Oil Pump with Tank (12 Litres)
www.gedore-automotive.com
www.gedore-automotive.com
GEDORE Automotive GmbH
Breslauer Straße 41
78166 - Donaueschingen
Postfach 1329
78154 Donaueschingen - GERMANY
Worldwide GEDORE service centers and offices are listed on the Internet at: www.gedore.com
KL-0124-43
GEDORE TOOLS, INC.
+49 (0) 771 / 8 32 23-0
Only for USA, Canada & Mexico / Sólo para EE.UU., Canadá y México
+49 (0) 771 / 8 32 23-90
Seulement pour les USA, le Canada et le Mexique
info.gam@gedore.com
7187 Bryhawke Circle, Suite 700
gedore-automotive.com
North Charleston, SC 29418, USA
Operating instructions
Read and understand before use!
+1-843 / 225 50 15
+1-843 / 225 50 20
Version 11/2023
info@gedoretools.com
gedore.com
KL-124-43 (EN231134).indd
EN
Advertisement
Table of Contents
Summary of Contents for Gedore KL-0124-43
- Page 1 +1-843 / 225 50 20 Version 11/2023 Postfach 1329 info.gam@gedore.com 7187 Bryhawke Circle, Suite 700 info@gedoretools.com 78154 Donaueschingen - GERMANY gedore-automotive.com North Charleston, SC 29418, USA gedore.com KL-124-43 (EN231134).indd Worldwide GEDORE service centers and offices are listed on the Internet at: www.gedore.com...
-
Page 2: Manufacturer's Address
Instructions for use and safety are not binding. They never substitute for any legal or trade association regulations. We do not accept any liability for printing errors. Any reproduction, in whole or in part, requires the prior written consent of GEDORE Automotive GmbH. All rights reserved worldwide. © Copyright by GEDORE Automotive GmbH, Donaueschingen (GERMANY) -
Page 3: Table Of Contents
1.9 Work environment ..................................6 1.10 Emissions ......................................6 2. PRODUCT DESCRIPTION ....................................2.1 KL-0124-43 - Oil pump with tank (12 litres) ..........................7 2.2 Scope of delivery / spare parts overview ........................... 7 2.3 Specifications ....................................7 2.4 Component overview ..................................8 3. -
Page 4: Read And Understand For Your Safety
1 bar (14 psi)! may only be operated by hand or pressurised with dry and oil-free compressed air! may only be used with GEDORE Automotive genuine spare parts and accessories! may only be used in the way described in these operating instructions! Any other use can result in DEATH or SEVERE INJURIES ! 1.4 Reasonably foreseeable misuse... -
Page 5: Personal Protective Equipment
Always check the setting of the dosing screw before using the oil pump with compressed air! Never use the oil pump if it is damaged or has loose parts or unauthorised modifications! Always wear your personal protective equipment (safety goggles, protective gloves, safety shoes) during work! © Copyright by GEDORE Automotive GmbH, Germany KL-124-43 (EN231134).indd... -
Page 6: Basic Safety Instructions
Always observe the max. loading capacity when using the oil pump, and never exceed it! Always wear your personal protective equipment (safety goggles, protective gloves, safety shoes) during work! Interrupt your work immediately if you are unsure about using the oil pump. Contact GEDORE Automotive GmbH if necessary! -
Page 7: Product Description
Operating instructions (Translation of the operating instructions) 2. PRODUCT DESCRIPTION 2.1 KL-0124-43 - Oil pump with tank (12 litres) Can be universally used on cars and commercial vehicles. Particularly suitable for transmissions for VW-Audi, Ford, BMW, Honda, Nissan, Toyota, Mercedes, Volvo. -
Page 8: Component Overview
Filling hose with shut-off valve [D] Quick change of filling adapters by a quick coupling. Tank, 12 litres [C] Other tanks with lids (KL-0124-433) are available as accessories. Adapter case [B] Vehicle-specific filler adapter © Copyright by GEDORE Automotive GmbH, Germany KL-124-43 (EN231134).indd... -
Page 9: Preparation
[C] with the required oil CLOSED 3. Close the "shut-off valve" on the compressed air connection [I] and on the filling hose [D], if they are still open CLOSED OPEN © Copyright by GEDORE Automotive GmbH, Germany KL-124-43 (EN231134).indd... -
Page 10: Preparations For Compressed Air Operation
Only use the oil pump in compressed air operation with dry and oil-free compressed air! 2. Couple the "compressed air hose" to the compressed air connection [I] as shown in 10 - © Copyright by GEDORE Automotive GmbH, Germany KL-124-43 (EN231134).indd... -
Page 11: Typical Application
Remove the compressed air hose on the compressed air connection [I] and foldthe carrying handle [E] briefly to the side. This opens a pressure release valve and releases any residual pressure in the tank [C]. - 11 © Copyright by GEDORE Automotive GmbH, Germany KL-124-43 (EN231134).indd... -
Page 12: Care And Storage
Automotive GmbH. Improper repair can result in SEVERE INJURIES. 7. ACCESSORIES/COMPLETIONS KL-0124-433 - 12-litre-tank with lid An additional tank (12 litres) for the oil pump - KL-0124-43, for easy change between and storage of several oil grades. KL-0124-4358-10 - Filling adapter, VW DSG gearbox...
