Talon 1810340 Manual

Item /
Part # Description
Assembly
2 2371884 JACK PLATE ELBOW BRACKET
4 2371999 ARM BRACKET
6 2371959 FLAG MOUNTING PLATE BRACKET
A
Includes 2994905 BAG ASSY, "J" ADAPTER BRACKET
8-12
8 2373519 BOLT-1/2-13 X 3" HHCS SS
10 2371757 WASHER-1/2", HEAVY DUTY, SS
12 2373108 NUT-1/2-13, NYLOC, SS
B
Includes 2994900 BAG ASSY,TALON TO ADP. BRACKET
14-22
14 2373526 BOLT-5/16-18 X 2.00" HHCS SS
16 2371749 WASHER-FLAT 5/16 SS
18 2371746 WASHER .750 X .3125 SS
20 2223100 NUT-5/16-18 NYLOCK S/S
22 2378608 ANTI SEIZE TUBE, 4CC, TALON
C
Includes 2994913 BAG ASSY, 3PC ADAPTER BRACKET
24-28
24 2373528 BOLT-1/2-13 X 4 1/4" SS
26 2371757 WASHER-1/2", HEAVY DUTY, SS
28 2373108 NUT-1/2-13, NYLOC, SS
p
2374945 INSTR. SHEET,3PC JACK PLATE BRK
✖
This part is included in an assembly and cannot be ordered individually.
▲
Not shown on Parts Diagram.
TOOLS AND RESOURCES REQUIRED
• Marine grade silicone
• Torque Wrench
MOUNTING CONSIDERATIONS
Before mounting your Talon Adapter Bracket, please give consideration to the following:
1. The Jack Plate Elbow Bracket will only work with compatible Jack Plate designs and may not work with all Jack Plates. Please refer to the
chart below for compatible Jack Plate designs. Instructions follow by Jack Plate in the order listed in the chart.
Manufacturer
TH Marine
R&R Designs
Bob's Machine Shop
1 | minnkotamotors.com
JACK PLATE SIDE MOUNT ADAPTER BRACKETS
Qty.
1
1
1
1
2
4
2
1
4
4
4
4
1
1
4
8
4
1
• 1/2" Drill Bit
• Pencil or marking tool
Model
Atlas Hydraulic
Z-Lock Manual
Slidemaster Manual
Action Series
Standard Series
UNIVERSAL OFFSET - PORT/STARBOARD
16 16
B B
18 18
22 22
8 8
A A
10 10
12 12
6 6
• A second person to help
with installation
1810340
14 14
C C
20 20
• 1/2" Box End or
Socket Wrench
Offset
4" Thru 12"
6" Thru 12"
6" Thru 12"
6" Thru 14"
6" Thru 14"
©2020 Johnson Outdoors Marine Electronics, Inc.
24 24
26 26
28 28
4 4
2 2
