2-ISLAND BBQ
ASSEMBLY INSTRUCTIONS
Includes:
Tools Needed:
H Bar
Front Panel
Back Panel
Side Panel
Top Panel
28x*
1x
2x
2x
2x
2x
Drill or Impact Driver
WATCH
ON
YouTube
*Amount of self tapping screws may vary.
*Islands may vary. General Instructions remain the same.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Diamond 2-ISLAND BBQ
Summary of Contents for Diamond 2-ISLAND BBQ
- Page 1 2-ISLAND BBQ ASSEMBLY INSTRUCTIONS Includes: Tools Needed: H Bar Front Panel Back Panel Side Panel Top Panel 28x* Drill or Impact Driver WATCH YouTube *Amount of self tapping screws may vary. *Islands may vary. General Instructions remain the same.
- Page 2 KD BBQ ISLAND 1. 36” Diamond Series DG-4B36 [LP/NG] 2. 24” Double Side Burner DG-DSB [LP/NG] 1. 48” Island 2. 24” Island *Islands may vary. General Instructions remain the same. Start by securing one corner of the BBQ Island. Connect “FRONT 1”...
- Page 3 Connect one end of “SIDE 2” to “BACK 2” forming a right angle. SIDE 2 Then, connect the other end of “SIDE 2” to “FRONT 2” also at a right angle. Place “TOP 1” on top of “Island 1” with the opening of the panel facing the front of the island.
