leaves and other step 4: Pull the handle of B bucket other items in the bucket. items. frame back to lock automatically. Note: After use, D bucket handle needs to be reset and locked.
- Page 15 8. Digging bucket operation instruction ！ WARNING RISK OF TIPPING OVER Before use, the anti-tip wheel must be rotated to the anti-tip position, otherwise it may cause injury to the user or cause other damage. Remove the foam from the excavator bucket seat support wheel. 1.
-
Page 16: Charging Instructions
9. Charging instructions. B: the excavator bucket arm handle Operating the bucket arm handle to make the bucket arm turn it up and down, turn right and left. When the battery is low, please charge it immediately.1. Please find and open the Charging hole cover as shown in figure. - Page 17 Trouble elimination methods 1.Yes, the fuse cuts off the power 1. Is the fuse overloaded? automatically by 5-60 seconds, then 2. The pedal switch connector is restart; No, check next reason analysis The motor good? 2.No, repair foot switch ; Yes, check next 3.
