ASUS ROG Flow Z13 (GZ301V) Series
Service Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the ROG Flow Z13 GZ301V Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Asus ROG Flow Z13 GZ301V Series

Summary of Contents for Asus ROG Flow Z13 GZ301V Series

  • Page 1 ASUS ROG Flow Z13 (GZ301V) Series Service Guide...

  • Page 2: Copyright Information

    LIMITATION OF LIABILITY Circumstances may arise where because of a default on ASUS’ part or other liability, you are entitled to recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death) and damage to real property and tangible personal property;...
  • Page 3 Disclaimer ASUS is not responsible for direct, indirect, intentional or unintentional damages resulting from improper installation and operation. Safety precautions • Keep liquids or moisture away from your Notebook PC before installing or removing any components. • Ensure to place your Notebook PC on a stable surface before installing or removing any components.

  • Page 4: Table Of Contents

    Table of Contents ⚫ Service Overview ⚫ ASUS ROG Flow Z13 (GZ301V) Series Overview ⚫ Components Top View ⚫ Components Bottom View ⚫ Repair Overview ⚫ Appropriate Tools ⚫ Keyparts and Related Parts ⚫ Disassembly Steps : • KEYBOARD •...

  • Page 5: Service Overview

    Service Overview • Carefully read through this Service Guide for a look at various components of the device before performing any service and repairs. • To provide the best service, we have provided the below information for technicians from distributors and resellers to perform the complete device disassembly and assembly.

  • Page 6: Asus Rog Flow Z13 (Gz301V) Series Overview

    ASUS ROG Flow Z13 (GZ301V) Series Overview Front View Rear View ❶ Array microphones ❺ Microphone ❷ Camera Indicator ❻ Air vents ❸ Camera ❼ Kickstand ❹ Touch screen panel ❽ MicroSD card slot ❾ Camera Top View ❶ Air vents Right View ❶...

  • Page 7: Components Top View

    Components Top View ⧫ SIDE KEY FPC ⧫ A COVER ASSY ⧫ BATTERY ⧫ KICKSTAND ASSY ⧫ CAMERA MODULE 13M ⧫ VOL KEY ⧫ FRONT CAMERA FPC ⧫HINGE (THERMAL BATT TOP SPONGE) (Power Key Sponge) (VOL Key Sponge) (BATT TOP SPONGE MYLAR) ⧫...
  • Page 8 Components Top View ⧫ MB SSD GASKET ⧫ GZ301VV-1F ⧫ GZ301VV-1F ⧫ LCD TOUCH IC GASKET ⧫ INDICATOR LENS ASSY ⧫ GZ301VV-1F A For GZ301VIC KICKSTAND ASSY VOLUME KEY COVER ASSY ⧫ HALL SENSOR BD ⧫ GZ301VV-1F ⧫ GZ301VV-1F SSD ⧫...

  • Page 9: Components Bottom View

    Components Bottom View ⧫ A COVER ASSY ⧫ CAMERA HOLDER ⧫ CAMERA MODULE 13M ⧫ BATTERY ⧫ GZ301VV-1F A CONDUCTIVE TAPE COVER ASSY REAR CAMERA AL FOIL (BATTERY THERMAL SPONGE L) ⧫ LCD MODULE ⧫ LCD GASKET ⧫ KICKSTAND ASSY ⧫...

  • Page 10: Repair Overview

    Repair Overview This chapter describes disassembly and assembly (Assemble document please look up from the last page), please follow the information provided in this section to perform the complete disassembly procedure. ⧫ Precautions: Before you perform any service or repair on the notebook, please pay special attention to the cautions prevent any damages to the notebook. 1.

  • Page 11: Appropriate Tools

    Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the ASUS ROG Flow Z13 (GZ301V) Series notebook. ⧫ Screwdriver ⧫ Alcohol 95% ⧫ Glove ⧫ Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head.
  • Page 12 Appropriate Tools Please prepare and select the appropriate tools to disassemble/assemble for the ASUS ROG Flow Z13 (GZ301V) Series notebook. ❶ ❼ ❷ ❸ ❺ ❹ ❻ Item Part Name Memo ❶ Silicone scraping pen Please store it in the environment of 10 ~ 40 ℃.

  • Page 13: Keyboard

    KEYBOARD The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Remove the Keyboard from device. Back...

  • Page 14: Ssd

    The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Turn on the KICKSTAND. Screws Spec Torque (kgf-cm) Step 2 : Remove screw *1pc, and SSD DOOR. M2*4.8L (3.1,0.8) (K)+H #1 1.8±0.2 Step 3 : Remove screw *1pc, and SSD. M2*2.5L (5,0.5) (K) #1 1.8±0.2 Open...
  • Page 15 The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice Step 1. Put the SSD into the SSD slot. Step 2. Push SSD in. Step 3. Lock the screw *1pc. Step 4. Assemble SSD DOOR, and lock the screw *1pc. Push Back...

  • Page 16: Lcd Module

    LCD MODULE The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Turn on the KICKSTAND and remove screws. Screws Spec Torque (kgf-cm) Step 2 : Position LCD Screen Opening on upper middle side (or lower middle side) of panel. M1.6*8L (3.6,0.8) (K)+H T5 1.8±0.2 Step 3 : Clamp LCD Screen Opening to separate the panel from the frame, and create a gap.
  • Page 17 LCD MODULE The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice For GZ301VIC Step 1 : Turn on the KICKSTAND and remove screws *2pcs. Screws Spec Torque (kgf-cm) Step 2 : Position LCD Screen Opening on lower middle side of panel. Step 3 : Clamp LCD Screen Opening to separate the panel from the frame, and create a gap.
  • Page 18 LCD MODULE The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Ambient Light Sensor (ALS): Step 6 : Move panel up and disconnect battery connector first, then disconnect cables*2pcs, 1. After removing the BOTTOM CASE, Step 7 : Release LCD TOUCH IC GASKET and disconnect TOUCH PANEL FFC and LCD EDP.
  • Page 19 LCD MODULE The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice If FFC is damage during disassembly, please replace new one. Here are some samples of FFC damage: Step 1 : Release LCD TOUCH IC GASKET (green mark) and assemble cables*2pcs then paste the GASKET back. Step 2 : Put LCD module on the top of battery as the picture and assemble cables*2pcs.

  • Page 20: Battery

    BATTERY The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to IC damage. Step 1 : Remove screws *6pcs Screws Spec Torque (kgf-cm)

  • Page 21: Speaker

    SPEAKER The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Disconnect SPEAKER connector. Screws Spec Torque (kgf-cm) Assembly Notice Step 2 : Release SPK ACERATE. M2*3L D3.5 (K) B-NI,NY 1.8±0.2 Step 3 : Remove screws *4pcs. When Speaker assembly, please follow the mark below Step 4 : Remove SPEAKER.

  • Page 22: Hall Sensor Board And Camera Module 13M

    HALL SENSOR BOARD AND CAMERA MODULE 13M The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Disconnect and remove HALL SENSOR FFC. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *3pcs then remove HALL SENSOR BD and LIGHT SENSOR RUBBER. M2*3L (3.5,0.5) (K) #1 1.8±0.2 Step 3 : Disconnect FPC and remove Rear CAM MODULE 13M.
  • Page 23 HALL SENSOR BOARD AND CAMERA MODULE 13M The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice Please follow below steps to assemble Hall Sensor BD and Rear CAM Module 13M. If FFC is damage during disassembly, please replace new one.
  • Page 24 HALL SENSOR BOARD AND CAMERA MODULE 13M The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice For GZ301VIC Step 1 : Disconnect and remove HALL SENSOR FFC. Screws Spec Torque (kgf-cm) Step 2 : Remove screws then remove HALL SENSOR BD and LIGHT SENSOR RUBBER (green mark). Step 3 : Disconnect fan connector and remove mylar and screws, then remove fan.
  • Page 25 HALL SENSOR BOARD AND CAMERA MODULE 13M The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice For GZ301VIC Please follow below steps to assemble Hall Sensor BD and Rear CAM Module 13M. If FFC is damage during disassembly, Step-1 Check the camera lens on cover is clean, then assemble Camera Module 13M on cover.

  • Page 26: Fan

    The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Disconnect fan connectors. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *4pcs. Step 3 : Tear off Mylar (green mark). M2*5L (K)B-ZN,NY 1.8±0.2 Step 4 : Remove Fan *2pcs.

  • Page 27: Usb Board And Hinge

    USB BOARD AND HINGE The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Tear off HINGE MYLAR *2pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove screws *11pcs, then remove HINGE MASK MYLAR *2pcs and HINGE *2pcs. M2*3L D3.5 (K) B-NI,NY 2.0±0.2 Step 3 : Remove screw *1pc.
  • Page 28 USB BOARD AND HINGE The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice When HINGE MASK MYLAR assembly, please follow below illustration to align the Mylar position. (Right) (Left) (Left) (Right) When HINGE assembly, please follow the screws numbers to lock Hinge. (Right) (Left) Back...

  • Page 29: Thermal Module& Camera 5M Rgb/Hd Ir Cr

    THERMAL MODULE & CAMERA 5M RGB/HD IR CR The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Please follow the reverse screw numbers to release retention screws *8pcs then remove THERMAL MODULE. Screws Spec Torque (kgf-cm)
  • Page 30 THERMAL MODULE & CAMERA 5M RGB/HD IR CR The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice When thermal module assembly, please align it according to the alignment Step-1 post below, and then vertically put down to assemble.

  • Page 31: Main Board

    MAIN BOARD The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Screws Spec Torque (kgf-cm) Step 1 : Remove POWER LED RUBBER *1pc and THERMAL SYS SPONGE *2pcs. Step 2 : Release MB SSD Gasket *1pc, LED FPC Gasket *2pcs, and disconnect cables *2pcs (yellow mark). M2*2L (6.6,0.55) (K) #1 1.8±0.2 Step 3 : Remove screws *9pcs.
  • Page 32 MAIN BOARD The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice When Main Board assembly, please follow the mark Please according to below image to assemble After POGO FPC and USB BOARD FPC assembled, please follow below to fix MB GC CONN GASKET、MB SSD Gasket WIFI MAIN and AUX Antenna.
  • Page 33 MAIN BOARD Mainboard connector placement REAR CAM FPC HALL SENSOR FFC FRONT CAM FPC SIDE KEY FPC USB BOARD FPC MICRO SD Supports using JIG BOARD to refresh F1 BIOS BATTERY CABLE EDP CABLE SPEAKER TOUCH PANEL FFC POGO FPC Back...
  • Page 34 MAIN BOARD Materials on mainboard GZ301VV MB MIC MESH NR2201ZE MB BOT CPU ABSORBER GZ301VV MB BOT POWER MYLAR NR2201ZE MB TOP ABSORBER X557UN SMT GASKET 2*2*2 NR2201ZE MB BOT GPU ABSORBER NR2201ZE MB BOT RAM ABSORBER X557UN SMT GASKET 2*2*2 GZ301VV MB BOT L MYLAR NR2201ZE MB SSD KAPTON NR2201ZE MB BOT LED SPONGE...
  • Page 35 MAIN BOARD NR2201ZE MB BOSS WASHER 1 Materials on mainboard GZ301VV MB TOP EMI GASKET GZ301VV MB TOP ABSORBER GZ301VV MIC RUBBER GZ301VV MB BATTERY CABLE L：63MM GZ301VV MB TOP POWER MYLAR NR2201ZE MB TYPE C GASKET NR2201ZE MB TOP GPU ABSORBER A NR2201ZE MB TOP DDR ABSORBER A GZ301VV MB TOP DDR ABSORBER NR2201ZE MB BOT RAM ABSORBER...

  • Page 36: Wifi Antenna (With Side Key)

    WIFI ANTENNA (with SIDE KEY) The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Remove screws *2pcs. Screws Spec Torque (kgf-cm) Step 2 : Remove WIFI Main and Aux Antenna. Step 3 : Remove screws *3pcs. M1.6*4L (3.2,0.6) (K) #0 1.4±0.1 Step 4 : Remove VOL Key, POWER Key, Side Key Bracket and SIDE KEY FPC.
  • Page 37 WIFI ANTENNA (with SIDE KEY) The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice When VOL KEY and POWER KEY assembly, please follow the direction When SIDE KEY FPC assembly, please follow the location (positioning (green circle) to assemble.

  • Page 38: A Cover

    A COVER The device has an Ambient Light Sensor (ALS) for power-off protection function. Disassembly Notice Step 1 : Remove INDICATOR LENS. Step 2 : Release LED FPC Gasket and remove LED FPC. Open and remove Step 3 : Open and remove KICKSTAND ASSY from cover. Remove(yellow mark) Release and remove Mylar should down through the hole.
  • Page 39 A COVER The device has an Ambient Light Sensor (ALS) for power-off protection function. Assembly Notice Once inside of deco glass is with dust and dirt, please clean it When LED FPC & LED FPC Gasket assembly, please follow with alcohol and Dust-free Cloth. below location to fix.
